SAME Krypton F 80
The SAME Krypton F 80 is a versatile tractor designed for various farming tasks. It features a powerful 4-cylinder diesel engine made by SAME. This engine has a displacement of 244.1 cubic inches and produces 69.1 horsepower at 2200 RPM. The liquid-cooled engine ensures reliable performance in different weather conditions. One of the Krypton F 80's standout features is its transmission system. It offers 32 total gears, with 16 forward and 16 reverse options. This includes a shuttle and creeper gear, giving farmers excellent control and flexibility in the field. The tractor's size is compact yet capable, measuring 129.9 inches long and 56.3 inches tall. With an operating weight of 8820 pounds, it's sturdy enough for tough jobs. The Krypton F 80 also comes with a Category 3 hitch, making it compatible with a wide range of farming implements.

Key specifications
- Category
- Agricultural
- Engine power
- 69hp
- Operating weight
- 8,820 lb
- Transmission
- shuttle, creeper
Category comparison
Krypton F 80 compared with its category
vs. Agricultural medianDistribution
Engine Power (hp)
All recorded Agricultural tractors
This model
The Krypton F 80 ranks at the 19th percentile for engine power among recorded agricultural tractors.
Overview
About the SAME Krypton F 80
The SAME Krypton F 80 is a versatile tractor designed for various farming tasks. It features a powerful 4-cylinder diesel engine made by SAME. This engine has a displacement of 244.1 cubic inches and produces 69.1 horsepower at 2200 RPM. The liquid-cooled engine ensures reliable performance in different weather conditions. One of the Krypton F 80's standout features is its transmission system. It offers 32 total gears, with 16 forward and 16 reverse options. This includes a shuttle and creeper gear, giving farmers excellent control and flexibility in the field. The tractor's size is compact yet capable, measuring 129.9 inches long and 56.3 inches tall. With an operating weight of 8820 pounds, it's sturdy enough for tough jobs. The Krypton F 80 also comes with a Category 3 hitch, making it compatible with a wide range of farming implements.
Full specifications
Recorded specifications
General
| Manufacturer | SAME |
|---|---|
| Model | Krypton F 80 |
| Category | Agricultural tractor |
| Operating weight | 8,820lb(4,001 kg) |
Engine
| Make | SAME |
|---|---|
| Model | 1000.4 W |
| Power | 69.1hp(51.53 kW) |
| Cylinders | 4 |
| Displacement | 244.1ci(4 L) |
| Bore | 4.13in(104.9 mm) |
| Stroke | 4.55in(115.6 mm) |
Transmission
| Type | shuttle, creeper |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Dimensions
| Length | 129.9in(3,299 mm) |
|---|---|
| Height | 56.3in(1,430 mm) |
| Operating weight | 8,820lb(4,001 kg) |
Closest alternatives
Krypton F 80 compared with the nearest models by horsepower
Among agricultural tractors, the Fiat 70-75 and the Fiat 70-76 are closest to the SAME Krypton F 80 in rated horsepower. The Fiat 70-75 matches it on rated power and weighs 990 lb less, carrying 113 lb per horsepower against 128 lb. The Fiat 70-76 matches it on rated power and weighs 4,040 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. Of the 3 models, the Krypton F 80 has the highest weight per horsepower at 128 lb per hp.
| Spec | SAME Krypton F 80 | Fiat 70-75 | Fiat 70-76 |
|---|---|---|---|
| Engine power | 69.1 hp51.5 kW | 69.1 hp51.5 kW | 69.1 hp51.5 kW |
| Operating weight | 8,820 lb4,001 kg | 7,826 lb3,550 kg | 4,782 lb2,169 kg |
| Weight per hp | 128 lb/hp78 kg/kW | 113 lb/hp69 kg/kW | 69 lb/hp42 kg/kW |
| Displacement | 244.1 ci4 L | 220.5 ci3.61 L | 220.5 ci3.61 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | shuttle, creeper | - | Partially synchronized |
Calculators
Calculators for the Krypton F 80
PTO power
About 57 to 62 PTO hp
Estimated from the 69.1 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 69.1 hp tractor can run
Maximum size is about a 8 ft rotary cutter or a 7 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
148 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
69.1 hp is 51.5 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the SAME Krypton F 80
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the SAME 1000.4 WAmazon
Fits the SAME 1000.4 W 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the SAME 1000.4 WAmazon
Fits the SAME 1000.4 W 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the SAME 1000.4 WAmazon
Fits the SAME 1000.4 W 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the SAME 1000.4 WAmazon
Fits the SAME 1000.4 W 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- SAME Krypton F 80 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- SAME Krypton F 80 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- SAME Krypton F 80 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Krypton F 80 vs. Agricultural median
SAME Krypton F 80 compared with other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 69.1 hp | 110 hp | -37% | 19th |
| Engine Displacement | 244 ci | 336 ci | -27% | 28th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 8,820 lb | 10,914 lb | -19% | 38th |
| Length | 130 in | 173 in | -25% | 12th |
| Height | 56.3 in | 111 in | -49% | 6th |
Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 795–1,130 models).
Same manufacturer
Other SAME models
Other manufacturers
Models with similar horsepower
Gallery
SAME Krypton F 80 photos




FAQ
Frequently asked questions
What is the engine power output of the SAME Krypton F 80?
Rated engine output for the SAME Krypton F 80 is 69.1 hp, delivered by a 4-cylinder engine. The engine displaces 244.1 ci.
Which transmission does the SAME Krypton F 80 use?
The SAME Krypton F 80 is equipped with a shuttle, creeper transmission with 16 forward gears.
What three-point hitch category does the SAME Krypton F 80 use?
The SAME Krypton F 80 has a Category Category 3 three-point hitch.
What is the operating weight of the SAME Krypton F 80?
The SAME Krypton F 80 has an operating weight of about 8,820 lb.
How do I maintain a SAME Krypton F 80?
Routine service for the SAME Krypton F 80 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
