Row CropPerformance profile
McCormick Intl MTX165
The McCormick Intl MTX165 is a powerful row crop tractor built for serious farming. It has a strong 4-wheel drive system and a smooth powershift transmission with 32 forward gears and 24 reverse gears. This gives farmers lots of options for different tasks. Under the hood, the MTX165 has a 6-cylinder Iveco diesel engine that's turbocharged for extra power. The engine puts out 160 horsepower, which is above average for tractors. It has a liquid cooling system to keep it running smoothly. The tractor weighs 16,185 pounds, making it sturdy enough for tough jobs. It also has a three-point hitch at the back for attaching farm tools. This tractor is designed for comfort and ease of use. It has hydrostatic power steering, which makes it easy to turn. The hydraulic system is pressure flow compensating, which helps control attached equipment better. With its mix of power and features, the McCormick Intl MTX165 is a solid choice for farmers who need a reliable tractor for their fields.
ManufacturerMcCormick IntlPower160 hpEngine6-cylTransPowershift
Quick specs
- Category
- Row Crop
- Engine Power Output
- 160hp
- Operating Weight
- 16,185 lb
- Transmission
- Powershift
At a glance
How the MTX165 compares
vs. Row Crop medianDistribution
Engine Power (hp)
Across all Row Crop tractors
160 hp · 62nd
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The MTX165 ranks at the 62nd percentile for engine power among recorded row crop tractors.
Overview
About the McCormick Intl MTX165
The McCormick Intl MTX165 is a powerful row crop tractor built for serious farming. It has a strong 4-wheel drive system and a smooth powershift transmission with 32 forward gears and 24 reverse gears. This gives farmers lots of options for different tasks. Under the hood, the MTX165 has a 6-cylinder Iveco diesel engine that's turbocharged for extra power. The engine puts out 160 horsepower, which is above average for tractors. It has a liquid cooling system to keep it running smoothly. The tractor weighs 16,185 pounds, making it sturdy enough for tough jobs. It also has a three-point hitch at the back for attaching farm tools. This tractor is designed for comfort and ease of use. It has hydrostatic power steering, which makes it easy to turn. The hydraulic system is pressure flow compensating, which helps control attached equipment better. With its mix of power and features, the McCormick Intl MTX165 is a solid choice for farmers who need a reliable tractor for their fields.
Full specifications
Every recorded spec
General
| Manufacturer | McCormick Intl |
|---|---|
| Model | MTX165 |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 16,185lb |
Engine
| Make | Iveco |
|---|---|
| Power | 160hp |
| Cylinders | 6 |
| Displacement | 411.88ci |
| Bore | 4.09in |
| Stroke | 5.2in |
Transmission
| Type | Powershift |
|---|---|
| Forward gears | 32 |
| Reverse gears | 24 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic power |
Hydraulics
| Type | Pressure flow compensating |
|---|
Dimensions
| Length | 205.91in |
|---|---|
| Operating weight | 16,185lb |
Head to head
MTX165 vs. Row Crop median
How the McCormick Intl MTX165 compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 160 hp | 138 hp | +16% | 62nd |
| Engine Displacement | 412 ci | 391 ci | +5% | 64th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 32 | 16 | +100% | 91st |
| Operating Weight | 16,185 lb | 12,307 lb | +32% | 70th |
| Length | 206 in | 180 in | +15% | 81st |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 1,157–1,417 models).
Compare to tractors with similar specs
Commonly compared McCormick Intl tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| McCormick Intl MTX155 | 160 hp | 14,440 lb | — | Compare → |
| McCormick Intl X7.460 | 160 hp | 12,680 lb | — | Compare → |
| McCormick Intl XTX185 | 162 hp | 17,739 lb | — | Compare → |
| McCormick Intl G165 Max | 157 hp | 13,750 lb | — | Compare → |
| McCormick Intl X70.50 | 165 hp | 14,330 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO DT160 | 160 hp | 18,500 lb | 2002–2004 | Compare → |
| Agrinar T-160 | 161 hp | 13,450 lb | — | Compare → |
| AGCO RT155A | 162.5 hp | — | — | Compare → |
| Allis Chalmers HD16A | 163 hp | 31,500 lb | — | Compare → |
| Allis Chalmers 7050 | 156.49 hp | 19,530 lb | 1973–1974 | Compare → |
Explore
McCormick Intl siblings
Explore
Similar-spec models
Gallery
McCormick Intl MTX165 photos
FAQ
Common questions
What is the engine power output of the McCormick Intl MTX165?
Rated engine output for the McCormick Intl MTX165 is 160 hp, delivered by a 6-cylinder engine. The engine displaces 411.88 ci.
What hydraulics does the McCormick Intl MTX165 have?
The McCormick Intl MTX165 uses a Pressure flow compensating hydraulic system.
What three-point hitch category does the McCormick Intl MTX165 use?
The McCormick Intl MTX165 has a Category III three-point hitch.
What is the operating weight of the McCormick Intl MTX165?
In working trim, the McCormick Intl MTX165 comes in at roughly 16,185 lb.
Which transmission does the McCormick Intl MTX165 use?
The McCormick Intl MTX165 is equipped with a Powershift transmission with 32 forward gears.
How do I maintain a McCormick Intl MTX165?
Routine service for the McCormick Intl MTX165 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
