UtilityPerformance profile
Antonio Carraro TRG 10400
The Antonio Carraro TRG 10400 is a powerful utility tractor built for tough jobs. It has a strong 4-wheel drive system and can turn easily with its special design. The tractor is powered by a VM Motori D754 diesel engine with 4 cylinders. This engine is turbocharged and intercooled, giving it extra power. It can produce 95 horsepower, which is quite high for its class. The TRG 10400 is designed to be versatile and easy to use. It has 16 forward and 16 reverse gears, allowing the driver to choose the right speed for any task. The tractor's size is compact, measuring 138 inches long, 55.7 inches wide, and 91.5 inches tall. It weighs 5,247 pounds, which is about average for its type. The tractor has different-sized tires in the front and back, helping it move well on various surfaces. It also has a strong hitch system for attaching tools and equipment.
ManufacturerAntonio CarraroPower95 hpEngine4-cyl
Quick specs
- Category
- Utility
- Engine Power Output
- 95hp
- Operating Weight
- 5,247 lb
At a glance
How the TRG 10400 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
95 hp · 81st
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The TRG 10400 ranks at the 81st percentile for engine power among recorded utility tractors.
Overview
About the Antonio Carraro TRG 10400
The Antonio Carraro TRG 10400 is a powerful utility tractor built for tough jobs. It has a strong 4-wheel drive system and can turn easily with its special design. The tractor is powered by a VM Motori D754 diesel engine with 4 cylinders. This engine is turbocharged and intercooled, giving it extra power. It can produce 95 horsepower, which is quite high for its class. The TRG 10400 is designed to be versatile and easy to use. It has 16 forward and 16 reverse gears, allowing the driver to choose the right speed for any task. The tractor's size is compact, measuring 138 inches long, 55.7 inches wide, and 91.5 inches tall. It weighs 5,247 pounds, which is about average for its type. The tractor has different-sized tires in the front and back, helping it move well on various surfaces. It also has a strong hitch system for attaching tools and equipment.
Full specifications
Every recorded spec
General
| Manufacturer | Antonio Carraro |
|---|---|
| Model | TRG 10400 |
| Category | Utility tractor |
| Type | 4x4 articulated 4WD |
| Operating weight | 5,247lb |
Engine
| Make | VM Motori |
|---|---|
| Model | D754 |
| Power | 95hp |
| Cylinders | 4 |
| Displacement | 181.2ci |
| Bore | 3.7in |
| Stroke | 4.21in |
Transmission
| Forward gears | 16 |
|---|---|
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 articulated 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydraulic Power |
Dimensions
| Length | 138in |
|---|---|
| Width | 55.7in |
| Height | 91.5in |
| Operating weight | 5,247lb |
Tires
| Front | 11.2R20 |
|---|---|
| Rear | 320/85R24 |
Head to head
TRG 10400 vs. Utility median
How the Antonio Carraro TRG 10400 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 95 hp | 55 hp | +73% | 81st |
| Engine Displacement | 181 ci | 183 ci | -1% | 49th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 5,247 lb | 5,303 lb | -1% | 50th |
| Length | 138 in | 137 in | +1% | 52nd |
| Width | 55.7 in | 66 in | -16% | 29th |
| Height | 91.5 in | 94.1 in | -3% | 45th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Antonio Carraro tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro TRX 10400 | 95 hp | 4,828 lb | — | Compare → |
| Antonio Carraro TTR 10400 | 95 hp | 4,806 lb | — | Compare → |
| Antonio Carraro Mach 4 | 87 hp | 6,725 lb | — | Compare → |
| Antonio Carraro SRH 9800 Infinity | 87 hp | — | — | Compare → |
| Antonio Carraro SX 9400S | 87 hp | 4,707 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 6080 | 93 hp | 6,500 lb | 1980–1985 | Compare → |
| Agrinar T-100 | 97.9 hp | 3,850 lb | — | Compare → |
| Belarus 9011 | 98 hp | 7,750 lb | — | Compare → |
| Belarus 9021 | 98 hp | 7,750 lb | — | Compare → |
| Belarus 9045 | 98 hp | 8,300 lb | — | Compare → |
Explore
Antonio Carraro siblings
Explore
Similar-spec models
Gallery
Antonio Carraro TRG 10400 photos
FAQ
Common questions
How much horsepower does the Antonio Carraro TRG 10400 have?
The Antonio Carraro TRG 10400 produces 95 hp from its 4-cylinder engine. Engine displacement is 181.2 ci.
How much does the Antonio Carraro TRG 10400 weigh?
The Antonio Carraro TRG 10400 weighs about 5,247 lb in operating condition.
What size tires does the Antonio Carraro TRG 10400 use?
Factory rubber for the Antonio Carraro TRG 10400 is 11.2R20 front tires and 320/85R24 rear tires.
What hitch category is the Antonio Carraro TRG 10400?
The Antonio Carraro TRG 10400 uses a Category II/I hitch.
What maintenance does the Antonio Carraro TRG 10400 require?
Like any tractor, the Antonio Carraro TRG 10400 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
