Gibson I
The Gibson I is a 2-wheel drive tractor with a 4x2 chassis. It has a manual steering system and a gear transmission with 4 forward gears and 1 reverse gear. The tractor is powered by a Hercules QXLD engine that runs on gasoline. This 6-cylinder engine has a displacement of 236.7 cubic inches and operates at 1800 rpm. The Gibson I measures 127.25 inches in length and stands 67 inches tall. It weighs 4512 pounds and is equipped with agricultural tires on both the front and rear. The front tires are 16 inches in diameter and 5.5 inches wide, while the rear tires are larger at 38 inches in diameter and 12 inches wide. The tractor features an electric starter and operates on a 6-volt electrical system. It has a coolant capacity of 16 quarts, which helps keep the engine running smoothly during operation.
ManufacturerGibsonEngine6-cylTransGear
Quick specs
- Category
- Standard Tread
- Operating Weight
- 4,512 lb
- Transmission
- Gear
Overview
About the Gibson I
The Gibson I is a 2-wheel drive tractor with a 4x2 chassis. It has a manual steering system and a gear transmission with 4 forward gears and 1 reverse gear. The tractor is powered by a Hercules QXLD engine that runs on gasoline. This 6-cylinder engine has a displacement of 236.7 cubic inches and operates at 1800 rpm. The Gibson I measures 127.25 inches in length and stands 67 inches tall. It weighs 4512 pounds and is equipped with agricultural tires on both the front and rear. The front tires are 16 inches in diameter and 5.5 inches wide, while the rear tires are larger at 38 inches in diameter and 12 inches wide. The tractor features an electric starter and operates on a 6-volt electrical system. It has a coolant capacity of 16 quarts, which helps keep the engine running smoothly during operation.
Full specifications
Every recorded spec
General
| Manufacturer | Gibson |
|---|---|
| Model | I |
| Category | Standard Tread tractor |
| Type | 4x2 2WD |
| Operating weight | 4,512lb |
Engine
| Make | Hercules |
|---|---|
| Model | QXLD |
| Cylinders | 6 |
| Displacement | 236.7ci |
| Bore | 3.44in |
| Stroke | 4.13in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 4 |
| Reverse gears | 1 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
Dimensions
| Length | 127.25in |
|---|---|
| Height | 67in |
| Operating weight | 4,512lb |
Capacities
| Cooling system | 4gal |
|---|
Head to head
I vs. Standard Tread median
How the Gibson I compares to other Standard Tread tractors
| Spec | This model | Standard Tread median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 237 ci | 382 ci | -38% | 19th |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 4 | 4 | at median | 50th |
| Operating Weight | 4,512 lb | 6,834 lb | -34% | 20th |
| Length | 127 in | 137 in | -7% | 27th |
| Height | 67 in | 72.3 in | -7% | 34th |
Medians and percentiles are computed from the standard tread tractors in our database with a recorded value for each spec (sample sizes 234–367 models).
Compare to tractors with similar specs
Commonly compared Gibson tractors
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
Gibson siblings
Explore
Similar-spec models
Gallery
Gibson I photos
FAQ
Common questions
What engine configuration does the Gibson I use?
The Gibson I is equipped with a 6-cylinder engine displacing 236.7 ci.
What is the working weight of the Gibson I?
The operating weight of the Gibson I is approximately 4,512 lb.
What type of transmission does the Gibson I have?
The Gibson I uses a Gear transmission offering 4 forward gears.
What routine service does the Gibson I need?
Regular maintenance for the Gibson I includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
