UtilityPerformance profile
LS XR3032
The LS XR3032 is a compact utility tractor built for versatility and efficiency. It features a 4-wheel drive system and hydrostatic power steering, making it easy to maneuver in tight spaces. The tractor is powered by a Shibaura N843T-F engine, which is a 3-cylinder, turbocharged diesel engine with liquid cooling. This engine produces 32.2 hp at 2600 rpm, offering average power for its size class. The XR3032 comes with a 12-speed synchro shuttle transmission, providing 12 forward and 12 reverse gears. This gives operators plenty of options for different tasks. The tractor meets Tier 4 emissions standards, using exhaust-gas recirculation (EGR) to reduce harmful emissions. It has compact dimensions, measuring 121 inches long, 60 inches wide, and 90 inches tall, with an operating weight of 3220 lb. The tractor is equipped with a Category I rear hitch and features a ROPS (Roll-Over Protective Structure) for operator safety. Overall, the LS XR3032 is a well-rounded utility tractor suitable for small to medium-sized farms and properties.
ManufacturerLSPower32.2 hpEngine3-cylTrans12-speed synchro shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 32hp
- Operating Weight
- 3,220 lb
- Transmission
- 12-speed synchro shuttle
At a glance
How the XR3032 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
32.2 hp · 25th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The XR3032 ranks at the 25th percentile for engine power among recorded utility tractors.
Overview
About the LS XR3032
The LS XR3032 is a compact utility tractor built for versatility and efficiency. It features a 4-wheel drive system and hydrostatic power steering, making it easy to maneuver in tight spaces. The tractor is powered by a Shibaura N843T-F engine, which is a 3-cylinder, turbocharged diesel engine with liquid cooling. This engine produces 32.2 hp at 2600 rpm, offering average power for its size class. The XR3032 comes with a 12-speed synchro shuttle transmission, providing 12 forward and 12 reverse gears. This gives operators plenty of options for different tasks. The tractor meets Tier 4 emissions standards, using exhaust-gas recirculation (EGR) to reduce harmful emissions. It has compact dimensions, measuring 121 inches long, 60 inches wide, and 90 inches tall, with an operating weight of 3220 lb. The tractor is equipped with a Category I rear hitch and features a ROPS (Roll-Over Protective Structure) for operator safety. Overall, the LS XR3032 is a well-rounded utility tractor suitable for small to medium-sized farms and properties.
Full specifications
Every recorded spec
General
| Manufacturer | LS |
|---|---|
| Model | XR3032 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 3,220lb |
Engine
| Make | Shibaura |
|---|---|
| Model | N843T-F |
| Power | 32.2hp |
| Cylinders | 3 |
| Displacement | 91.3ci |
| Bore | 3.31in |
| Stroke | 3.54in |
Transmission
| Type | 12-speed synchro shuttle |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
| Cab | ROPS |
Dimensions
| Length | 121in |
|---|---|
| Width | 60in |
| Height | 90in |
| Operating weight | 3,220lb |
Head to head
XR3032 vs. Utility median
How the LS XR3032 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 32.2 hp | 55 hp | -41% | 25th |
| Engine Displacement | 91.3 ci | 183 ci | -50% | 17th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 3,220 lb | 5,303 lb | -39% | 26th |
| Length | 121 in | 137 in | -11% | 28th |
| Width | 60 in | 66 in | -9% | 37th |
| Height | 90 in | 94.1 in | -4% | 40th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared LS tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| LS XG3032 | 32.2 hp | 2,855 lb | — | Compare → |
| LS XR3032H | 32.2 hp | 3,220 lb | — | Compare → |
| LS Topa 32 | 32 hp | 2,857 lb | — | Compare → |
| LS LT330HST | 32.5 hp | 2,976 lb | — | Compare → |
| LS G3033 | 33 hp | 2,690 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST32 | 33 hp | 2,642 lb | — | Compare → |
| AGCO ST33A | 33 hp | 2,400 lb | — | Compare → |
| AGCO ST34A | 33 hp | 3,000 lb | — | Compare → |
| AGCO ST35 | 33 hp | 3,168 lb | — | Compare → |
| Allis Chalmers 5030 | 31 hp | 2,530 lb | 1979–1985 | Compare → |
Explore
LS siblings
Explore
Similar-spec models
Gallery
LS XR3032 photos
FAQ
Common questions
What is the engine power output of the LS XR3032?
Rated engine output for the LS XR3032 is 32.2 hp, delivered by a 3-cylinder engine. The engine displaces 91.3 ci.
What is the operating weight of the LS XR3032?
In working trim, the LS XR3032 comes in at roughly 3,220 lb.
Which transmission does the LS XR3032 use?
The LS XR3032 is equipped with a 12-speed synchro shuttle transmission with 12 forward gears.
How do I maintain a LS XR3032?
Routine service for the LS XR3032 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
