Same brandSAME Vigneron 75
The SAME Vigneron 75 is a specialized tractor designed for orchards and vineyards. It's a compact machine with a 4-wheel drive system, making it great for working in tight spaces between rows of trees or vines. The tractor is powered by a SAME 1000.4A diesel engine with 4 cylinders and 75 horsepower, which is about average for its class. This air-cooled engine is naturally aspirated and runs at 2500 rpm, which is above average for tractor engines. At 132.3 inches long, 46.5 inches wide, and 51.5 inches high (at the hood), the Vigneron 75 is built to maneuver easily in orchards. It weighs 4,520 pounds, which is on the lighter side for tractors. The tractor features a partially synchronized transmission with 12 forward and 12 reverse gears, giving operators plenty of options for different tasks. It also has power steering and a three-point hitch at the rear for attaching various implements. With its agricultural tires and electric starter, this SAME tractor is ready to tackle a variety of orchard and vineyard jobs efficiently.

Key specifications
- Category
- Agricultural
- Engine power
- 75hp
- Operating weight
- 4,520 lb
- Transmission
- Partially synchronized
Category comparison
Vigneron 75 compared with its category
vs. Agricultural medianDistribution
Engine Power (hp)
All recorded Agricultural tractors
This model
The Vigneron 75 ranks at the 23rd percentile for engine power among recorded agricultural tractors.
Overview
About the SAME Vigneron 75
The SAME Vigneron 75 is a specialized tractor designed for orchards and vineyards. It's a compact machine with a 4-wheel drive system, making it great for working in tight spaces between rows of trees or vines. The tractor is powered by a SAME 1000.4A diesel engine with 4 cylinders and 75 horsepower, which is about average for its class. This air-cooled engine is naturally aspirated and runs at 2500 rpm, which is above average for tractor engines. At 132.3 inches long, 46.5 inches wide, and 51.5 inches high (at the hood), the Vigneron 75 is built to maneuver easily in orchards. It weighs 4,520 pounds, which is on the lighter side for tractors. The tractor features a partially synchronized transmission with 12 forward and 12 reverse gears, giving operators plenty of options for different tasks. It also has power steering and a three-point hitch at the rear for attaching various implements. With its agricultural tires and electric starter, this SAME tractor is ready to tackle a variety of orchard and vineyard jobs efficiently.
Full specifications
Recorded specifications
General
| Manufacturer | SAME |
|---|---|
| Model | Vigneron 75 |
| Category | Agricultural tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 4,520lb(2,050 kg) |
Engine
| Make | SAME |
|---|---|
| Model | 1000.4A |
| Power | 75hp(55.93 kW) |
| Cylinders | 4 |
| Displacement | 244ci(4 L) |
| Bore | 4.13in(104.9 mm) |
| Stroke | 4.54in(115.3 mm) |
Transmission
| Type | Partially synchronized |
|---|---|
| Forward gears | 12 |
| Reverse gears | 12 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
Dimensions
| Length | 132.3in(3,360 mm) |
|---|---|
| Width | 46.5in(1,181 mm) |
| Height | 51.5in(1,308 mm) |
| Operating weight | 4,520lb(2,050 kg) |
Closest alternatives
Vigneron 75 compared with the nearest models by horsepower
Among agricultural tractors, the SAME Centurion 75 and the Massey Ferguson 3707F are closest to the SAME Vigneron 75 in rated horsepower. The SAME Centurion 75 matches it on rated power and weighs 2,670 lb more, at 96 lb per horsepower against 60 lb. The Massey Ferguson 3707F matches it on rated power.
| Spec | SAME Vigneron 75 | SAME Centurion 75 | Massey Ferguson 3707F |
|---|---|---|---|
| Engine power | 75 hp55.9 kW | 75 hp55.9 kW | 75 hp55.9 kW |
| Operating weight | 4,520 lb2,050 kg | 7,188 lb3,260 kg | - |
| Weight per hp | 60 lb/hp37 kg/kW | 96 lb/hp58 kg/kW | - |
| Displacement | 244 ci4 L | 253.5 ci4.15 L | 207.5 ci3.4 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Partially synchronized | Manual | - |
| Drive | 4WD | 2WD | 4WD |
Calculators
Calculators for the Vigneron 75
PTO power
About 62 to 68 PTO hp
Estimated from the 75 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 75 hp tractor can run
Maximum size is about a 9 ft rotary cutter or a 7.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
70 lb per PTO hp as listed
Heavy draft work calls for 120 to 135 lb/hp. The calculator gives the ballast to add.
Units
75 hp is 55.9 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the SAME Vigneron 75
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the SAME 1000.4AAmazon
Fits the SAME 1000.4A 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the SAME 1000.4AAmazon
Fits the SAME 1000.4A 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the SAME 1000.4AAmazon
Fits the SAME 1000.4A 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the SAME 1000.4AAmazon
Fits the SAME 1000.4A 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- SAME Vigneron 75 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- SAME Vigneron 75 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- SAME Vigneron 75 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Vigneron 75 vs. Agricultural median
SAME Vigneron 75 compared with other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 75 hp | 110 hp | -32% | 23rd |
| Engine Displacement | 244 ci | 336 ci | -27% | 26th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 12 | 16 | -25% | 33rd |
| Operating Weight | 4,520 lb | 10,914 lb | -59% | 9th |
| Length | 132 in | 173 in | -23% | 14th |
| Width | 46.5 in | 79.5 in | -42% | 7th |
| Height | 51.5 in | 111 in | -53% | 4th |
Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 497–1,130 models).
Same manufacturer
Other SAME models
Other manufacturers
Models with similar horsepower
Gallery
SAME Vigneron 75 photos






FAQ
Frequently asked questions
What is the engine power output of the SAME Vigneron 75?
Rated engine output for the SAME Vigneron 75 is 75 hp, delivered by a 4-cylinder engine. The engine displaces 244 ci.
What is the operating weight of the SAME Vigneron 75?
The SAME Vigneron 75 has an operating weight of about 4,520 lb.
Which transmission does the SAME Vigneron 75 use?
The SAME Vigneron 75 is equipped with a Partially synchronized transmission with 12 forward gears.
How do I maintain a SAME Vigneron 75?
Routine service for the SAME Vigneron 75 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
