Fendt 514
The Fendt 514 is a powerful and versatile tractor designed for modern farming needs. It features a water-cooled 4-cylinder engine with a displacement of 1346 cubic inches. This engine packs a punch, delivering 143.5 horsepower at 2100 rpm, making it suitable for a wide range of agricultural tasks. This tractor is built to handle heavy-duty work with ease. It has a front hitch that can lift up to 7687.6 pounds, perfect for attaching various implements. The Fendt 514 also comes with a 1000 rpm PTO, allowing it to power different attachments. With its large size (175.4 inches long, 99.6 inches wide, and 117.6 inches tall) and hefty operating weight of 23148.6 pounds, this tractor offers stability and traction in challenging field conditions. Additional features include a 500-hour engine oil service interval and a top speed of 25 mph, making it both low-maintenance and efficient for transportation between work sites.

Key specifications
- Category
- Agricultural
- Engine power
- 144hp
- Operating weight
- 23,148.6 lb
Category comparison
514 compared with its category
vs. Agricultural medianDistribution
Engine Power (hp)
All recorded Agricultural tractors
This model
The 514 ranks at the 67th percentile for engine power among recorded agricultural tractors.
Overview
About the Fendt 514
The Fendt 514 is a powerful and versatile tractor designed for modern farming needs. It features a water-cooled 4-cylinder engine with a displacement of 1346 cubic inches. This engine packs a punch, delivering 143.5 horsepower at 2100 rpm, making it suitable for a wide range of agricultural tasks. This tractor is built to handle heavy-duty work with ease. It has a front hitch that can lift up to 7687.6 pounds, perfect for attaching various implements. The Fendt 514 also comes with a 1000 rpm PTO, allowing it to power different attachments. With its large size (175.4 inches long, 99.6 inches wide, and 117.6 inches tall) and hefty operating weight of 23148.6 pounds, this tractor offers stability and traction in challenging field conditions. Additional features include a 500-hour engine oil service interval and a top speed of 25 mph, making it both low-maintenance and efficient for transportation between work sites.
Full specifications
Recorded specifications
General
| Manufacturer | Fendt |
|---|---|
| Model | 514 |
| Category | Agricultural tractor |
| Operating weight | 23,148.6lb(10,500 kg) |
Engine
| Power | 143.5hp(107 kW) |
|---|---|
| Cylinders | 4 |
| Displacement | 1,346ci(22.06 L) |
| Bore | 4in(101.6 mm) |
| Stroke | 5in(127 mm) |
Power take-off
| PTO speed | 1,000rpm |
|---|
Dimensions
| Length | 175.4in(4,455 mm) |
|---|---|
| Width | 99.6in(2,530 mm) |
| Height | 117.6in(2,987 mm) |
| Operating weight | 23,148.6lb(10,500 kg) |
Closest alternatives
514 compared with the nearest models by horsepower
Among agricultural tractors, the Massey Ferguson 6715S and the Deutz-Fahr AgroStar 6.61 are closest to the Fendt 514 in rated horsepower. The Massey Ferguson 6715S is rated 0.5 hp higher and weighs 8,650 lb less, carrying 101 lb per horsepower against 161 lb. The Deutz-Fahr AgroStar 6.61 makes 0.5 hp less and weighs 11,240 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. Of the 3 models, the 514 has the highest weight per horsepower at 161 lb per hp.
| Spec | Fendt 514 | Massey Ferguson 6715S | Deutz-Fahr AgroStar 6.61 |
|---|---|---|---|
| Engine power | 143.5 hp107 kW | 144 hp107.4 kW | 143 hp106.6 kW |
| Operating weight | 23,149 lb10,500 kg | 14,495 lb6,575 kg | 11,907 lb5,401 kg |
| Weight per hp | 161 lb/hp98 kg/kW | 101 lb/hp61 kg/kW | 83 lb/hp51 kg/kW |
| Displacement | 1,346 ci22.06 L | 299 ci4.9 L | 373.9 ci6.13 L |
| Cylinders | 4 | 4 | 6 |
| Transmission | - | Dyna-4 Power Shift | Gear type or synchronized gears type |
| Years built | - | 2017+ | 1990-1995 |
Calculators
Calculators for the 514
PTO power
About 119 to 129 PTO hp
Estimated from the 143.5 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 143.5 hp tractor can run
Maximum size is about a 17 ft rotary cutter or a 14.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
188 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
143.5 hp is 107.0 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the Fendt 514
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Fendt 514Amazon
For the 4-cylinder engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Fendt 514Amazon
For the 4-cylinder engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Fendt 514Amazon
For the 4-cylinder engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Fendt 514Amazon
For the 4-cylinder engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Fendt 514 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Fendt 514 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Fendt 514 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
514 vs. Agricultural median
Fendt 514 compared with other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 144 hp | 110 hp | +30% | 67th |
| Engine Displacement | 1,346 ci | 336 ci | +301% | 99th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Operating Weight | 23,149 lb | 10,914 lb | +112% | 90th |
| Length | 175 in | 173 in | +1% | 53rd |
| Width | 99.6 in | 79.5 in | +25% | 82nd |
| Height | 118 in | 111 in | +6% | 69th |
| 3-Point Hitch Capacity | 7,688 lb | 12,126 lb | -37% | 25th |
Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 93–1,130 models).
Same manufacturer
Other Fendt models
Other manufacturers
Models with similar horsepower
Gallery
Fendt 514 photos



FAQ
Frequently asked questions
How powerful is the Fendt 514?
The Fendt 514 has an engine power output of 143.5 hp. It is powered by a 4-cylinder engine displacing 1,346 ci.
What is the working weight of the Fendt 514?
The operating weight of the Fendt 514 is approximately 23,148.6 lb.
What routine service does the Fendt 514 need?
Regular maintenance for the Fendt 514 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
