SpecializedPerformance profile
Kubota BX23
The Kubota BX23 is a small but mighty tractor that can do many jobs. It was made from 2004 to 2005 and is great for both farm work and digging. This tractor has four-wheel drive, which means it can move well on rough ground. The BX23 has a Kubota D905-E-BX engine with three cylinders. It runs on diesel fuel and can produce 22 horsepower. The tractor has a hydrostatic transmission, which makes it easy to change speeds. It can go forward and backward with two gears each way. The BX23 has a three-point hitch that can lift up to 684 pounds. It also has a PTO (power take-off) that can run at 540 or 2500 rpm, which is useful for running different tools. The tractor is about 14 feet long, 3.75 feet wide, and 7 feet tall. It weighs about 2,699 pounds, which is light enough to not damage lawns but heavy enough to do serious work.
ManufacturerKubotaPower22 hpEngine3-cylTransHydrostatic
Quick specs
- Category
- Specialized
- Engine Power Output
- 22hp
- Operating Weight
- 2,698.5 lb
- Transmission
- Hydrostatic
At a glance
How the BX23 compares
vs. Specialized medianDistribution
Engine Power (hp)
Across all Specialized tractors
22 hp · 9th
This model
15
Median 62 hp
85
This modelSpecialized tractorsMediann = 55
The BX23 ranks at the 9th percentile for engine power among recorded specialized tractors.
Overview
About the Kubota BX23
The Kubota BX23 is a small but mighty tractor that can do many jobs. It was made from 2004 to 2005 and is great for both farm work and digging. This tractor has four-wheel drive, which means it can move well on rough ground. The BX23 has a Kubota D905-E-BX engine with three cylinders. It runs on diesel fuel and can produce 22 horsepower. The tractor has a hydrostatic transmission, which makes it easy to change speeds. It can go forward and backward with two gears each way. The BX23 has a three-point hitch that can lift up to 684 pounds. It also has a PTO (power take-off) that can run at 540 or 2500 rpm, which is useful for running different tools. The tractor is about 14 feet long, 3.75 feet wide, and 7 feet tall. It weighs about 2,699 pounds, which is light enough to not damage lawns but heavy enough to do serious work.
Full specifications
Every recorded spec
General
| Manufacturer | Kubota |
|---|---|
| Model | BX23 |
| Category | Specialized tractor |
| Type | 4×4 MFWD 4WD |
| Years built | 2004–2005 |
| Operating weight | 2,698.5lb |
Engine
| Make | Kubota |
|---|---|
| Model | D905-E-BX |
| Power | 22hp |
| Cylinders | 3 |
| Displacement | 54.8ci |
| Bore | 2.83in |
| Stroke | 2.9in |
Transmission
| Type | Hydrostatic |
|---|---|
| Forward gears | 2 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4×4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
| Brakes | Wet disk |
| Cab | Open operator station with ROPS |
Power take-off
| Rear PTO | Independent |
|---|---|
| PTO speed | 540rpm |
Dimensions
| Length | 167.7in |
|---|---|
| Width | 45.1in |
| Height | 85.8in |
| Operating weight | 2,698.5lb |
Capacities
| Cooling system | 0.93gal |
|---|
Head to head
BX23 vs. Specialized median
How the Kubota BX23 compares to other Specialized tractors
| Spec | This model | Specialized median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 22 hp | 62 hp | -65% | 9th |
| Engine Displacement | 54.8 ci | 239 ci | -77% | 5th |
| Cylinders | 3 | 4 | -25% | 18th |
| Forward Gears | 2 | 4 | -50% | 5th |
| Operating Weight | 2,699 lb | 12,600 lb | -79% | 21st |
| Length | 168 in | 274 in | -39% | 29th |
| Width | 45.1 in | 83.9 in | -46% | 12th |
| Height | 85.8 in | 108 in | -20% | 16th |
Medians and percentiles are computed from the specialized tractors in our database with a recorded value for each spec (sample sizes 43–58 models).
Compare to tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota BX22 | 22 hp | 1,521.2 lb | 2002–2003 | Compare → |
| Kubota B21 | 21 hp | 3,990 lb | 2001–2007 | Compare → |
| Kubota BX23S | 23 hp | 1,598.3 lb | 2017+ | Compare → |
| Kubota BX24 | 23 hp | 2,698 lb | 2006–2009 | Compare → |
| Kubota BX25 | 23 hp | 2,700 lb | 2009–2013 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D270 | 22 hp | 2,500 lb | — | Compare → |
| Belarus 200 | 22 hp | 2,600 lb | — | Compare → |
| Belarus 2011 | 22 hp | 2,602 lb | — | Compare → |
| Belarus 2045 | 22 hp | 2,712 lb | — | Compare → |
| Belarus 2145 | 22 hp | 2,700 lb | — | Compare → |
Explore
Kubota siblings
Explore
Similar-spec models
Gallery
Kubota BX23 photos
FAQ
Common questions
When was the Kubota BX23 in production?
Kubota BX23 production started in 2004 and ended in 2005.
How much horsepower does the Kubota BX23 have?
The Kubota BX23 produces 22 hp from its 3-cylinder engine. Engine displacement is 54.8 ci.
How much does the Kubota BX23 weigh?
The Kubota BX23 weighs about 2,698.5 lb in operating condition.
What transmission is in the Kubota BX23?
Transmission on the Kubota BX23 is Hydrostatic, with 2 forward speeds.
What three-point hitch category does the Kubota BX23 use?
The Kubota BX23 has a Category I three-point hitch rated to lift 684 lb.
What maintenance does the Kubota BX23 require?
Like any tractor, the Kubota BX23 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
