Sub-CompactPerformance profile
Hinomoto Plainsman E150
The Hinomoto Plainsman E150 is a compact 2WD tractor designed for small-scale farming and light agricultural work. It features a 6-forward and 2-reverse gear transmission, making it easy to operate in various field conditions. The tractor is powered by a Toyosha S-88 diesel engine, which is liquid-cooled and has 2 cylinders. With 15 horsepower, this tractor offers enough power for basic farm tasks. The Plainsman E150 has a length of 98.4 inches and a width of 39.8 inches, making it suitable for working in tight spaces. It weighs 1360 pounds, which is relatively light for a tractor. The tractor comes with agricultural tires for both front and rear wheels, providing good traction in farm settings. It has a Category I hitch at the rear, allowing it to connect with various implements. The hydraulic system is an open center type, and the tractor uses a 12-volt electrical system with an electric starter. Additional features include glow plugs for easier starting in cold weather and a dry-type air cleaner to protect the engine from dust and debris.
ManufacturerHinomotoPower15 hpEngine2-cylTransGear
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 15hp
- Operating Weight
- 1,360 lb
- Transmission
- Gear
At a glance
How the Plainsman E150 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
15 hp · 9th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The Plainsman E150 ranks at the 9th percentile for engine power among recorded sub-compact tractors.
Overview
About the Hinomoto Plainsman E150
The Hinomoto Plainsman E150 is a compact 2WD tractor designed for small-scale farming and light agricultural work. It features a 6-forward and 2-reverse gear transmission, making it easy to operate in various field conditions. The tractor is powered by a Toyosha S-88 diesel engine, which is liquid-cooled and has 2 cylinders. With 15 horsepower, this tractor offers enough power for basic farm tasks. The Plainsman E150 has a length of 98.4 inches and a width of 39.8 inches, making it suitable for working in tight spaces. It weighs 1360 pounds, which is relatively light for a tractor. The tractor comes with agricultural tires for both front and rear wheels, providing good traction in farm settings. It has a Category I hitch at the rear, allowing it to connect with various implements. The hydraulic system is an open center type, and the tractor uses a 12-volt electrical system with an electric starter. Additional features include glow plugs for easier starting in cold weather and a dry-type air cleaner to protect the engine from dust and debris.
Full specifications
Every recorded spec
General
| Manufacturer | Hinomoto |
|---|---|
| Model | Plainsman E150 |
| Category | Sub-Compact tractor |
| Type | 2WD |
| Operating weight | 1,360lb |
Engine
| Make | Toyosha |
|---|---|
| Model | S-88 |
| Power | 15hp |
| Cylinders | 2 |
| Displacement | 54.07ci |
| Bore | 3.31in |
| Stroke | 3.15in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 6 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 2WD |
|---|---|
| Drive | 2WD |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 98.4in |
|---|---|
| Width | 39.8in |
| Operating weight | 1,360lb |
Capacities
| Cooling system | 1.05gal |
|---|
Head to head
Plainsman E150 vs. Sub-Compact median
How the Hinomoto Plainsman E150 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 15 hp | 26.9 hp | -44% | 9th |
| Engine Displacement | 54.1 ci | 91.4 ci | -41% | 13th |
| Cylinders | 2 | 3 | -33% | 11th |
| Forward Gears | 6 | 9 | -33% | 18th |
| Operating Weight | 1,360 lb | 2,700 lb | -50% | 15th |
| Length | 98.4 in | 113 in | -13% | 28th |
| Width | 39.8 in | 50.7 in | -21% | 11th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).
Compare to tractors with similar specs
Commonly compared Hinomoto tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Hinomoto E15 | 15.8 hp | 1,538 lb | — | Compare → |
| Hinomoto E16 | 15.8 hp | 1,760 lb | — | Compare → |
| Hinomoto MB-1500 | 17 hp | 1,025 lb | — | Compare → |
| Hinomoto C174 | 19.7 hp | 1,600 lb | — | Compare → |
| Hinomoto E204 | 19.7 hp | 2,066 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Bolens G152 | 15 hp | 1,034 lb | — | Compare → |
| Bolens G154 | 15 hp | 1,124 lb | — | Compare → |
| Bolens H1502 | 15 hp | 1,080 lb | — | Compare → |
| Cub Cadet 1515 | 15 hp | 498 lb | 2002+ | Compare → |
| Cub Cadet 1525 | 15 hp | 500 lb | — | Compare → |
Explore
Hinomoto siblings
Explore
Similar-spec models
Gallery
Hinomoto Plainsman E150 photos
FAQ
Common questions
How powerful is the Hinomoto Plainsman E150?
The Hinomoto Plainsman E150 has an engine power output of 15 hp. It is powered by a 2-cylinder engine displacing 54.07 ci.
What type of hydraulic system does the Hinomoto Plainsman E150 use?
Hydraulics on the Hinomoto Plainsman E150 are Open Center.
What is the working weight of the Hinomoto Plainsman E150?
The operating weight of the Hinomoto Plainsman E150 is approximately 1,360 lb.
What type of transmission does the Hinomoto Plainsman E150 have?
The Hinomoto Plainsman E150 uses a Gear transmission offering 6 forward gears.
What routine service does the Hinomoto Plainsman E150 need?
Regular maintenance for the Hinomoto Plainsman E150 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
