UtilityPerformance profile
Kubota KB23X
The Kubota KB23X is a small but mighty utility tractor, perfect for farmers who need a compact helper. This sub-compact tractor was made from 2009 to 2014. It has a 4-wheel drive system and power steering, making it easy to handle in tight spaces. Under the hood, the KB23X has a Kubota D1305 diesel engine with 3 cylinders. It's liquid-cooled and puts out 22.1 horsepower, which is on the lower end for tractors but good for its size. The engine runs at a high 2600 RPM, giving it plenty of pep. With 36 forward gears and 24 reverse gears, this tractor offers lots of speed choices for different jobs. It's small, measuring just 92.3 inches long, 44.5 inches wide, and 74.8 inches tall. At 1554 pounds, it's very light compared to most tractors, making it easy to move around the farm.
ManufacturerKubotaPower22.1 hpEngine3-cylTransPower shift, Glideshift
Quick specs
- Category
- Utility
- Engine Power Output
- 22hp
- Operating Weight
- 1,554 lb
- Transmission
- Power shift, Glideshift
At a glance
How the KB23X compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
22.1 hp · 12th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The KB23X ranks at the 12th percentile for engine power among recorded utility tractors.
Overview
About the Kubota KB23X
The Kubota KB23X is a small but mighty utility tractor, perfect for farmers who need a compact helper. This sub-compact tractor was made from 2009 to 2014. It has a 4-wheel drive system and power steering, making it easy to handle in tight spaces. Under the hood, the KB23X has a Kubota D1305 diesel engine with 3 cylinders. It's liquid-cooled and puts out 22.1 horsepower, which is on the lower end for tractors but good for its size. The engine runs at a high 2600 RPM, giving it plenty of pep. With 36 forward gears and 24 reverse gears, this tractor offers lots of speed choices for different jobs. It's small, measuring just 92.3 inches long, 44.5 inches wide, and 74.8 inches tall. At 1554 pounds, it's very light compared to most tractors, making it easy to move around the farm.
Full specifications
Every recorded spec
General
| Manufacturer | Kubota |
|---|---|
| Model | KB23X |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Years built | 2009–2014 |
| Operating weight | 1,554lb |
Engine
| Make | Kubota |
|---|---|
| Model | D1305 |
| Power | 22.1hp |
| Cylinders | 3 |
| Displacement | 77ci |
| Bore | 3.1in |
| Stroke | 3.5in |
Transmission
| Type | Power shift, Glideshift |
|---|---|
| Forward gears | 36 |
| Reverse gears | 24 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
Dimensions
| Length | 92.3in |
|---|---|
| Width | 44.5in |
| Height | 74.8in |
| Operating weight | 1,554lb |
Head to head
KB23X vs. Utility median
How the Kubota KB23X compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 22.1 hp | 55 hp | -60% | 12th |
| Engine Displacement | 77 ci | 183 ci | -58% | 11th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 36 | 12 | +200% | 99th |
| Operating Weight | 1,554 lb | 5,303 lb | -71% | 7th |
| Length | 92.3 in | 137 in | -32% | 5th |
| Width | 44.5 in | 66 in | -33% | 9th |
| Height | 74.8 in | 94.1 in | -21% | 20th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota KB225 | 22.1 hp | — | 2008–2009 | Compare → |
| Kubota B1702 | 22 hp | 1,422 lb | 1981–1985 | Compare → |
| Kubota B2301 | 22 hp | 1,566 lb | 2018+ | Compare → |
| Kubota B2301HSD | 22 hp | 1,565.3 lb | — | Compare → |
| Kubota BX2200 | 22 hp | 1,600 lb | 2001–2003 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D270 | 22 hp | 2,500 lb | — | Compare → |
| Belarus 200 | 22 hp | 2,600 lb | — | Compare → |
| Belarus 2011 | 22 hp | 2,602 lb | — | Compare → |
| Belarus 2045 | 22 hp | 2,712 lb | — | Compare → |
| Belarus 2145 | 22 hp | 2,700 lb | — | Compare → |
Explore
Kubota siblings
Explore
Similar-spec models
Gallery
Kubota KB23X photos
FAQ
Common questions
What years was the Kubota KB23X manufactured?
Production of the Kubota KB23X ran from 2009 through 2014.
What type of transmission does the Kubota KB23X have?
The Kubota KB23X uses a Power shift, Glideshift transmission offering 36 forward gears.
How powerful is the Kubota KB23X?
The Kubota KB23X has an engine power output of 22.1 hp. It is powered by a 3-cylinder engine displacing 77 ci.
What is the working weight of the Kubota KB23X?
The operating weight of the Kubota KB23X is approximately 1,554 lb.
What routine service does the Kubota KB23X need?
Regular maintenance for the Kubota KB23X includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
