Brand siblingRow Crop
Hesston 1180
The Hesston 1180 is a row crop tractor built for farm work. It has a 2WD drive system and hydrostatic power steering, making it easy to control in the fields. The tractor comes with a 24-speed forward and 8-speed reverse transmission, giving farmers lots of options for different tasks. Under the hood, the Hesston 1180 has a Fiat 8065 engine. This diesel engine is turbocharged and liquid-cooled, with 6 cylinders. It has an average engine size for its class, measuring 335 cubic inches. The engine runs at a very high 2550 RPM, which means it can work hard and fast. The tractor weighs 11,800 pounds, which is about average for similar tractors. It's 162.8 inches long and 112 inches tall, with big farm tires in the front and back. The rear hitch is a Type II, good for attaching many farm tools.
ManufacturerHesstonEngine6-cyl
Quick specs
- Category
- Row Crop
- Operating Weight
- 11,800 lb
Overview
About the Hesston 1180
The Hesston 1180 is a row crop tractor built for farm work. It has a 2WD drive system and hydrostatic power steering, making it easy to control in the fields. The tractor comes with a 24-speed forward and 8-speed reverse transmission, giving farmers lots of options for different tasks. Under the hood, the Hesston 1180 has a Fiat 8065 engine. This diesel engine is turbocharged and liquid-cooled, with 6 cylinders. It has an average engine size for its class, measuring 335 cubic inches. The engine runs at a very high 2550 RPM, which means it can work hard and fast. The tractor weighs 11,800 pounds, which is about average for similar tractors. It's 162.8 inches long and 112 inches tall, with big farm tires in the front and back. The rear hitch is a Type II, good for attaching many farm tools.
Full specifications
Every recorded spec
General
| Manufacturer | Hesston |
|---|---|
| Model | 1180 |
| Category | Row Crop tractor |
| Type | 4x2 2WD |
| Operating weight | 11,800lb |
Engine
| Make | Fiat |
|---|---|
| Model | 8065 |
| Cylinders | 6 |
| Displacement | 335ci |
| Bore | 4.05in |
| Stroke | 4.33in |
Transmission
| Forward gears | 24 |
|---|---|
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 162.8in |
|---|---|
| Height | 112in |
| Operating weight | 11,800lb |
Tires
| Front | 11.00-16 |
|---|---|
| Rear | 18.4-38 |
Head to head
1180 vs. Row Crop median
How the Hesston 1180 compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 335 ci | 391 ci | -14% | 36th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 24 | 16 | +50% | 81st |
| Operating Weight | 11,800 lb | 12,307 lb | -4% | 46th |
| Length | 163 in | 180 in | -9% | 27th |
| Height | 112 in | 114 in | -1% | 44th |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 1,140–1,417 models).
Compare to tractors with similar specs
Commonly compared Hesston tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Hesston 100-90 | 100 hp | 9,540 lb | — | Compare → |
| Hesston 1380 | — | 12,015 lb | — | Compare → |
| Hesston 140-90 | — | — | — | Compare → |
| Hesston 1580 | — | 13,350 lb | — | Compare → |
| Hesston 160-90 | — | 13,350 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
Hesston siblings
Explore
Similar-spec models
Gallery
Hesston 1180 photos
FAQ
Common questions
How many cylinders does the Hesston 1180 have?
The Hesston 1180 runs a 6-cylinder engine with a displacement of 335 ci.
What type of hydraulic system does the Hesston 1180 use?
Hydraulics on the Hesston 1180 are Open center.
What size tires does the Hesston 1180 use?
Factory rubber for the Hesston 1180 is 11.00-16 front tires and 18.4-38 rear tires.
What is the operating weight of the Hesston 1180?
In working trim, the Hesston 1180 comes in at roughly 11,800 lb.
How do I maintain a Hesston 1180?
Routine service for the Hesston 1180 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
