Sub-CompactPerformance profile
Iseki TL3700
The Iseki TL3700 is a compact and capable tractor designed for various farming tasks. It features an Isuzu 4FB1 engine, which is a 4-cylinder, liquid-cooled diesel engine. This engine has a displacement of 110.9 cubic inches and produces 36 horsepower at 2600 RPM. The tractor's power is well-suited for small to medium-sized farms. One of the standout features of the TL3700 is its transmission, offering 18 forward gears and 6 reverse gears. This wide range of gears allows farmers to choose the perfect speed for different jobs. The tractor measures 126.4 inches long, 60.2 inches wide, and 84.1 inches tall, making it compact enough to work in tight spaces. It weighs 2976 pounds, providing a good balance between stability and maneuverability. The TL3700 comes with agricultural tires on both front and rear, suitable for various field conditions. It also features an electric starter for easy operation and a JIS1 hitch type for attaching implements.
ManufacturerIsekiPower36 hpEngine4-cyl
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 36hp
- Operating Weight
- 2,976 lb
At a glance
How the TL3700 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
36 hp · 68th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The TL3700 ranks at the 68th percentile for engine power among recorded sub-compact tractors.
Overview
About the Iseki TL3700
The Iseki TL3700 is a compact and capable tractor designed for various farming tasks. It features an Isuzu 4FB1 engine, which is a 4-cylinder, liquid-cooled diesel engine. This engine has a displacement of 110.9 cubic inches and produces 36 horsepower at 2600 RPM. The tractor's power is well-suited for small to medium-sized farms. One of the standout features of the TL3700 is its transmission, offering 18 forward gears and 6 reverse gears. This wide range of gears allows farmers to choose the perfect speed for different jobs. The tractor measures 126.4 inches long, 60.2 inches wide, and 84.1 inches tall, making it compact enough to work in tight spaces. It weighs 2976 pounds, providing a good balance between stability and maneuverability. The TL3700 comes with agricultural tires on both front and rear, suitable for various field conditions. It also features an electric starter for easy operation and a JIS1 hitch type for attaching implements.
Full specifications
Every recorded spec
General
| Manufacturer | Iseki |
|---|---|
| Model | TL3700 |
| Category | Sub-Compact tractor |
| Operating weight | 2,976lb |
Engine
| Make | Isuzu |
|---|---|
| Model | 4FB1 |
| Power | 36hp |
| Cylinders | 4 |
| Displacement | 110.9ci |
| Bore | 3.31in |
| Stroke | 3.23in |
Transmission
| Forward gears | 18 |
|---|---|
| Reverse gears | 6 |
Dimensions
| Length | 126.4in |
|---|---|
| Width | 60.2in |
| Height | 84.1in |
| Operating weight | 2,976lb |
Head to head
TL3700 vs. Sub-Compact median
How the Iseki TL3700 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 36 hp | 26.9 hp | +34% | 68th |
| Engine Displacement | 111 ci | 91.4 ci | +21% | 63rd |
| Cylinders | 4 | 3 | +33% | 90th |
| Forward Gears | 18 | 9 | +100% | 96th |
| Operating Weight | 2,976 lb | 2,700 lb | +10% | 56th |
| Length | 126 in | 113 in | +11% | 71st |
| Width | 60.2 in | 50.7 in | +19% | 76th |
| Height | 84.1 in | 78.4 in | +7% | 58th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).
Compare to tractors with similar specs
Commonly compared Iseki tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Iseki TG6375 | 35.7 hp | 3,428 lb | — | Compare → |
| Iseki TA375 | 36.5 hp | 3,815 lb | — | Compare → |
| Iseki TK37 | 36.5 hp | 3,759 lb | — | Compare → |
| Iseki TA370 | 37 hp | 3,439 lb | — | Compare → |
| Iseki TA537 | 37 hp | 3,384 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro TTR 3800 | 36 hp | 2,150 lb | — | Compare → |
| Barreiros R-350 S | 36 hp | — | — | Compare → |
| Belarus 300 | 36 hp | 4,500 lb | — | Compare → |
| Belarus 3011 | 36 hp | 4,425 lb | — | Compare → |
| Belarus 3021 | 36 hp | 4,500 lb | — | Compare → |
Explore
Iseki siblings
Explore
Similar-spec models
Gallery
Iseki TL3700 photos
FAQ
Common questions
What is the engine power output of the Iseki TL3700?
Rated engine output for the Iseki TL3700 is 36 hp, delivered by a 4-cylinder engine. The engine displaces 110.9 ci.
What is the operating weight of the Iseki TL3700?
In working trim, the Iseki TL3700 comes in at roughly 2,976 lb.
How do I maintain a Iseki TL3700?
Routine service for the Iseki TL3700 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
