UtilityPerformance profile
Kubota M4970
The Kubota M4970 is a utility tractor built for hard work on the farm. It has a strong 4-wheel drive system that helps it move well in tough conditions. The tractor is powered by a Kubota S2802 diesel engine with 6 cylinders. This engine gives the M4970 49.5 horsepower, which is about average for tractors in its class. The engine is cooled by liquid and breathes in air naturally without any extra help. This tractor has a manual transmission with 16 forward gears and 4 reverse gears. This gives the driver lots of choices for different jobs. The M4970 is a mid-sized tractor, measuring 143.5 inches long, 68.9 inches wide, and 95.3 inches tall. It weighs 5,379 pounds, which is also about average for similar tractors. The tractor has ag tires in the front and back, making it ready for farm work. It also has a Category 3 hitch, which lets it connect to many different tools. For safety, it has a ROPS (Roll-Over Protective Structure) to protect the driver.
ManufacturerKubotaPower49.5 hpEngine6-cylTransManual
Quick specs
- Category
- Utility
- Engine Power Output
- 50hp
- Operating Weight
- 5,379 lb
- Transmission
- Manual
At a glance
How the M4970 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
49.5 hp · 45th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The M4970 ranks at the 45th percentile for engine power among recorded utility tractors.
Overview
About the Kubota M4970
The Kubota M4970 is a utility tractor built for hard work on the farm. It has a strong 4-wheel drive system that helps it move well in tough conditions. The tractor is powered by a Kubota S2802 diesel engine with 6 cylinders. This engine gives the M4970 49.5 horsepower, which is about average for tractors in its class. The engine is cooled by liquid and breathes in air naturally without any extra help. This tractor has a manual transmission with 16 forward gears and 4 reverse gears. This gives the driver lots of choices for different jobs. The M4970 is a mid-sized tractor, measuring 143.5 inches long, 68.9 inches wide, and 95.3 inches tall. It weighs 5,379 pounds, which is also about average for similar tractors. The tractor has ag tires in the front and back, making it ready for farm work. It also has a Category 3 hitch, which lets it connect to many different tools. For safety, it has a ROPS (Roll-Over Protective Structure) to protect the driver.
Full specifications
Every recorded spec
General
| Manufacturer | Kubota |
|---|---|
| Model | M4970 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 5,379lb |
Engine
| Make | Kubota |
|---|---|
| Model | S2802 |
| Power | 49.5hp |
| Cylinders | 6 |
| Displacement | 170.3ci |
| Bore | 3.35in |
| Stroke | 3.23in |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 16 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Cab | ROPS |
Dimensions
| Length | 143.5in |
|---|---|
| Width | 68.9in |
| Height | 95.3in |
| Operating weight | 5,379lb |
Capacities
| Cooling system | 2.18gal |
|---|
Head to head
M4970 vs. Utility median
How the Kubota M4970 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 49.5 hp | 55 hp | -10% | 45th |
| Engine Displacement | 170 ci | 183 ci | -7% | 45th |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 5,379 lb | 5,303 lb | +1% | 50th |
| Length | 144 in | 137 in | +5% | 59th |
| Width | 68.9 in | 66 in | +4% | 57th |
| Height | 95.3 in | 94.1 in | +1% | 53rd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota KL50 Hi-Speed | 49.4 hp | — | — | Compare → |
| Kubota KL500 Hi-Speed | 49.4 hp | — | — | Compare → |
| Kubota KL505 Hi-Speed | 49.4 hp | 3,583 lb | — | Compare → |
| Kubota MZ50 | 49.3 hp | 5,225 lb | 2006–2009 | Compare → |
| Kubota MZ505 | 49.3 hp | 5,225 lb | 2010–2014 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5050 | 50 hp | 4,410 lb | 1977–1983 | Compare → |
| Allis Chalmers FD5 | 50 hp | 5,412 lb | — | Compare → |
| Belarus 4055 | 50 hp | 4,750 lb | — | Compare → |
| Antonio Carraro Tigrone 5800 | 48 hp | 3,417 lb | — | Compare → |
| Antonio Carraro Tigrone Jona 5800 | 48 hp | — | — | Compare → |
Explore
Kubota siblings
Explore
Similar-spec models
Gallery
Kubota M4970 photos
FAQ
Common questions
How powerful is the Kubota M4970?
The Kubota M4970 has an engine power output of 49.5 hp. It is powered by a 6-cylinder engine displacing 170.3 ci.
What three-point hitch category does the Kubota M4970 use?
The Kubota M4970 has a Category Category 3 three-point hitch.
What is the working weight of the Kubota M4970?
The operating weight of the Kubota M4970 is approximately 5,379 lb.
What type of transmission does the Kubota M4970 have?
The Kubota M4970 uses a Manual transmission offering 16 forward gears.
What routine service does the Kubota M4970 need?
Regular maintenance for the Kubota M4970 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
