Fiat 431R
The Fiat 431R is a compact orchard and vineyard tractor designed for specialized agricultural work. It features a 2-wheel drive (2WD) system and a manual steering setup, making it easy to maneuver in tight spaces between rows of crops. The tractor is powered by a 4-cylinder, liquid-cooled diesel engine made by FIAT. This engine is naturally aspirated and produces 40 horsepower at 2300 RPM, which is on the lower end of the power range for tractors. The 431R comes with a gear transmission that offers 6 forward gears and 2 reverse gears, giving operators good control over speed and power. It has agricultural tires on both front and rear, suitable for various farm tasks. The tractor's compact size, measuring 113.5 inches long, 43.25 inches wide, and 51.125 inches tall, makes it ideal for working in orchards and vineyards where space is limited. With an operating weight of 3350 lb, it's a relatively light tractor, which helps reduce soil compaction. The 431R also features an electric starter system, making it easy to get the tractor running each day.
ManufacturerFiatPower40 hpEngine4-cylTransGear
Quick specs
- Category
- Agricultural
- Engine Power Output
- 40hp
- Operating Weight
- 3,350 lb
- Transmission
- Gear
At a glance
How the 431R compares
vs. Agricultural medianDistribution
Engine Power (hp)
Across all Agricultural tractors
40 hp · 6th
This model
13
Median 110 hp
282
This modelAgricultural tractorsMediann = 1,028
The 431R ranks at the 6th percentile for engine power among recorded agricultural tractors.
Overview
About the Fiat 431R
The Fiat 431R is a compact orchard and vineyard tractor designed for specialized agricultural work. It features a 2-wheel drive (2WD) system and a manual steering setup, making it easy to maneuver in tight spaces between rows of crops. The tractor is powered by a 4-cylinder, liquid-cooled diesel engine made by FIAT. This engine is naturally aspirated and produces 40 horsepower at 2300 RPM, which is on the lower end of the power range for tractors. The 431R comes with a gear transmission that offers 6 forward gears and 2 reverse gears, giving operators good control over speed and power. It has agricultural tires on both front and rear, suitable for various farm tasks. The tractor's compact size, measuring 113.5 inches long, 43.25 inches wide, and 51.125 inches tall, makes it ideal for working in orchards and vineyards where space is limited. With an operating weight of 3350 lb, it's a relatively light tractor, which helps reduce soil compaction. The 431R also features an electric starter system, making it easy to get the tractor running each day.
Full specifications
Every recorded spec
General
| Manufacturer | Fiat |
|---|---|
| Model | 431R |
| Category | Agricultural tractor |
| Type | 4x2 |
| Operating weight | 3,350lb |
Engine
| Make | FIAT |
|---|---|
| Power | 40hp |
| Cylinders | 4 |
| Displacement | 138.5ci |
| Bore | 3.35in |
| Stroke | 3.94in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 6 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
| Steering | Manual |
Dimensions
| Length | 113.5in |
|---|---|
| Width | 43.25in |
| Height | 51.13in |
| Operating weight | 3,350lb |
Head to head
431R vs. Agricultural median
How the Fiat 431R compares to other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 40 hp | 110 hp | -64% | 6th |
| Engine Displacement | 139 ci | 336 ci | -59% | 4th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 6 | 16 | -62% | 11th |
| Operating Weight | 3,350 lb | 10,914 lb | -69% | 3rd |
| Length | 114 in | 173 in | -34% | 4th |
| Width | 43.3 in | 79.5 in | -46% | 5th |
| Height | 51.1 in | 111 in | -54% | 4th |
Medians and percentiles are computed from the agricultural tractors in our database with a recorded value for each spec (sample sizes 497–1,130 models).
Compare to tractors with similar specs
Commonly compared Fiat tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Fiat 421R | 40 hp | 3,087 lb | — | Compare → |
| Fiat 45-76 | 44.4 hp | 3,748 lb | 2003+ | Compare → |
| Fiat 465C | 54 hp | 6,349 lb | — | Compare → |
| Fiat 55-76 | 54.2 hp | 3,792 lb | — | Compare → |
| Fiat 55-65 | 55 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely OilPull K 12/20 | 40 hp | 6,430 lb | — | Compare → |
| Allis Chalmers 160 | 40 hp | 4,674 lb | 1970–1975 | Compare → |
| Allis Chalmers 5040 | 40 hp | 3,858 lb | 1976–1980 | Compare → |
| Allis Chalmers 6140 | 40 hp | 4,000 lb | 1982–1985 | Compare → |
| Allis Chalmers D15 Series I | 40 hp | 3,990 lb | 1960–1963 | Compare → |
Explore
Fiat siblings
Explore
Similar-spec models
Gallery
Fiat 431R photos
FAQ
Common questions
What is the engine power output of the Fiat 431R?
Rated engine output for the Fiat 431R is 40 hp, delivered by a 4-cylinder engine. The engine displaces 138.5 ci.
Which transmission does the Fiat 431R use?
The Fiat 431R is equipped with a Gear transmission with 6 forward gears.
What is the operating weight of the Fiat 431R?
In working trim, the Fiat 431R comes in at roughly 3,350 lb.
How do I maintain a Fiat 431R?
Routine service for the Fiat 431R covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
