Shibaura SD2640
The Shibaura SD2640 is a utility tractor built for versatility and efficiency. It features a 4-wheel drive system, making it great for tough jobs on various terrains. The tractor has a manual transmission with 12 forward gears and 4 reverse gears, giving the operator plenty of options for different tasks. Under the hood, the SD2640 has a Shibaura LEM853 engine. This 3-cylinder diesel engine is liquid-cooled and naturally aspirated. It has a displacement of 87.2 cubic inches, which is below average for tractors. The engine produces 26 horsepower, which is also on the lower end of the power range. Despite its smaller size, this tractor is well-suited for many farm and landscaping jobs. It weighs 2,904 pounds and has compact dimensions, measuring 119 inches long, 56 inches wide, and 73 inches tall. This makes it easy to maneuver in tight spaces.
ManufacturerShibauraPower26 hpEngine3-cylTransManual
Quick specs
- Category
- Utility
- Engine Power Output
- 26hp
- Operating Weight
- 2,904 lb
- Transmission
- Manual
At a glance
How the SD2640 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
26 hp · 18th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The SD2640 ranks at the 18th percentile for engine power among recorded utility tractors.
Overview
About the Shibaura SD2640
The Shibaura SD2640 is a utility tractor built for versatility and efficiency. It features a 4-wheel drive system, making it great for tough jobs on various terrains. The tractor has a manual transmission with 12 forward gears and 4 reverse gears, giving the operator plenty of options for different tasks. Under the hood, the SD2640 has a Shibaura LEM853 engine. This 3-cylinder diesel engine is liquid-cooled and naturally aspirated. It has a displacement of 87.2 cubic inches, which is below average for tractors. The engine produces 26 horsepower, which is also on the lower end of the power range. Despite its smaller size, this tractor is well-suited for many farm and landscaping jobs. It weighs 2,904 pounds and has compact dimensions, measuring 119 inches long, 56 inches wide, and 73 inches tall. This makes it easy to maneuver in tight spaces.
Full specifications
Every recorded spec
General
| Manufacturer | Shibaura |
|---|---|
| Model | SD2640 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 2,904lb |
Engine
| Make | Shibaura |
|---|---|
| Model | LEM853 |
| Power | 26hp |
| Cylinders | 3 |
| Displacement | 87.2ci |
| Bore | 3.35in |
| Stroke | 3.31in |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 12 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
Dimensions
| Length | 119in |
|---|---|
| Width | 56in |
| Height | 73in |
| Operating weight | 2,904lb |
Head to head
SD2640 vs. Utility median
How the Shibaura SD2640 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 26 hp | 55 hp | -53% | 18th |
| Engine Displacement | 87.2 ci | 183 ci | -52% | 15th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 2,904 lb | 5,303 lb | -45% | 21st |
| Length | 119 in | 137 in | -13% | 26th |
| Width | 56 in | 66 in | -15% | 30th |
| Height | 73 in | 94.1 in | -22% | 18th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Shibaura tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Shibaura SD2600 | 26 hp | 2,662 lb | — | Compare → |
| Shibaura SD2603 | 26 hp | 2,904 lb | — | Compare → |
| Shibaura SD2643 | 26 hp | 3,243 lb | — | Compare → |
| Shibaura S325 | 25 hp | 2,235 lb | — | Compare → |
| Shibaura SD2500 | 24.7 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 5020 | 25 hp | 2,060 lb | 1977–1985 | Compare → |
| Allis Chalmers FD3 | 25 hp | 3,150 lb | — | Compare → |
| Apollo 254 | 25 hp | — | — | Compare → |
| Belarus 254 | 25 hp | — | — | Compare → |
| Bobcat CT225 | 27 hp | 3,021 lb | 2008–2013 | Compare → |
Explore
Shibaura siblings
Explore
Similar-spec models
Gallery
Shibaura SD2640 photos
FAQ
Common questions
How much horsepower does the Shibaura SD2640 have?
The Shibaura SD2640 produces 26 hp from its 3-cylinder engine. Engine displacement is 87.2 ci.
How much does the Shibaura SD2640 weigh?
The Shibaura SD2640 weighs about 2,904 lb in operating condition.
What transmission is in the Shibaura SD2640?
Transmission on the Shibaura SD2640 is Manual, with 12 forward speeds.
What hitch category is the Shibaura SD2640?
The Shibaura SD2640 uses a Category Category 3 hitch.
What maintenance does the Shibaura SD2640 require?
Like any tractor, the Shibaura SD2640 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
