Specialized tractorsSpec sheet
Antonio Carraro TTR 3800
The Antonio Carraro TTR 3800 is a compact but powerful tractor designed for versatile use. It features a 4x4 articulated chassis with four-wheel drive, making it great for working in tight spaces and on uneven ground. The tractor has a hydrostatic transmission with infinite forward and reverse gears, allowing for smooth and easy speed changes. Under the hood, the TTR 3800 is equipped with a Lombardini 1503 engine. This liquid-cooled diesel engine has 3 cylinders and puts out 36 hp. It has a displacement of 94.7 ci, which is about average for tractors in its class. The engine starts with an electric starter for quick and easy operation. With an operating weight of 2150 lb, this tractor is light enough to be nimble but still has enough heft for serious work. It comes with a Category I hitch, suitable for attaching various implements and tools.
ManufacturerAntonio CarraroPower36 hp(26.8 kW)Class25–40 HP tractors →Engine3-cylinderTransmissionHydrostatic
Key specifications
- Category
- Specialized
- Engine power
- 36hp
- Operating weight
- 2,150 lb
- Transmission
- Hydrostatic
Category comparison
TTR 3800 compared with its category
vs. Specialized medianDistribution
Engine Power (hp)
All recorded Specialized tractors
36 hp · 25th
This model
15
Median 62 hp
85
This modelSpecialized tractorsMediann = 55
The TTR 3800 ranks at the 25th percentile for engine power among recorded specialized tractors.
Overview
About the Antonio Carraro TTR 3800
The Antonio Carraro TTR 3800 is a compact but powerful tractor designed for versatile use. It features a 4x4 articulated chassis with four-wheel drive, making it great for working in tight spaces and on uneven ground. The tractor has a hydrostatic transmission with infinite forward and reverse gears, allowing for smooth and easy speed changes. Under the hood, the TTR 3800 is equipped with a Lombardini 1503 engine. This liquid-cooled diesel engine has 3 cylinders and puts out 36 hp. It has a displacement of 94.7 ci, which is about average for tractors in its class. The engine starts with an electric starter for quick and easy operation. With an operating weight of 2150 lb, this tractor is light enough to be nimble but still has enough heft for serious work. It comes with a Category I hitch, suitable for attaching various implements and tools.
Full specifications
Recorded specifications
General
| Manufacturer | Antonio Carraro |
|---|---|
| Model | TTR 3800 |
| Category | Specialized tractor |
| Type | 4x4 articulated 4WD |
| Operating weight | 2,150lb(975.2 kg) |
Engine
| Make | Lombardini |
|---|---|
| Model | 1503 |
| Power | 36hp(26.85 kW) |
| Cylinders | 3 |
| Displacement | 94.7ci(1.55 L) |
| Bore | 3.46in(87.88 mm) |
| Stroke | 3.35in(85.09 mm) |
Transmission
| Type | Hydrostatic |
|---|
Chassis & drive
| Chassis | 4x4 articulated 4WD |
|---|---|
| Drive | 4WD |
| Steering | Articulated Power Steering |
Dimensions
| Operating weight | 2,150lb(975.2 kg) |
|---|
Closest alternatives
TTR 3800 compared with the nearest models by horsepower
The closest specialized models to the Antonio Carraro TTR 3800 by rated horsepower are the Kubota L35 and the Kubota L39. The Kubota L35 is rated 1 hp lower and weighs 3,850 lb more, at 171 lb per horsepower against 60 lb. The Kubota L39 makes 3 hp more and weighs 4,840 lb more, so it carries more weight per horsepower, which helps traction in draft work. Of the 3 models, the TTR 3800 has the lowest weight per horsepower at 60 lb per hp.
| Spec | Antonio Carraro TTR 3800 | Kubota L35 | Kubota L39 |
|---|---|---|---|
| Engine power | 36 hp26.8 kW | 35 hp26.1 kW | 39 hp29.1 kW |
| Operating weight | 2,150 lb975 kg | 5,996 lb2,720 kg | 6,988 lb3,170 kg |
| Weight per hp | 60 lb/hp36 kg/kW | 171 lb/hp104 kg/kW | 179 lb/hp109 kg/kW |
| Displacement | 94.7 ci1.55 L | 100.5 ci1.65 L | 111.4 ci1.83 L |
| Cylinders | 3 | 3 | 3 |
| Transmission | Hydrostatic | Glide Shift | Glide Shift |
| Drive | 4WD | 4WD | 4WD |
| Years built | - | 1999-2004 | 2005+ |
Calculators
Calculators for the TTR 3800
PTO power
About 30 to 32 PTO hp
Estimated from the 36 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 36 hp tractor can run
The calculator sizes mowers, tillers, discs, plows and balers for this tractor.
Ballast
69 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
36 hp is 26.8 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
TTR 3800 vs. Specialized median
Antonio Carraro TTR 3800 compared with other Specialized tractors
| Spec | This model | Specialized median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 36 hp | 62 hp | -42% | 25th |
| Engine Displacement | 94.7 ci | 239 ci | -60% | 17th |
| Cylinders | 3 | 4 | -25% | 18th |
| Operating Weight | 2,150 lb | 12,600 lb | -83% | 7th |
Medians and percentiles are calculated from the specialized tractors in the database that have a recorded value for each specification (sample size 50–58 models).
Same manufacturer
Other Antonio Carraro models
Other manufacturers
Models with similar horsepower
Gallery
Antonio Carraro TTR 3800 photos
FAQ
Frequently asked questions
How much horsepower does the Antonio Carraro TTR 3800 have?
The Antonio Carraro TTR 3800 produces 36 hp from its 3-cylinder engine. Engine displacement is 94.7 ci.
How much does the Antonio Carraro TTR 3800 weigh?
The Antonio Carraro TTR 3800 weighs about 2,150 lb in operating condition.
What transmission is in the Antonio Carraro TTR 3800?
Transmission on the Antonio Carraro TTR 3800 is Hydrostatic.
What three-point hitch category does the Antonio Carraro TTR 3800 use?
The Antonio Carraro TTR 3800 has a Category I three-point hitch.
What maintenance does the Antonio Carraro TTR 3800 require?
The Antonio Carraro TTR 3800 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
