Kioti LK3052
The Kioti LK3052 is a utility tractor that packs a punch in a compact size. It's powered by a Daedong TD1400 diesel engine with 3 cylinders and 30.5 horsepower. This engine is liquid-cooled and has a displacement of 85.1 cubic inches, which is below average for tractors in its class. However, it makes up for this with a very high rated RPM of 2600, allowing it to perform well in various tasks. This tractor measures 111.4 inches long, 51.7 inches wide, and 80.3 inches tall, making it easy to maneuver in tight spaces. It has a synchronized shuttle transmission with 8 forward and 8 reverse gears, giving operators plenty of options for different jobs. The LK3052 features power steering and a Type I rear hitch, along with an open center hydraulic system. With a weight of 2866 pounds, it's on the lighter side for utility tractors, but still sturdy enough for most farm work. Additional features include a 10.8-inch ground clearance, glow plugs for easy starting in cold weather, and a dry disc clutch for smooth operation.
ManufacturerKiotiPower30.5 hpEngine3-cylTransSynchronized shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 31hp
- Operating Weight
- 2,866 lb
- Transmission
- Synchronized shuttle
At a glance
How the LK3052 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
30.5 hp · 23rd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The LK3052 ranks at the 23rd percentile for engine power among recorded utility tractors.
Overview
About the Kioti LK3052
The Kioti LK3052 is a utility tractor that packs a punch in a compact size. It's powered by a Daedong TD1400 diesel engine with 3 cylinders and 30.5 horsepower. This engine is liquid-cooled and has a displacement of 85.1 cubic inches, which is below average for tractors in its class. However, it makes up for this with a very high rated RPM of 2600, allowing it to perform well in various tasks. This tractor measures 111.4 inches long, 51.7 inches wide, and 80.3 inches tall, making it easy to maneuver in tight spaces. It has a synchronized shuttle transmission with 8 forward and 8 reverse gears, giving operators plenty of options for different jobs. The LK3052 features power steering and a Type I rear hitch, along with an open center hydraulic system. With a weight of 2866 pounds, it's on the lighter side for utility tractors, but still sturdy enough for most farm work. Additional features include a 10.8-inch ground clearance, glow plugs for easy starting in cold weather, and a dry disc clutch for smooth operation.
Full specifications
Every recorded spec
General
| Manufacturer | Kioti |
|---|---|
| Model | LK3052 |
| Category | Utility tractor |
| Operating weight | 2,866lb |
Engine
| Make | Daedong |
|---|---|
| Model | TD1400 |
| Power | 30.5hp |
| Cylinders | 3 |
| Displacement | 85.1ci |
| Bore | 3.35in |
| Stroke | 3.22in |
Transmission
| Type | Synchronized shuttle |
|---|---|
| Forward gears | 8 |
| Reverse gears | 8 |
Chassis & drive
| Steering | Power |
|---|
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 111.4in |
|---|---|
| Width | 51.7in |
| Height | 80.3in |
| Operating weight | 2,866lb |
Head to head
LK3052 vs. Utility median
How the Kioti LK3052 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 30.5 hp | 55 hp | -45% | 23rd |
| Engine Displacement | 85.1 ci | 183 ci | -54% | 14th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 2,866 lb | 5,303 lb | -46% | 21st |
| Length | 111 in | 137 in | -18% | 17th |
| Width | 51.7 in | 66 in | -22% | 20th |
| Height | 80.3 in | 94.1 in | -15% | 28th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Kioti tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kioti LK3054XS | 30.5 hp | 2,974 lb | — | Compare → |
| Kioti LK3054 | 30.4 hp | 2,976 lb | 1993–2003 | Compare → |
| Kioti CK30 | 30 hp | 3,042 lb | 2004–2014 | Compare → |
| Kioti CK30 HST | 30 hp | 3,143.8 lb | — | Compare → |
| Kioti CK27 | 28 hp | 3,117 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST30 | 30.3 hp | 2,594 lb | — | Compare → |
| Allis Chalmers UC | 30.93 hp | 5,710 lb | — | Compare → |
| Allis Chalmers 5030 | 31 hp | 2,530 lb | 1979–1985 | Compare → |
| Allis Chalmers D12 | 31 hp | 2,800 lb | 1959–1968 | Compare → |
| Antonio Carraro Tigre 4000 | 31 hp | — | — | Compare → |
Explore
Kioti siblings
Explore
Similar-spec models
Gallery
Kioti LK3052 photos
FAQ
Common questions
How much horsepower does the Kioti LK3052 have?
The Kioti LK3052 produces 30.5 hp from its 3-cylinder engine. Engine displacement is 85.1 ci.
How much does the Kioti LK3052 weigh?
The Kioti LK3052 weighs about 2,866 lb in operating condition.
What transmission is in the Kioti LK3052?
Transmission on the Kioti LK3052 is Synchronized shuttle, with 8 forward speeds.
What hydraulics does the Kioti LK3052 have?
The Kioti LK3052 uses an Open center hydraulic system.
What maintenance does the Kioti LK3052 require?
Like any tractor, the Kioti LK3052 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
