UtilityPerformance profile
Deutz-Fahr 4100E
The Deutz-Fahr 4100E is a powerful utility tractor built for tough farm work. It has a strong diesel engine made by SDF FARMotion. This engine has 3 cylinders and can produce 95.2 hp, which is very high for its class. The engine is turbocharged and intercooled, giving it extra power when needed. This tractor is designed for versatility. It has a 4x4 chassis with power steering, making it easy to handle in various conditions. The transmission has 15 forward and 15 reverse gears, allowing for precise speed control. The 4100E weighs 6,614 lb, which is above average for its size. It's 152 inches long and 78.9 inches wide, fitting well in most farm settings. The tractor has an open operator station and uses an electric starter for quick and easy operation.
ManufacturerDeutz-FahrPower95.2 hpEngine3-cylTransPartially Synchronized
Quick specs
- Category
- Utility
- Engine Power Output
- 95hp
- Operating Weight
- 6,614 lb
- Transmission
- Partially Synchronized
At a glance
How the 4100E compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
95.2 hp · 81st
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 4100E ranks at the 81st percentile for engine power among recorded utility tractors.
Overview
About the Deutz-Fahr 4100E
The Deutz-Fahr 4100E is a powerful utility tractor built for tough farm work. It has a strong diesel engine made by SDF FARMotion. This engine has 3 cylinders and can produce 95.2 hp, which is very high for its class. The engine is turbocharged and intercooled, giving it extra power when needed. This tractor is designed for versatility. It has a 4x4 chassis with power steering, making it easy to handle in various conditions. The transmission has 15 forward and 15 reverse gears, allowing for precise speed control. The 4100E weighs 6,614 lb, which is above average for its size. It's 152 inches long and 78.9 inches wide, fitting well in most farm settings. The tractor has an open operator station and uses an electric starter for quick and easy operation.
Full specifications
Every recorded spec
General
| Manufacturer | Deutz-Fahr |
|---|---|
| Model | 4100E |
| Category | Utility tractor |
| Type | 4x4 |
| Years built | 2018+ |
| Operating weight | 6,614lb |
Engine
| Make | SDF FARMotion |
|---|---|
| Model | KD3TA |
| Power | 95.2hp |
| Cylinders | 3 |
| Displacement | 176.2ci |
| Bore | 4.06in |
| Stroke | 4.53in |
Transmission
| Type | Partially Synchronized |
|---|---|
| Forward gears | 15 |
| Reverse gears | 15 |
Chassis & drive
| Chassis | 4x4 |
|---|---|
| Drive | MFWD 4WD |
| Steering | Power |
| Cab | Open |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 152in |
|---|---|
| Width | 78.9in |
| Operating weight | 6,614lb |
Head to head
4100E vs. Utility median
How the Deutz-Fahr 4100E compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 95.2 hp | 55 hp | +73% | 81st |
| Engine Displacement | 176 ci | 183 ci | -4% | 47th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 15 | 12 | +25% | 64th |
| Operating Weight | 6,614 lb | 5,303 lb | +25% | 63rd |
| Length | 152 in | 137 in | +11% | 68th |
| Width | 78.9 in | 66 in | +20% | 79th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Deutz-Fahr tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Deutz-Fahr AgroStar 4.71 | 95 hp | 9,283 lb | — | Compare → |
| Deutz-Fahr Agrotron 4.95 | 95 hp | 9,305 lb | — | Compare → |
| Deutz-Fahr Agrotron 6.00 | 95 hp | 11,047 lb | — | Compare → |
| Deutz-Fahr Agroplus 95 | 94 hp | 8,379 lb | — | Compare → |
| Deutz-Fahr 4100.4E | 93.9 hp | 6,834 lb | 2018+ | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro SRX 10400 | 95 hp | 4,718 lb | — | Compare → |
| Antonio Carraro TGF 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRG 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRX 10400 | 95 hp | 4,828 lb | — | Compare → |
| Antonio Carraro TTR 10400 | 95 hp | 4,806 lb | — | Compare → |
Explore
Deutz-Fahr siblings
Explore
Similar-spec models
Gallery
Deutz-Fahr 4100E photos
FAQ
Common questions
When was the Deutz-Fahr 4100E made?
The Deutz-Fahr 4100E entered production in 2018.
What type of hydraulic system does the Deutz-Fahr 4100E use?
Hydraulics on the Deutz-Fahr 4100E are Open Center.
What is the engine power output of the Deutz-Fahr 4100E?
Rated engine output for the Deutz-Fahr 4100E is 95.2 hp, delivered by a 3-cylinder engine. The engine displaces 176.2 ci.
What is the operating weight of the Deutz-Fahr 4100E?
In working trim, the Deutz-Fahr 4100E comes in at roughly 6,614 lb.
Which transmission does the Deutz-Fahr 4100E use?
The Deutz-Fahr 4100E is equipped with a Partially Synchronized transmission with 15 forward gears.
How do I maintain a Deutz-Fahr 4100E?
Routine service for the Deutz-Fahr 4100E covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
