UtilityPerformance profile
John Deere 5100E
The John Deere 5100E is a powerful and versatile tractor designed for various farming tasks. It features a John Deere PowerTech 4045 engine, which is a 4-cylinder, turbocharged diesel engine with 89.49 hp. This engine is liquid-cooled and has a displacement of 276 ci, making it suitable for demanding agricultural work. The tractor comes with a selective gear fixed ratio transmission, offering 12 forward and 12 reverse gears for a total of 24 gears. This gives farmers plenty of options for different tasks and speeds. The 5100E has power steering and can be equipped with either a ROPS or a cab for operator comfort. It has a Category II hitch at the rear and a PTO with 540 and 540E rpm options. The hydraulic system is an open center type with a pump flow capacity of 16.5 gpm and pressure of 2873 psi, allowing for efficient operation of various implements.
ManufacturerJohn DeerePower89.49 hpEngine4-cylTransSelective gear fixed ratio
Quick specs
- Category
- Utility
- Engine Power Output
- 89hp
- Operating Weight
- 7,940 lb
- Transmission
- Selective gear fixed ratio
At a glance
How the 5100E compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
89.49 hp · 77th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 5100E ranks at the 77th percentile for engine power among recorded utility tractors.
Overview
About the John Deere 5100E
The John Deere 5100E is a powerful and versatile tractor designed for various farming tasks. It features a John Deere PowerTech 4045 engine, which is a 4-cylinder, turbocharged diesel engine with 89.49 hp. This engine is liquid-cooled and has a displacement of 276 ci, making it suitable for demanding agricultural work. The tractor comes with a selective gear fixed ratio transmission, offering 12 forward and 12 reverse gears for a total of 24 gears. This gives farmers plenty of options for different tasks and speeds. The 5100E has power steering and can be equipped with either a ROPS or a cab for operator comfort. It has a Category II hitch at the rear and a PTO with 540 and 540E rpm options. The hydraulic system is an open center type with a pump flow capacity of 16.5 gpm and pressure of 2873 psi, allowing for efficient operation of various implements.
Full specifications
Every recorded spec
General
| Manufacturer | John Deere |
|---|---|
| Model | 5100E |
| Category | Utility tractor |
| Operating weight | 7,940lb |
Engine
| Make | John Deere |
|---|---|
| Model | PowerTech 4045 |
| Power | 89.49hp |
| Cylinders | 4 |
| Displacement | 276ci |
| Bore | 4.19in |
| Stroke | 5in |
Transmission
| Type | Selective gear fixed ratio |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Steering | Power |
|---|---|
| Cab | ROPS / Cab |
Hydraulics
| Type | Open Center |
|---|---|
| Pump flow | 16.5gpm |
| Pressure | 2,873psi |
Power take-off
| Rear PTO | 540/540E |
|---|---|
| PTO speed | 540rpm |
Dimensions
| Length | 154.5in |
|---|---|
| Width | 69.6in |
| Height | 101.2in |
| Operating weight | 7,940lb |
Head to head
5100E vs. Utility median
How the John Deere 5100E compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 89.5 hp | 55 hp | +63% | 77th |
| Engine Displacement | 276 ci | 183 ci | +51% | 81st |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 7,940 lb | 5,303 lb | +50% | 75th |
| Length | 155 in | 137 in | +13% | 71st |
| Width | 69.6 in | 66 in | +5% | 59th |
| Height | 101 in | 94.1 in | +8% | 69th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared John Deere tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| John Deere 2840 | 89 hp | 8,700 lb | 1977–1979 | Compare → |
| John Deere 5510 | 89 hp | 5,720 lb | 1998–2001 | Compare → |
| John Deere 5520 | 89 hp | 4,809 lb | 2002–2004 | Compare → |
| John Deere 5715 | 89 hp | 5,732 lb | — | Compare → |
| John Deere 5725 | 89 hp | 5,512 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro Mach 2 | 87 hp | 6,504 lb | — | Compare → |
| Antonio Carraro Mach 4 | 87 hp | 6,725 lb | — | Compare → |
| Antonio Carraro SRH 9800 Infinity | 87 hp | — | — | Compare → |
| Antonio Carraro SRX 9800 | 87 hp | 4,850 lb | — | Compare → |
| Antonio Carraro SX 9400S | 87 hp | 4,707 lb | — | Compare → |
Explore
John Deere siblings
Explore
Similar-spec models
Gallery
John Deere 5100E photos
FAQ
Common questions
What is the engine power output of the John Deere 5100E?
Rated engine output for the John Deere 5100E is 89.49 hp, delivered by a 4-cylinder engine. The engine displaces 276 ci.
Which transmission does the John Deere 5100E use?
The John Deere 5100E is equipped with a Selective gear fixed ratio transmission with 12 forward gears.
What type of hydraulic system does the John Deere 5100E use?
Hydraulics on the John Deere 5100E are Open Center, delivering 16.5 gpm of pump flow.
What hitch category is the John Deere 5100E?
The John Deere 5100E uses a Category Category 3 hitch.
What is the operating weight of the John Deere 5100E?
In working trim, the John Deere 5100E comes in at roughly 7,940 lb.
How do I maintain a John Deere 5100E?
Routine service for the John Deere 5100E covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
