Kubota M4970
Complete specifications and technical data for the Kubota M4970. Compare with similar tractors from Kubota and other manufacturers.
Quick Specs
Category
Engine Power Output
Operating Weight
Transmission
Strength vs Median
The Kubota M4970 is a utility tractor built for hard work on the farm. It has a strong 4-wheel drive system that helps it move well in tough conditions. The tractor is powered by a Kubota S2802 diesel...
Photo Gallery
Specifications
Engine Power Output Comparison of Kubota M4970 vs. Other Utility Tractors
Loading Chart...
Operating Weight Comparison of Kubota M4970 vs. Other Utility Tractors
Loading Chart...
Compare to Other Tractors
How the Kubota M4970 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 49.5 hp | 50.3 hp | at median | 49th |
| Engine Displacement | 170 ci | 175 ci | -3% | 50th |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 16 | 12 | +33% | 74th |
| Operating Weight | 5,379 lb | 4,850 lb | +11% | 54th |
| Length | 144 in | 134 in | +7% | 63rd |
| Width | 68.9 in | 65 in | +6% | 59th |
| Height | 95.3 in | 92.9 in | +3% | 56th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,570–4,952 models).
Compare to other tractors with similar specs
Commonly compared Kubota tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Kubota KL50 Hi-Speed | 49.4 hp | — | — | Compare → |
| Kubota KL500 Hi-Speed | 49.4 hp | — | — | Compare → |
| Kubota KL505 Hi-Speed | 49.4 hp | 3,583 lb | — | Compare → |
| Kubota MZ50 | 49.3 hp | 5,225 lb | 2006–2009 | Compare → |
| Kubota MZ505 | 49.3 hp | 5,225 lb | 2010–2014 | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5050 | 50 hp | 4,410 lb | 1977–1983 | Compare → |
| Allis Chalmers FD5 | 50 hp | 5,412 lb | — | Compare → |
| Belarus 4055 | 50 hp | 4,750 lb | — | Compare → |
| Antonio Carraro Tigrone 5800 | 48 hp | 3,417 lb | — | Compare → |
| Antonio Carraro Tigrone Jona 5800 | 48 hp | — | — | Compare → |
Frequently Asked Questions
What is the engine power output of the Kubota M4970?
The Kubota M4970 has an engine power output of 49.5 hp.
How many cylinders does the Kubota M4970 have?
The Kubota M4970 is equipped with a 6-cylinder engine.
What is the operating weight of the Kubota M4970?
The operating weight of the Kubota M4970 is approximately 5,379 lb.
What type of transmission does the Kubota M4970 have?
The Kubota M4970 is equipped with a Manual transmission.
What hitch category is the Kubota M4970?
The Kubota M4970 is a Category Category 3 hitch.
What maintenance does the Kubota M4970 require?
Regular maintenance for the Kubota M4970 includes checking and changing engine oil, hydraulic fluid, filters, and performing routine inspections as recommended in the owner's manual. Always refer to the manufacturer's maintenance schedule for specific intervals and procedures.
