John Deere 410
The John Deere 410 is a specialized backhoe loader tractor that was made from 1971 to 1983. It's a big machine, measuring 285.4 inches long, 83.9 inches wide, and 102 inches tall. This tractor weighs 14,209 pounds, which is pretty heavy. The 410 has a John Deere diesel engine with 4 cylinders. It can produce 66 horsepower at 2500 RPM. The engine is liquid-cooled and uses 13 quarts of coolant. This tractor has a power shuttle transmission with 8 forward and 8 reverse gears, giving the driver lots of options for different jobs. It has power steering and hydraulic wet disc brakes, which make it easier and safer to use. The tractor comes with either a four-post ROPS (roll-over protection structure) or a cab with a heater option for comfort in cold weather.
ManufacturerJohn DeerePower66 hp(49.2 kW)Class60–100 HP tractors →Engine4-cylinderTransmissionPower shuttle with wet disc clutch
Key specifications
- Category
- Specialized
- Engine power
- 66hp
- Operating weight
- 14,209 lb
- Transmission
- Power shuttle with wet disc clutch
Category comparison
410 compared with its category
vs. Specialized medianDistribution
Engine Power (hp)
All recorded Specialized tractors
66 hp · 55th
This model
15
Median 62 hp
85
This modelSpecialized tractorsMediann = 55
The 410 ranks at the 55th percentile for engine power among recorded specialized tractors.
Overview
About the John Deere 410
The John Deere 410 is a specialized backhoe loader tractor that was made from 1971 to 1983. It's a big machine, measuring 285.4 inches long, 83.9 inches wide, and 102 inches tall. This tractor weighs 14,209 pounds, which is pretty heavy. The 410 has a John Deere diesel engine with 4 cylinders. It can produce 66 horsepower at 2500 RPM. The engine is liquid-cooled and uses 13 quarts of coolant. This tractor has a power shuttle transmission with 8 forward and 8 reverse gears, giving the driver lots of options for different jobs. It has power steering and hydraulic wet disc brakes, which make it easier and safer to use. The tractor comes with either a four-post ROPS (roll-over protection structure) or a cab with a heater option for comfort in cold weather.
Full specifications
Recorded specifications
General
| Manufacturer | John Deere |
|---|---|
| Model | 410 |
| Category | Specialized tractor |
| Type | 4x2 2WD |
| Years built | 1971–1983 |
| Operating weight | 14,209lb(6,445 kg) |
Engine
| Make | John Deere |
|---|---|
| Power | 66hp(49.22 kW) |
| Cylinders | 4 |
| Displacement | 219ci(3.59 L) |
| Bore | 4.02in(102.1 mm) |
| Stroke | 4.33in(110 mm) |
Transmission
| Type | Power shuttle with wet disc clutch |
|---|---|
| Forward gears | 8 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Steering | Power |
| Brakes | Hydraulic wet disc |
| Cab | Four-post ROPS or Cab with available heater |
Hydraulics
| Type | Closed center |
|---|
Dimensions
| Length | 285.4in(7,249 mm) |
|---|---|
| Width | 83.9in(2,131 mm) |
| Height | 102in(2,591 mm) |
| Operating weight | 14,209lb(6,445 kg) |
Capacities
| Cooling system | 3.25gal(12.3 L) |
|---|
Closest alternatives
410 compared with the nearest models by horsepower
Among specialized tractors, the John Deere 310B and the John Deere 410B are closest to the John Deere 410 in rated horsepower. The John Deere 310B makes 1 hp less and weighs 1,010 lb less. It entered production in 1982, 11 years after the 410. The John Deere 410B is rated 4 hp lower and weighs 190 lb more. It entered production in 1983, 12 years after the 410.
| Spec | John Deere 410 | John Deere 310B | John Deere 410B |
|---|---|---|---|
| Engine power | 66 hp49.2 kW | 65 hp48.5 kW | 62 hp46.2 kW |
| Operating weight | 14,209 lb6,445 kg | 13,195 lb5,985 kg | 14,396 lb6,530 kg |
| Weight per hp | 215 lb/hp131 kg/kW | 203 lb/hp123 kg/kW | 232 lb/hp141 kg/kW |
| Displacement | 219 ci3.59 L | 219 ci3.59 L | 219 ci3.59 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Power shuttle with wet disc clutch | Power Shuttle | - |
| Years built | 1971-1983 | 1982-1986 | 1983-1986 |
Calculators
Calculators for the 410
PTO power
About 55 to 59 PTO hp
Estimated from the 66 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 66 hp tractor can run
Maximum size is about a 8 ft rotary cutter or a 6.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
250 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
66 hp is 49.2 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the John Deere 410
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the John DeereAmazon
Fits the John Deere 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the John DeereAmazon
Fits the John Deere 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the John DeereAmazon
Fits the John Deere 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the John DeereAmazon
Fits the John Deere 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- John Deere 410 service and repair manualseManualOnline
Digital manuals. Built 1971 to 1983. Check the serial number range on the listing.
- John Deere 410 operator's manualAmazon
Printed and reprint manuals. Built 1971 to 1983. Check the serial number range on the listing.
- John Deere 410 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
410 vs. Specialized median
John Deere 410 compared with other Specialized tractors
| Spec | This model | Specialized median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 66 hp | 62 hp | +6% | 55th |
| Engine Displacement | 219 ci | 239 ci | -8% | 43rd |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 8 | 4 | +100% | 88th |
| Operating Weight | 14,209 lb | 12,600 lb | +13% | 69th |
| Length | 285 in | 274 in | +4% | 90th |
| Width | 83.9 in | 83.9 in | at median | 50th |
| Height | 102 in | 108 in | -5% | 40th |
Medians and percentiles are calculated from the specialized tractors in the database that have a recorded value for each specification (sample size 43–58 models).
Same manufacturer
Other John Deere models
Other manufacturers
Models with similar horsepower
Gallery
John Deere 410 photos
FAQ
Frequently asked questions
When was the John Deere 410 in production?
John Deere 410 production started in 1971 and ended in 1983.
How much does the John Deere 410 weigh?
The John Deere 410 weighs about 14,209 lb in operating condition.
What transmission is in the John Deere 410?
Transmission on the John Deere 410 is Power shuttle with wet disc clutch, with 8 forward speeds.
What type of hydraulic system does the John Deere 410 use?
Hydraulics on the John Deere 410 are Closed center.
How much horsepower does the John Deere 410 have?
The John Deere 410 produces 66 hp from its 4-cylinder engine. Engine displacement is 219 ci.
What maintenance does the John Deere 410 require?
The John Deere 410 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
