Cletrac H 12-20
The Cletrac H 12-20 is a crawler tractor built for farm work. It has a unique design with tracks instead of wheels, which helps it move well on different types of ground. This tractor is compact, measuring 96 inches long, 50 inches wide, and 52 inches tall. Under the hood, the H 12-20 has a Weidely engine with four cylinders. The engine runs on kerosene and is cooled by liquid. It has an average-sized engine for tractors of its time, with a displacement of 243 cubic inches. The tractor uses a gear transmission with two forward speeds and one reverse. It also has a Kingston carburetor to mix fuel and air for the engine. These features make the Cletrac H 12-20 a reliable choice for farmers looking for a sturdy, crawler-type tractor.

Key specifications
- Category
- Crawler
- Transmission
- Gear
Overview
About the Cletrac H 12-20
The Cletrac H 12-20 is a crawler tractor built for farm work. It has a unique design with tracks instead of wheels, which helps it move well on different types of ground. This tractor is compact, measuring 96 inches long, 50 inches wide, and 52 inches tall. Under the hood, the H 12-20 has a Weidely engine with four cylinders. The engine runs on kerosene and is cooled by liquid. It has an average-sized engine for tractors of its time, with a displacement of 243 cubic inches. The tractor uses a gear transmission with two forward speeds and one reverse. It also has a Kingston carburetor to mix fuel and air for the engine. These features make the Cletrac H 12-20 a reliable choice for farmers looking for a sturdy, crawler-type tractor.
Full specifications
Recorded specifications
General
| Manufacturer | Cletrac |
|---|---|
| Model | H 12-20 |
| Category | Crawler tractor |
| Type | Crawler |
Engine
| Make | Weidely |
|---|---|
| Cylinders | 4 |
| Displacement | 243ci(3.98 L) |
| Bore | 3.75in(95.25 mm) |
| Stroke | 5.5in(139.7 mm) |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 2 |
| Reverse gears | 1 |
Chassis & drive
| Chassis | Crawler |
|---|
Dimensions
| Length | 96in(2,438 mm) |
|---|---|
| Width | 50in(1,270 mm) |
| Height | 52in(1,321 mm) |
Parts and manuals
Parts and manuals for the Cletrac H 12-20
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the WeidelyAmazon
Fits the Weidely 4-cylinder kerosene engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the WeidelyAmazon
Fits the Weidely 4-cylinder kerosene engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the WeidelyAmazon
Fits the Weidely 4-cylinder kerosene engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the WeidelyAmazon
Fits the Weidely 4-cylinder kerosene engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Cletrac H 12-20 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Cletrac H 12-20 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Cletrac H 12-20 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
H 12-20 vs. Crawler median
Cletrac H 12-20 compared with other Crawler tractors
| Spec | This model | Crawler median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 243 ci | 468 ci | -48% | 34th |
| Cylinders | 4 | 6 | -33% | 33rd |
| Forward Gears | 2 | 10 | -80% | 2nd |
| Length | 96 in | 146 in | -34% | 2nd |
| Width | 50 in | 79.5 in | -37% | 13th |
| Height | 52 in | 90.6 in | -43% | 3rd |
Medians and percentiles are calculated from the crawler tractors in the database that have a recorded value for each specification (sample size 134–192 models).
Same manufacturer
Other Cletrac models
Other manufacturers
Models with similar horsepower
Gallery
Cletrac H 12-20 photos



FAQ
Frequently asked questions
What engine configuration does the Cletrac H 12-20 use?
The Cletrac H 12-20 is equipped with a 4-cylinder engine displacing 243 ci.
Which transmission does the Cletrac H 12-20 use?
The Cletrac H 12-20 is equipped with a Gear transmission with 2 forward gears.
How do I maintain a Cletrac H 12-20?
Routine service for the Cletrac H 12-20 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
