Kubota L1-28
The Kubota L1-28 is a utility tractor made from 1983 to 1985. It's a 2WD tractor with a shuttle transmission that has 16 forward and 16 reverse gears. This tractor is powered by a Kubota V1512 engine, which is a 4-cylinder, liquid-cooled diesel engine. The engine is naturally aspirated and has a displacement of 91.5 ci, which is below average for tractors. It runs at 2700 rpm, which is very high, and produces 27.6 hp, which is below average power for tractors. The L1-28 is compact, measuring 124.4 inches long, 55.9 inches wide, and 77.8 inches tall. It weighs 2546 lb, which is lighter than most tractors. This tractor has agricultural tires on both front and rear wheels. It features a Type I rear hitch and an electric starter. The L1-28 is part of Kubota's L1 Series and has a wheelbase of 68.3 inches. It uses a dry disc clutch and operates on a 12-volt electrical system.
ManufacturerKubotaPower27.6 hpEngine4-cylTransShuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 28hp
- Operating Weight
- 2,546 lb
- Transmission
- Shuttle
At a glance
How the L1-28 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
27.6 hp · 19th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The L1-28 ranks at the 19th percentile for engine power among recorded utility tractors.
Overview
About the Kubota L1-28
The Kubota L1-28 is a utility tractor made from 1983 to 1985. It's a 2WD tractor with a shuttle transmission that has 16 forward and 16 reverse gears. This tractor is powered by a Kubota V1512 engine, which is a 4-cylinder, liquid-cooled diesel engine. The engine is naturally aspirated and has a displacement of 91.5 ci, which is below average for tractors. It runs at 2700 rpm, which is very high, and produces 27.6 hp, which is below average power for tractors. The L1-28 is compact, measuring 124.4 inches long, 55.9 inches wide, and 77.8 inches tall. It weighs 2546 lb, which is lighter than most tractors. This tractor has agricultural tires on both front and rear wheels. It features a Type I rear hitch and an electric starter. The L1-28 is part of Kubota's L1 Series and has a wheelbase of 68.3 inches. It uses a dry disc clutch and operates on a 12-volt electrical system.
Full specifications
Every recorded spec
General
| Manufacturer | Kubota |
|---|---|
| Model | L1-28 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Years built | 1983–1985 |
| Operating weight | 2,546lb |
Engine
| Make | Kubota |
|---|---|
| Model | V1512 |
| Power | 27.6hp |
| Cylinders | 4 |
| Displacement | 91.5ci |
Transmission
| Type | Shuttle |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 124.4in |
|---|---|
| Width | 55.9in |
| Height | 77.8in |
| Operating weight | 2,546lb |
Head to head
L1-28 vs. Utility median
How the Kubota L1-28 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 27.6 hp | 55 hp | -50% | 19th |
| Engine Displacement | 91.5 ci | 183 ci | -50% | 20th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 2,546 lb | 5,303 lb | -52% | 17th |
| Length | 124 in | 137 in | -9% | 34th |
| Width | 55.9 in | 66 in | -15% | 29th |
| Height | 77.8 in | 94.1 in | -17% | 24th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota FT28 | 27.6 hp | 2,116 lb | 2012–2015 | Compare → |
| Kubota GL280 | 27.6 hp | — | 1993–1995 | Compare → |
| Kubota KL28 Hi-Speed | 27.6 hp | 3,219 lb | — | Compare → |
| Kubota KL280 Hi-Speed | 27.6 hp | — | — | Compare → |
| Kubota KL285 | 27.6 hp | 3,285 lb | 2008–2009 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D272 | 27.5 hp | 2,060 lb | — | Compare → |
| Ascot Universal 300 | 27.5 hp | 3,800 lb | — | Compare → |
| Bobcat CT225 | 27 hp | 3,021 lb | 2008–2013 | Compare → |
| AGCO ST28A | 28.4 hp | 2,400 lb | — | Compare → |
| AGCO ST30x | 28.4 hp | 1,984 lb | — | Compare → |
Explore
Kubota siblings
Explore
Similar-spec models
Gallery
Kubota L1-28 photos
FAQ
Common questions
When was the Kubota L1-28 in production?
Kubota L1-28 production started in 1983 and ended in 1985.
How much horsepower does the Kubota L1-28 have?
The Kubota L1-28 produces 27.6 hp from its 4-cylinder engine. Engine displacement is 91.5 ci.
How much does the Kubota L1-28 weigh?
The Kubota L1-28 weighs about 2,546 lb in operating condition.
What transmission is in the Kubota L1-28?
Transmission on the Kubota L1-28 is Shuttle, with 16 forward speeds.
What maintenance does the Kubota L1-28 require?
Like any tractor, the Kubota L1-28 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
