SAME Atlanta 45
The SAME Atlanta 45 is a utility tractor built for everyday farm work. It has a 2WD drive system and a gear transmission with 6 forward gears and 2 reverse gears. This tractor is powered by a SAME DA 954/V engine, which is air-cooled and has 4 cylinders in a V-shape. The engine runs on diesel fuel and is naturally aspirated. The Atlanta 45's engine has an above-average displacement of 207.5 ci, with a bore of 3.74 in and a stroke of 4.72 in. It produces 44 hp at 1700 rpm, which is about average for its class. The tractor weighs 3814 lb and has compact dimensions, measuring 109.8 in long, 63 in wide, and 57.5 in tall. It features agricultural tires on both front and rear wheels and comes with an electric starter for easy operation.
Key specifications
- Category
- Utility
- Engine power
- 44hp
- Operating weight
- 3,814 lb
- Transmission
- Gear
Category comparison
Atlanta 45 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
44 hp · 38th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Atlanta 45 ranks at the 38th percentile for engine power among recorded utility tractors.
Overview
About the SAME Atlanta 45
The SAME Atlanta 45 is a utility tractor built for everyday farm work. It has a 2WD drive system and a gear transmission with 6 forward gears and 2 reverse gears. This tractor is powered by a SAME DA 954/V engine, which is air-cooled and has 4 cylinders in a V-shape. The engine runs on diesel fuel and is naturally aspirated. The Atlanta 45's engine has an above-average displacement of 207.5 ci, with a bore of 3.74 in and a stroke of 4.72 in. It produces 44 hp at 1700 rpm, which is about average for its class. The tractor weighs 3814 lb and has compact dimensions, measuring 109.8 in long, 63 in wide, and 57.5 in tall. It features agricultural tires on both front and rear wheels and comes with an electric starter for easy operation.
Full specifications
Recorded specifications
General
| Manufacturer | SAME |
|---|---|
| Model | Atlanta 45 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 3,814lb(1,730 kg) |
Engine
| Make | SAME |
|---|---|
| Model | DA 954/V |
| Power | 44hp(32.81 kW) |
| Cylinders | 4 |
| Displacement | 207.5ci(3.4 L) |
| Bore | 3.74in(95 mm) |
| Stroke | 4.72in(119.9 mm) |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 6 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 109.8in(2,789 mm) |
|---|---|
| Width | 63in(1,600 mm) |
| Height | 57.5in(1,461 mm) |
| Operating weight | 3,814lb(1,730 kg) |
Closest alternatives
Atlanta 45 compared with the nearest models by horsepower
The closest utility models to the SAME Atlanta 45 by rated horsepower are the Kubota L4240 and the John Deere 3720. The Kubota L4240 matches it on rated power and weighs 140 lb less. The John Deere 3720 matches it on rated power and weighs 910 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. Of the 3 models, the Atlanta 45 has the highest weight per horsepower at 87 lb per hp.
| Spec | SAME Atlanta 45 | Kubota L4240 | John Deere 3720 |
|---|---|---|---|
| Engine power | 44 hp32.8 kW | 44 hp32.8 kW | 44 hp32.8 kW |
| Operating weight | 3,814 lb1,730 kg | 3,671 lb1,665 kg | 2,900 lb1,315 kg |
| Weight per hp | 87 lb/hp53 kg/kW | 83 lb/hp51 kg/kW | 66 lb/hp40 kg/kW |
| Displacement | 207.5 ci3.4 L | 134.1 ci2.2 L | 91.5 ci1.5 L |
| Cylinders | 4 | 4 | 3 |
| Transmission | Gear | Hydrostatic | Hydrostatic |
| Drive | 2WD | Four-wheel drive (4WD) | 4WD |
| Years built | - | 2007-2013 | 2005-2013 |
Calculators
Calculators for the Atlanta 45
PTO power
About 37 to 40 PTO hp
Estimated from the 44 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 44 hp tractor can run
Maximum size is about a 5 ft rotary cutter or a 4.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
101 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
44 hp is 32.8 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the SAME Atlanta 45
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the SAME DA 954/VAmazon
Fits the SAME DA 954/V 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the SAME DA 954/VAmazon
Fits the SAME DA 954/V 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the SAME DA 954/VAmazon
Fits the SAME DA 954/V 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the SAME DA 954/VAmazon
Fits the SAME DA 954/V 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- SAME Atlanta 45 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- SAME Atlanta 45 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- SAME Atlanta 45 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Atlanta 45 vs. Utility median
SAME Atlanta 45 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 44 hp | 55 hp | -20% | 38th |
| Engine Displacement | 208 ci | 183 ci | +13% | 58th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 6 | 12 | -50% | 11th |
| Operating Weight | 3,814 lb | 5,303 lb | -28% | 34th |
| Length | 110 in | 137 in | -20% | 16th |
| Width | 63 in | 66 in | -5% | 43rd |
| Height | 57.5 in | 94.1 in | -39% | 8th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other SAME models
Other manufacturers
Models with similar horsepower
Gallery
SAME Atlanta 45 photos
FAQ
Frequently asked questions
What is the engine power output of the SAME Atlanta 45?
Rated engine output for the SAME Atlanta 45 is 44 hp, delivered by a 4-cylinder engine. The engine displaces 207.5 ci.
What is the operating weight of the SAME Atlanta 45?
The SAME Atlanta 45 has an operating weight of about 3,814 lb.
Which transmission does the SAME Atlanta 45 use?
The SAME Atlanta 45 is equipped with a Gear transmission with 6 forward gears.
How do I maintain a SAME Atlanta 45?
Routine service for the SAME Atlanta 45 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
