Deutz-Fahr Agrotron 235
The Deutz-Fahr Agrotron 235 is a powerful tractor built for serious farm work. It has a strong Deutz engine with 6 cylinders and 232 horsepower. This engine is turbocharged and intercooled, which helps it perform well in tough conditions. The tractor uses diesel fuel and has a liquid cooling system to keep the engine running smoothly. One of the best features of the Agrotron 235 is its transmission. It has 40 forward gears and 40 reverse gears, giving the driver lots of options for different tasks. The tractor is big, measuring about 197 inches long and 128 inches tall. It's also heavy, weighing nearly 20,000 pounds. This size and weight help it handle heavy loads and tough field work. The Agrotron 235 has large tires, with 520/70R34 in front and 710/70R42 in the back, which are good for gripping the soil. It also has a strong hydraulic system and a category III hitch in the back for attaching various farm tools.
ManufacturerDeutz-FahrPower232 hp(173.0 kW)Class150–300 HP tractors →Engine6-cylinderTransmissionFour-Speed Power Shift
Key specifications
- Category
- Agricultural
- Engine power
- 232hp
- Operating weight
- 19,952 lb
- Transmission
- Four-Speed Power Shift
Category comparison
Agrotron 235 compared with its category
vs. Agricultural medianDistribution
Engine Power (hp)
All recorded Agricultural tractors
232 hp · 85th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The Agrotron 235 ranks at the 85th percentile for engine power among recorded agricultural tractors.
Overview
About the Deutz-Fahr Agrotron 235
The Deutz-Fahr Agrotron 235 is a powerful tractor built for serious farm work. It has a strong Deutz engine with 6 cylinders and 232 horsepower. This engine is turbocharged and intercooled, which helps it perform well in tough conditions. The tractor uses diesel fuel and has a liquid cooling system to keep the engine running smoothly. One of the best features of the Agrotron 235 is its transmission. It has 40 forward gears and 40 reverse gears, giving the driver lots of options for different tasks. The tractor is big, measuring about 197 inches long and 128 inches tall. It's also heavy, weighing nearly 20,000 pounds. This size and weight help it handle heavy loads and tough field work. The Agrotron 235 has large tires, with 520/70R34 in front and 710/70R42 in the back, which are good for gripping the soil. It also has a strong hydraulic system and a category III hitch in the back for attaching various farm tools.
Full specifications
Recorded specifications
General
| Manufacturer | Deutz-Fahr |
|---|---|
| Model | Agrotron 235 |
| Category | Agricultural tractor |
| Operating weight | 19,952lb(9,050 kg) |
Engine
| Make | Deutz |
|---|---|
| Model | BF6M1013EC |
| Power | 232hp(173 kW) |
| Cylinders | 6 |
| Displacement | 436.1ci(7.15 L) |
| Bore | 4.25in(107.9 mm) |
| Stroke | 5.12in(130 mm) |
Transmission
| Type | Four-Speed Power Shift |
|---|---|
| Forward gears | 40 |
| Reverse gears | 40 |
Hydraulics
| Type | Closed Center Load Sensing |
|---|
Dimensions
| Length | 196.9in(5,001 mm) |
|---|---|
| Height | 128.2in(3,256 mm) |
| Operating weight | 19,952lb(9,050 kg) |
Tires
| Front | 520/70R34Convert |
|---|---|
| Rear | 710/70R42Convert |
Closest alternatives
Agrotron 235 compared with the nearest models by horsepower
By engine horsepower, the nearest agricultural models to the Agrotron 235 are the Claas Atles 926 and the Challenger MT595D. The Claas Atles 926 matches it on rated power and weighs 450 lb less. The Challenger MT595D makes 1.9 hp more and weighs 640 lb less. Of the 3 models, the Agrotron 235 has the highest weight per horsepower at 86 lb per hp.
| Spec | Deutz-Fahr Agrotron 235 | Claas Atles 926 | Challenger MT595D |
|---|---|---|---|
| Engine power | 232 hp173 kW | 232 hp173 kW | 233.9 hp174.4 kW |
| Operating weight | 19,952 lb9,050 kg | 19,501 lb8,845 kg | 19,310 lb8,759 kg |
| Weight per hp | 86 lb/hp52 kg/kW | 84 lb/hp51 kg/kW | 83 lb/hp50 kg/kW |
| Displacement | 436.1 ci7.15 L | 436.4 ci7.15 L | 449 ci7.36 L |
| Cylinders | 6 | 6 | 6 |
| Transmission | Four-Speed Power Shift | 18-speed | Selective gear fixed ratio with partial (6) range operator controlled powershift |
| Drive | - | 4WD | Front wheel assist |
Calculators
Calculators for the Agrotron 235
PTO power
About 193 to 209 PTO hp
Estimated from the 232 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 232 hp tractor can run
Maximum size is about a 27.5 ft rotary cutter or a 23.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
100 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
232 hp is 173.0 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Tires
Convert the 710/70R42 tire size
The calculator gives diameter, rolling circumference and the metric or inch equivalent.
Category medians
Agrotron 235 vs. Agricultural median
Deutz-Fahr Agrotron 235 compared with other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 232 hp | 110 hp | +111% | 85th |
| Engine Displacement | 436 ci | 336 ci | +30% | 77th |
| Cylinders | 6 | 5.5 | +9% | 74th |
| Forward Gears | 40 | 16 | +150% | 96th |
| Operating Weight | 19,952 lb | 10,914 lb | +83% | 84th |
| Length | 197 in | 173 in | +14% | 76th |
| Height | 128 in | 111 in | +16% | 88th |
Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 795–1,130 models).
Same manufacturer
Other Deutz-Fahr models
Other manufacturers
Models with similar horsepower
Gallery
Deutz-Fahr Agrotron 235 photos
FAQ
Frequently asked questions
How much horsepower does the Deutz-Fahr Agrotron 235 have?
The Deutz-Fahr Agrotron 235 produces 232 hp from its 6-cylinder engine. Engine displacement is 436.1 ci.
What hydraulics does the Deutz-Fahr Agrotron 235 have?
The Deutz-Fahr Agrotron 235 uses a Closed Center Load Sensing hydraulic system.
What are the factory tire sizes for the Deutz-Fahr Agrotron 235?
The Deutz-Fahr Agrotron 235 comes with 520/70R34 front tires and 710/70R42 rear tires.
What three-point hitch category does the Deutz-Fahr Agrotron 235 use?
The Deutz-Fahr Agrotron 235 has a Category III three-point hitch.
How much does the Deutz-Fahr Agrotron 235 weigh?
The Deutz-Fahr Agrotron 235 weighs about 19,952 lb in operating condition.
What transmission is in the Deutz-Fahr Agrotron 235?
Transmission on the Deutz-Fahr Agrotron 235 is Four-Speed Power Shift, with 40 forward speeds.
What maintenance does the Deutz-Fahr Agrotron 235 require?
The Deutz-Fahr Agrotron 235 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
