Shibaura SE1640
The Shibaura SE1640 is a compact utility tractor built for small farms and property maintenance. It has a 4-wheel drive system, which helps it work well on different types of ground. The tractor uses a gear transmission with 12 forward speeds and 4 reverse speeds, giving the driver good control over how fast it moves. Under the hood, the SE1640 has a small 2-cylinder diesel engine made by Shibaura. The engine is liquid-cooled to keep it running smoothly. It produces 16 horsepower, which is on the lower end for tractors but enough for light tasks. The tractor is quite small, measuring about 105 inches long, 50 inches wide, and 53 inches tall to the steering wheel. It weighs 1,775 pounds, making it lighter than many other tractors. This size makes it easy to use in tight spaces. The SE1640 has a Category I hitch, which lets it connect to various tools and attachments for different jobs.
ManufacturerShibauraPower16 hpEngine2-cylTransGear
Quick specs
- Category
- Utility
- Engine Power Output
- 16hp
- Operating Weight
- 1,775 lb
- Transmission
- Gear
At a glance
How the SE1640 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
16 hp · 4th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The SE1640 ranks at the 4th percentile for engine power among recorded utility tractors.
Overview
About the Shibaura SE1640
The Shibaura SE1640 is a compact utility tractor built for small farms and property maintenance. It has a 4-wheel drive system, which helps it work well on different types of ground. The tractor uses a gear transmission with 12 forward speeds and 4 reverse speeds, giving the driver good control over how fast it moves. Under the hood, the SE1640 has a small 2-cylinder diesel engine made by Shibaura. The engine is liquid-cooled to keep it running smoothly. It produces 16 horsepower, which is on the lower end for tractors but enough for light tasks. The tractor is quite small, measuring about 105 inches long, 50 inches wide, and 53 inches tall to the steering wheel. It weighs 1,775 pounds, making it lighter than many other tractors. This size makes it easy to use in tight spaces. The SE1640 has a Category I hitch, which lets it connect to various tools and attachments for different jobs.
Full specifications
Every recorded spec
General
| Manufacturer | Shibaura |
|---|---|
| Model | SE1640 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 1,775lb |
Engine
| Make | Shibaura |
|---|---|
| Model | LEK 802D |
| Power | 16hp |
| Cylinders | 2 |
| Displacement | 49.1ci |
| Bore | 3.15in |
| Stroke | 3.15in |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 12 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | MFWD (4WD) |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Length | 105.6in |
|---|---|
| Width | 50in |
| Height | 53.4in |
| Operating weight | 1,775lb |
Head to head
SE1640 vs. Utility median
How the Shibaura SE1640 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 16 hp | 55 hp | -71% | 4th |
| Engine Displacement | 49.1 ci | 183 ci | -73% | 2nd |
| Cylinders | 2 | 4 | -50% | 3rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 1,775 lb | 5,303 lb | -67% | 9th |
| Length | 106 in | 137 in | -23% | 12th |
| Width | 50 in | 66 in | -24% | 17th |
| Height | 53.4 in | 94.1 in | -43% | 5th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Shibaura tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Shibaura 1210 | 16 hp | 1,329 lb | 1983–1986 | Compare → |
| Shibaura SD1643 | 16 hp | — | — | Compare → |
| Shibaura SE1600 | 16 hp | 1,775 lb | — | Compare → |
| Shibaura SL1603 | 16 hp | 1,368 lb | — | Compare → |
| Shibaura SL1643 | 16 hp | 1,500 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Agria Hispania 7100 | 16 hp | — | — | Compare → |
| Bolens QS-16 | 16 hp | 849 lb | 1974–1977 | Compare → |
| Allis Chalmers 616 | 16.5 hp | 1,499 lb | 1972–1973 | Compare → |
| Ariens GT17 | 17 hp | 926 lb | 1979–1987 | Compare → |
| Bolens G152 | 15 hp | 1,034 lb | — | Compare → |
Explore
Shibaura siblings
Explore
Similar-spec models
Gallery
Shibaura SE1640 photos
FAQ
Common questions
How much horsepower does the Shibaura SE1640 have?
The Shibaura SE1640 produces 16 hp from its 2-cylinder engine. Engine displacement is 49.1 ci.
How much does the Shibaura SE1640 weigh?
The Shibaura SE1640 weighs about 1,775 lb in operating condition.
What transmission is in the Shibaura SE1640?
Transmission on the Shibaura SE1640 is Gear, with 12 forward speeds.
What type of hydraulic system does the Shibaura SE1640 use?
Hydraulics on the Shibaura SE1640 are Open Center.
What maintenance does the Shibaura SE1640 require?
Like any tractor, the Shibaura SE1640 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
