Utility tractorsSpec sheet
LS XU6158
The LS XU6158 is a versatile utility tractor designed for various farm tasks. It features a powerful 4-cylinder diesel engine that produces 58 horsepower, which is above average for its class. The engine is turbocharged and liquid-cooled, providing reliable performance in different conditions. With a 16-forward and 16-reverse synchronized shuttle transmission, this tractor offers smooth operation and easy gear changes. Built on a 4x4 MFWD chassis, the XU6158 provides excellent traction and stability. It has power steering for easy maneuverability and a Category II rear hitch for attaching various implements. The tractor's open center hydraulic system ensures efficient operation of attachments. Weighing 4,674 pounds and measuring 138.6 inches long, this LS tractor is compact yet capable. It meets Tier IV emissions standards, making it environmentally friendly. The XU6158 is a solid choice for farmers looking for a dependable and versatile utility tractor.
ManufacturerLSPower58 hp(43.3 kW)Class40–60 HP tractors →Engine4-cylinderTransmissionSynchronized shuttle
Key specifications
- Category
- Utility
- Engine power
- 58hp
- Operating weight
- 4,674 lb
- Transmission
- Synchronized shuttle
Category comparison
XU6158 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
58 hp · 52nd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The XU6158 ranks at the 52nd percentile for engine power among recorded utility tractors.
Overview
About the LS XU6158
The LS XU6158 is a versatile utility tractor designed for various farm tasks. It features a powerful 4-cylinder diesel engine that produces 58 horsepower, which is above average for its class. The engine is turbocharged and liquid-cooled, providing reliable performance in different conditions. With a 16-forward and 16-reverse synchronized shuttle transmission, this tractor offers smooth operation and easy gear changes. Built on a 4x4 MFWD chassis, the XU6158 provides excellent traction and stability. It has power steering for easy maneuverability and a Category II rear hitch for attaching various implements. The tractor's open center hydraulic system ensures efficient operation of attachments. Weighing 4,674 pounds and measuring 138.6 inches long, this LS tractor is compact yet capable. It meets Tier IV emissions standards, making it environmentally friendly. The XU6158 is a solid choice for farmers looking for a dependable and versatile utility tractor.
Full specifications
Recorded specifications
General
| Manufacturer | LS |
|---|---|
| Model | XU6158 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 4,674lb(2,120 kg) |
Engine
| Make | LS |
|---|---|
| Model | L4C25-T |
| Power | 58hp(43.25 kW) |
| Cylinders | 4 |
| Displacement | 152.8ci(2.5 L) |
| Bore | 3.46in(87.88 mm) |
| Stroke | 4.06in(103.1 mm) |
Transmission
| Type | Synchronized shuttle |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 138.6in(3,520 mm) |
|---|---|
| Width | 70in(1,778 mm) |
| Operating weight | 4,674lb(2,120 kg) |
Closest alternatives
XU6158 compared with the nearest models by horsepower
By engine horsepower, the nearest utility models to the XU6158 are the LS MT458 and the Kubota M5660SU. The LS MT458 matches it on rated power. The Kubota M5660SU matches it on rated power.
| Spec | LS XU6158 | LS MT458 | Kubota M5660SU |
|---|---|---|---|
| Engine power | 58 hp43.3 kW | 58 hp43.3 kW | 58 hp43.3 kW |
| Displacement | 152.8 ci2.5 L | 152.8 ci2.5 L | 148.5 ci2.43 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Synchronized shuttle | Mechanical shuttle | Shuttle |
| Drive | 4WD | 4WD | 4WD |
Calculators
Calculators for the XU6158
PTO power
About 48 to 52 PTO hp
Estimated from the 58 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 58 hp tractor can run
Maximum size is about a 7 ft rotary cutter or a 6 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
94 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
58 hp is 43.3 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
XU6158 vs. Utility median
LS XU6158 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 58 hp | 55 hp | +5% | 52nd |
| Engine Displacement | 153 ci | 183 ci | -17% | 40th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 4,674 lb | 5,303 lb | -12% | 45th |
| Length | 139 in | 137 in | +1% | 53rd |
| Width | 70 in | 66 in | +6% | 61st |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other LS models
Other manufacturers
Models with similar horsepower
Gallery
LS XU6158 photos
FAQ
Frequently asked questions
What is the engine power output of the LS XU6158?
Rated engine output for the LS XU6158 is 58 hp, delivered by a 4-cylinder engine. The engine displaces 152.8 ci.
Which transmission does the LS XU6158 use?
The LS XU6158 is equipped with a Synchronized shuttle transmission with 16 forward gears.
What type of hydraulic system does the LS XU6158 use?
Hydraulics on the LS XU6158 are Open center.
What is the operating weight of the LS XU6158?
The LS XU6158 has an operating weight of about 4,674 lb.
How do I maintain a LS XU6158?
Routine service for the LS XU6158 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
