Brand siblingSub-CompactPerformance profile
Satoh ST1100
The Satoh ST1100 is a compact tractor designed for various farm tasks. It features a Mitsubishi KE55 engine, which is a liquid-cooled diesel engine with two cylinders. This engine is naturally aspirated, meaning it doesn't use a turbocharger. It has a displacement of 33.2 cubic inches and produces 11 horsepower, making it suitable for light to medium-duty work. The tractor comes with a gear transmission that offers 6 forward speeds and 2 reverse speeds. This range of gears allows the operator to choose the right speed for different jobs. The ST1100 is equipped with a Category 3 hitch, which is typically found on larger tractors. This hitch type allows the tractor to work with a wide range of implements and attachments. Overall, the Satoh ST1100 is a versatile machine that can handle various farming tasks efficiently.
ManufacturerSatohPower11 hpEngine2-cylTransGear
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 11hp
- Transmission
- Gear
At a glance
How the ST1100 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
11 hp · 2nd
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The ST1100 ranks at the 2nd percentile for engine power among recorded sub-compact tractors.
Overview
About the Satoh ST1100
The Satoh ST1100 is a compact tractor designed for various farm tasks. It features a Mitsubishi KE55 engine, which is a liquid-cooled diesel engine with two cylinders. This engine is naturally aspirated, meaning it doesn't use a turbocharger. It has a displacement of 33.2 cubic inches and produces 11 horsepower, making it suitable for light to medium-duty work. The tractor comes with a gear transmission that offers 6 forward speeds and 2 reverse speeds. This range of gears allows the operator to choose the right speed for different jobs. The ST1100 is equipped with a Category 3 hitch, which is typically found on larger tractors. This hitch type allows the tractor to work with a wide range of implements and attachments. Overall, the Satoh ST1100 is a versatile machine that can handle various farming tasks efficiently.
Full specifications
Every recorded spec
General
| Manufacturer | Satoh |
|---|---|
| Model | ST1100 |
| Category | Sub-Compact tractor |
Engine
| Make | Mitsubishi |
|---|---|
| Model | KE55 |
| Power | 11hp |
| Cylinders | 2 |
| Displacement | 33.2ci |
| Bore | 2.68in |
| Stroke | 2.91in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 6 |
| Reverse gears | 2 |
Head to head
ST1100 vs. Sub-Compact median
How the Satoh ST1100 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 11 hp | 26.9 hp | -59% | 2nd |
| Engine Displacement | 33.2 ci | 91.4 ci | -64% | 2nd |
| Cylinders | 2 | 3 | -33% | 11th |
| Forward Gears | 6 | 9 | -33% | 18th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 616–816 models).
Compare to tractors with similar specs
Commonly compared Satoh tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Satoh ST1300 | 13 hp | — | — | Compare → |
| Satoh ST1320 | 13 hp | — | — | Compare → |
| Satoh ST1340 | 13 hp | — | — | Compare → |
| Satoh Beaver S370 | 15 hp | 1,035.3 lb | 1977–1984 | Compare → |
| Satoh ST1510 | 15 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Cub Cadet 1100 | 11 hp | 570 lb | 1974–1979 | Compare → |
| Cub Cadet 482 | 11 hp | — | 1979–1981 | Compare → |
| Deutz F1L612 | 10.8 hp | 1,830 lb | — | Compare → |
| Deutz F1M414 | 10.8 hp | 2,491 lb | — | Compare → |
| Allis Chalmers WC (1933-1937) | 11.9 hp | 3,188 lb | 1933–1937 | Compare → |
Explore
Satoh siblings
Explore
Similar-spec models
Gallery
Satoh ST1100 photos
FAQ
Common questions
How much horsepower does the Satoh ST1100 have?
The Satoh ST1100 produces 11 hp from its 2-cylinder engine. Engine displacement is 33.2 ci.
What hitch category is the Satoh ST1100?
The Satoh ST1100 uses a Category Category 3 hitch.
What transmission is in the Satoh ST1100?
Transmission on the Satoh ST1100 is Gear, with 6 forward speeds.
What maintenance does the Satoh ST1100 require?
Like any tractor, the Satoh ST1100 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
