UtilityPerformance profile

Shibaura SD2803

The Shibaura SD2803 is a utility tractor designed for various farm tasks. It's powered by a Shibaura H843 engine, which is a 3-cylinder diesel engine with turbocharging. This engine has a displacement of 85.2 ci, which is below average compared to other tractors. It runs at 2500 rpm, which is above average, and produces 27.6 hp, which is on the lower end of the power range for tractors. This tractor has a 12-speed forward and 4-speed reverse transmission, giving the operator good control over speed and power. The SD2803 is compact, measuring 113 inches long, 52 inches wide, and 72 inches tall. It weighs 2433 lb, making it a lighter tractor that's easy to maneuver. The tractor's size and weight make it suitable for working in tight spaces or on smaller farms. Shibaura, a Japanese manufacturer, is known for making reliable, compact tractors for various agricultural needs.

ManufacturerShibauraPower27.6 hpEngine3-cyl
Jump to specs ↓Compare →
Shibaura SD2803
Jump to Full Specifications List

Quick specs

Category
Utility
Engine Power Output
28hp
Operating Weight
2,433 lb
Compare this model

At a glance

How the SD2803 compares

vs. Utility median

Distribution

Engine Power (hp)

Across all Utility tractors

27.6 hp · 19th

This model

9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383

The SD2803 ranks at the 19th percentile for engine power among recorded utility tractors.

Overview

About the Shibaura SD2803

The Shibaura SD2803 is a utility tractor designed for various farm tasks. It's powered by a Shibaura H843 engine, which is a 3-cylinder diesel engine with turbocharging. This engine has a displacement of 85.2 ci, which is below average compared to other tractors. It runs at 2500 rpm, which is above average, and produces 27.6 hp, which is on the lower end of the power range for tractors. This tractor has a 12-speed forward and 4-speed reverse transmission, giving the operator good control over speed and power. The SD2803 is compact, measuring 113 inches long, 52 inches wide, and 72 inches tall. It weighs 2433 lb, making it a lighter tractor that's easy to maneuver. The tractor's size and weight make it suitable for working in tight spaces or on smaller farms. Shibaura, a Japanese manufacturer, is known for making reliable, compact tractors for various agricultural needs.

Full specifications

Every recorded spec

General

ManufacturerShibaura
ModelSD2803
CategoryUtility tractor
Operating weight2,433lb

Engine

MakeShibaura
ModelH843
Power27.6hp
Cylinders3
Displacement85.2ci
Bore3.31in
Stroke3.31in

Transmission

Forward gears12
Reverse gears4

Dimensions

Length113in
Width52in
Height72in
Operating weight2,433lb

Head to head

SD2803 vs. Utility median

How the Shibaura SD2803 compares to other Utility tractors

SpecThis modelUtility medianDifferencePercentile
Engine Power27.6 hp55 hp-50%19th
Engine Displacement85.2 ci183 ci-53%14th
Cylinders34-25%23rd
Forward Gears1212at median50th
Operating Weight2,433 lb5,303 lb-54%16th
Length113 in137 in-17%18th
Width52 in66 in-21%20th
Height72 in94.1 in-23%17th

Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).

Explore

Shibaura siblings

All Shibaura models →

Explore

Similar-spec models

FAQ

Common questions

What is the engine power output of the Shibaura SD2803?

Rated engine output for the Shibaura SD2803 is 27.6 hp, delivered by a 3-cylinder engine. The engine displaces 85.2 ci.

What is the operating weight of the Shibaura SD2803?

In working trim, the Shibaura SD2803 comes in at roughly 2,433 lb.

How do I maintain a Shibaura SD2803?

Routine service for the Shibaura SD2803 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
