Hesston 140-90
The Hesston 140-90 is a powerful row crop tractor built for serious farming. It has a 2WD drive system and a sturdy 4x2 chassis, making it great for field work. The tractor comes with a comfortable cab for the driver and uses power steering to make it easy to control. Under the hood, the Hesston 140-90 has a strong Fiat 8065.25 engine. This diesel engine has 6 cylinders and is turbocharged for extra power. It's liquid-cooled to keep it running smoothly. The engine size is average compared to other tractors, but it can run at very high speeds. The tractor has a 16-speed synchronized transmission, giving farmers lots of options for different tasks. It also has a Category 3 rear hitch, which can handle big implements. The Hesston 140-90 is a big tractor, measuring over 13 feet long and nearly 6 feet tall, with large rear tires for good traction in the fields.
ManufacturerHesstonEngine6-cylTransSynchronized
Quick specs
- Category
- Row Crop
- Transmission
- Synchronized
Overview
About the Hesston 140-90
The Hesston 140-90 is a powerful row crop tractor built for serious farming. It has a 2WD drive system and a sturdy 4x2 chassis, making it great for field work. The tractor comes with a comfortable cab for the driver and uses power steering to make it easy to control. Under the hood, the Hesston 140-90 has a strong Fiat 8065.25 engine. This diesel engine has 6 cylinders and is turbocharged for extra power. It's liquid-cooled to keep it running smoothly. The engine size is average compared to other tractors, but it can run at very high speeds. The tractor has a 16-speed synchronized transmission, giving farmers lots of options for different tasks. It also has a Category 3 rear hitch, which can handle big implements. The Hesston 140-90 is a big tractor, measuring over 13 feet long and nearly 6 feet tall, with large rear tires for good traction in the fields.
Full specifications
Every recorded spec
General
| Manufacturer | Hesston |
|---|---|
| Model | 140-90 |
| Category | Row Crop tractor |
| Type | 4x2 2WD |
Engine
| Make | Fiat |
|---|---|
| Model | 8065.25 |
| Cylinders | 6 |
| Displacement | 358ci |
| Bore | 4.09in |
| Stroke | 4.52in |
Transmission
| Type | Synchronized |
|---|---|
| Forward gears | 16 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | Cab |
Dimensions
| Length | 162.75in |
|---|---|
| Height | 70.75in |
Head to head
140-90 vs. Row Crop median
How the Hesston 140-90 compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 358 ci | 391 ci | -8% | 40th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 16 | 16 | at median | 50th |
| Length | 163 in | 180 in | -9% | 26th |
| Height | 70.8 in | 114 in | -38% | 7th |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 1,140–1,417 models).
Compare to tractors with similar specs
Commonly compared Hesston tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Hesston 100-90 | 100 hp | 9,540 lb | — | Compare → |
| Hesston 1180 | — | 11,800 lb | — | Compare → |
| Hesston 1380 | — | 12,015 lb | — | Compare → |
| Hesston 1580 | — | 13,350 lb | — | Compare → |
| Hesston 160-90 | — | 13,350 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
Hesston siblings
Explore
Similar-spec models
Gallery
Hesston 140-90 photos
FAQ
Common questions
What engine configuration does the Hesston 140-90 use?
The Hesston 140-90 is equipped with a 6-cylinder engine displacing 358 ci.
Which transmission does the Hesston 140-90 use?
The Hesston 140-90 is equipped with a Synchronized transmission with 16 forward gears.
What three-point hitch category does the Hesston 140-90 use?
The Hesston 140-90 has a Category 3 three-point hitch.
How do I maintain a Hesston 140-90?
Routine service for the Hesston 140-90 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
