International Harvester TD-14
The International Harvester TD-14 is a powerful diesel tractor built for tough jobs. It has a big 4-cylinder engine that holds 460.7 cubic inches. This engine is cooled by liquid and breathes in air naturally. The TD-14 uses a gear transmission with 6 forward speeds and 2 reverse speeds, giving the driver good control. This tractor is quite large, measuring 134 inches long, 74 inches wide, and 73.75 inches tall. It's also very heavy, weighing 17,500 pounds. The TD-14 has some special features like an oil-bath air cleaner and a dry disc clutch. It starts up using gasoline, which is helpful in cold weather. The engine can hold 80 quarts of coolant, which helps keep it running smoothly during long work days.
ManufacturerInternational HarvesterEngine4-cylTransGear
Quick specs
- Category
- Industrial
- Operating Weight
- 17,500 lb
- Transmission
- Gear
Overview
About the International Harvester TD-14
The International Harvester TD-14 is a powerful diesel tractor built for tough jobs. It has a big 4-cylinder engine that holds 460.7 cubic inches. This engine is cooled by liquid and breathes in air naturally. The TD-14 uses a gear transmission with 6 forward speeds and 2 reverse speeds, giving the driver good control. This tractor is quite large, measuring 134 inches long, 74 inches wide, and 73.75 inches tall. It's also very heavy, weighing 17,500 pounds. The TD-14 has some special features like an oil-bath air cleaner and a dry disc clutch. It starts up using gasoline, which is helpful in cold weather. The engine can hold 80 quarts of coolant, which helps keep it running smoothly during long work days.
Full specifications
Every recorded spec
General
| Manufacturer | International Harvester |
|---|---|
| Model | TD-14 |
| Category | Industrial tractor |
| Operating weight | 17,500lb |
Engine
| Make | International Harvester |
|---|---|
| Cylinders | 4 |
| Displacement | 460.7ci |
| Bore | 4.75in |
| Stroke | 6.5in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 6 |
| Reverse gears | 2 |
Dimensions
| Length | 134in |
|---|---|
| Width | 74in |
| Height | 73.75in |
| Operating weight | 17,500lb |
Capacities
| Cooling system | 20gal |
|---|
Head to head
TD-14 vs. Industrial median
How the International Harvester TD-14 compares to other Industrial tractors
| Spec | This model | Industrial median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 461 ci | 284 ci | +62% | 67th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 6 | 5 | +20% | 65th |
| Operating Weight | 17,500 lb | 9,127 lb | +92% | 64th |
| Length | 134 in | 125 in | +7% | 55th |
| Width | 74 in | 70.5 in | +5% | 57th |
| Height | 73.8 in | 74.9 in | -2% | 49th |
Medians and percentiles are computed from the industrial tractors in our database with a recorded value for each spec (sample sizes 38–55 models).
Compare to tractors with similar specs
Commonly compared International Harvester tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| International Harvester 2444 | 47 hp | — | 1967–1971 | Compare → |
| International Harvester 3414 | 43.4 hp | 5,203 lb | 1961–1968 | Compare → |
| International Harvester TD-6 | 50 hp | 7,280 lb | 1959–1969 | Compare → |
| International Harvester 10-20 Titan | — | 5,525 lb | — | Compare → |
| International Harvester 100 | — | 2,600 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
International Harvester siblings
Brand sibling
Brand sibling
Brand siblingExplore
Similar-spec models
Gallery
International Harvester TD-14 photos
FAQ
Common questions
What engine configuration does the International Harvester TD-14 use?
The International Harvester TD-14 is equipped with a 4-cylinder engine displacing 460.7 ci.
How much does the International Harvester TD-14 weigh?
The International Harvester TD-14 weighs about 17,500 lb in operating condition.
What transmission is in the International Harvester TD-14?
Transmission on the International Harvester TD-14 is Gear, with 6 forward speeds.
What maintenance does the International Harvester TD-14 require?
Like any tractor, the International Harvester TD-14 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
