Utility
McCormick-Deering AW-7
The McCormick-Deering AW-7 is a utility tractor with a standard tread design. It's a 2-wheel drive machine with power steering, making it easy to handle. The tractor has a gear transmission with 5 forward gears and 1 reverse gear, giving drivers good control over speed and power. Under the hood, the AW-7 has a 4-cylinder diesel engine made by International Harvester. The engine is quite large for its class, with a displacement of 264 cubic inches. It runs at 1450 RPM, which is lower than most tractors but helps save fuel. The tractor is heavy, weighing 8,540 pounds, which is above average for its size. This weight helps it grip the ground well when working in fields. The AW-7 has agricultural tires on both front and rear wheels. It's 125 inches long and 78.75 inches wide, making it a good size for many farm tasks. The tractor has a category II hitch, which lets it use many different tools. It also has an electric starter, making it easy to get going in the morning. Overall, the McCormick-Deering AW-7 is a sturdy, powerful tractor built for everyday farm work.
ManufacturerMcCormick-DeeringEngine4-cylTransGear
Quick specs
- Category
- Utility
- Operating Weight
- 8,540 lb
- Transmission
- Gear
Overview
About the McCormick-Deering AW-7
The McCormick-Deering AW-7 is a utility tractor with a standard tread design. It's a 2-wheel drive machine with power steering, making it easy to handle. The tractor has a gear transmission with 5 forward gears and 1 reverse gear, giving drivers good control over speed and power. Under the hood, the AW-7 has a 4-cylinder diesel engine made by International Harvester. The engine is quite large for its class, with a displacement of 264 cubic inches. It runs at 1450 RPM, which is lower than most tractors but helps save fuel. The tractor is heavy, weighing 8,540 pounds, which is above average for its size. This weight helps it grip the ground well when working in fields. The AW-7 has agricultural tires on both front and rear wheels. It's 125 inches long and 78.75 inches wide, making it a good size for many farm tasks. The tractor has a category II hitch, which lets it use many different tools. It also has an electric starter, making it easy to get going in the morning. Overall, the McCormick-Deering AW-7 is a sturdy, powerful tractor built for everyday farm work.
Full specifications
Every recorded spec
General
| Manufacturer | McCormick-Deering |
|---|---|
| Model | AW-7 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 8,540lb |
Engine
| Make | International Harvester |
|---|---|
| Model | 4.3L 4-cyl |
| Cylinders | 4 |
| Displacement | 264ci |
| Bore | 4in |
| Stroke | 5.25in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 5 |
| Reverse gears | 1 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
Dimensions
| Length | 125in |
|---|---|
| Width | 78.75in |
| Operating weight | 8,540lb |
Head to head
AW-7 vs. Utility median
How the McCormick-Deering AW-7 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 264 ci | 183 ci | +44% | 74th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 5 | 12 | -58% | 6th |
| Operating Weight | 8,540 lb | 5,303 lb | +61% | 79th |
| Length | 125 in | 137 in | -8% | 34th |
| Width | 78.8 in | 66 in | +19% | 79th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared McCormick-Deering tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| McCormick-Deering 15-30 | 40.66 hp | 7,480 lb | — | Compare → |
| McCormick-Deering 22-36 | — | 6,500 lb | — | Compare → |
| McCormick-Deering 45219 | — | 3,700 lb | — | Compare → |
| McCormick-Deering 45585 | 20 hp | 3,700 lb | 1923–1939 | Compare → |
| McCormick-Deering A554 | 57 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Advance-Rumely 6A | — | 6,370 lb | — | Compare → |
| Advance-Rumely DoAll | — | 3,702 lb | — | Compare → |
| Advance-Rumely OilPull B 25/45 | — | 25,000 lb | — | Compare → |
| Advance-Rumely OilPull E 30/60 | — | 26,300 lb | — | Compare → |
| Advance-Rumely OilPull F 15/30 | — | 16,500 lb | — | Compare → |
Explore
McCormick-Deering siblings
Explore
Similar-spec models
Gallery
McCormick-Deering AW-7 photos
FAQ
Common questions
What engine configuration does the McCormick-Deering AW-7 use?
The McCormick-Deering AW-7 is equipped with a 4-cylinder engine displacing 264 ci.
Which transmission does the McCormick-Deering AW-7 use?
The McCormick-Deering AW-7 is equipped with a Gear transmission with 5 forward gears.
What three-point hitch category does the McCormick-Deering AW-7 use?
The McCormick-Deering AW-7 has a Category II three-point hitch.
What is the operating weight of the McCormick-Deering AW-7?
In working trim, the McCormick-Deering AW-7 comes in at roughly 8,540 lb.
How do I maintain a McCormick-Deering AW-7?
Routine service for the McCormick-Deering AW-7 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
