CrawlerPerformance profile
John Deere 8360RT
The John Deere 8360RT is a powerful crawler tractor designed for heavy-duty farm work. It has tracks instead of wheels, which helps it move better on different types of ground. The tractor is big, measuring 270.9 inches long and 131.3 inches tall. It's also heavy, weighing 35,605 pounds, which is above average for tractors like this. Under the hood, the 8360RT has a strong John Deere PowerTech PSX engine. This engine has 6 cylinders and uses diesel fuel. It can produce up to 339.86 horsepower, which is a lot of power for tough jobs. The engine is cooled by liquid and has two turbochargers to make it even stronger. The tractor also has a special transmission that lets it change speeds smoothly without gears. This makes it easy to drive in different conditions. The hydraulic system is strong too, with a pump that can move 65 gallons of fluid per minute. This helps run attachments and lift heavy loads.
ManufacturerJohn DeerePower339.86 hpEngine6-cylTransInfinitely Variable Transmission (IVT) with four mechanical ranges and automatic shifting between ranges
Quick specs
- Category
- Crawler
- Engine Power Output
- 340hp
- Operating Weight
- 35,605 lb
- Transmission
- Infinitely Variable Transmission (IVT) with four mechanical ranges and automatic shifting between ranges
At a glance
How the 8360RT compares
vs. Crawler medianDistribution
Engine Power (hp)
Across all Crawler tractors
339.86 hp · 70th
This model
18
Median 200 hp
508
This modelCrawler tractorsMediann = 142
The 8360RT ranks at the 70th percentile for engine power among recorded crawler tractors.
Overview
About the John Deere 8360RT
The John Deere 8360RT is a powerful crawler tractor designed for heavy-duty farm work. It has tracks instead of wheels, which helps it move better on different types of ground. The tractor is big, measuring 270.9 inches long and 131.3 inches tall. It's also heavy, weighing 35,605 pounds, which is above average for tractors like this. Under the hood, the 8360RT has a strong John Deere PowerTech PSX engine. This engine has 6 cylinders and uses diesel fuel. It can produce up to 339.86 horsepower, which is a lot of power for tough jobs. The engine is cooled by liquid and has two turbochargers to make it even stronger. The tractor also has a special transmission that lets it change speeds smoothly without gears. This makes it easy to drive in different conditions. The hydraulic system is strong too, with a pump that can move 65 gallons of fluid per minute. This helps run attachments and lift heavy loads.
Full specifications
Every recorded spec
General
| Manufacturer | John Deere |
|---|---|
| Model | 8360RT |
| Category | Crawler tractor |
| Type | Track |
| Operating weight | 35,605lb |
Engine
| Make | John Deere |
|---|---|
| Model | PowerTech PSX |
| Power | 339.86hp |
| Cylinders | 6 |
| Displacement | 548ci |
| Bore | 4.66in |
| Stroke | 5.35in |
Transmission
| Type | Infinitely Variable Transmission (IVT) with four mechanical ranges and automatic shifting between ranges |
|---|
Chassis & drive
| Chassis | Track |
|---|---|
| Steering | Electro-Hydraulic Power |
| Brakes | Wet multiple disc hydraulically actuated by foot pedal |
| Cab | Cab |
Hydraulics
| Type | Closed Center Pressure-Flow Compensated |
|---|---|
| Pump flow | 65gpm |
| Pressure | 2,417psi |
Dimensions
| Length | 270.9in |
|---|---|
| Height | 131.3in |
| Operating weight | 35,605lb |
Capacities
| Cooling system | 10.83gal |
|---|
Head to head
8360RT vs. Crawler median
How the John Deere 8360RT compares to other Crawler tractors
| Spec | This model | Crawler median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 340 hp | 200 hp | +70% | 70th |
| Engine Displacement | 548 ci | 468 ci | +17% | 62nd |
| Cylinders | 6 | 6 | at median | 50th |
| Operating Weight | 35,605 lb | 23,320 lb | +53% | 76th |
| Length | 271 in | 146 in | +86% | 98th |
| Height | 131 in | 90.6 in | +45% | 83rd |
Medians and percentiles are computed from the crawler tractors in our database with a recorded value for each spec (sample sizes 134–192 models).
Compare to tractors with similar specs
Commonly compared John Deere tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| John Deere 8430T | 335 hp | 28,790 lb | — | Compare → |
| John Deere 9400T | 346.53 hp | 42,620 lb | — | Compare → |
| John Deere 9520T | 333 hp | 43,585 lb | — | Compare → |
| John Deere 8345RT | 329.11 hp | 34,670 lb | — | Compare → |
| John Deere 8370RT | 359.53 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH 9170 | 335 hp | — | — | Compare → |
| CaseIH 9270 | 335 hp | 34,045 lb | — | Compare → |
| CaseIH Magnum 315 | 347 hp | 27,800 lb | — | Compare → |
| CaseIH Magnum 335 | 330 hp | 21,350 lb | — | Compare → |
| Big Bud HN350 | 350 hp | 40,000 lb | — | Compare → |
Explore
John Deere siblings
Explore
Similar-spec models
Gallery
John Deere 8360RT photos
FAQ
Common questions
How powerful is the John Deere 8360RT?
The John Deere 8360RT has an engine power output of 339.86 hp. It is powered by a 6-cylinder engine displacing 548 ci.
What type of hydraulic system does the John Deere 8360RT use?
Hydraulics on the John Deere 8360RT are Closed Center Pressure-Flow Compensated, delivering 65 gpm of pump flow.
What is the working weight of the John Deere 8360RT?
The operating weight of the John Deere 8360RT is approximately 35,605 lb.
What type of transmission does the John Deere 8360RT have?
The John Deere 8360RT uses an Infinitely Variable Transmission (IVT) with four mechanical ranges and automatic shifting between ranges transmission.
What routine service does the John Deere 8360RT need?
Regular maintenance for the John Deere 8360RT includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
