Utility tractorsSpec sheet
TAFE Gajraj 5900
The TAFE Gajraj 5900 is a utility tractor built for farm work. It has a 2WD drive system and a manual transmission with 8 forward gears and 2 reverse gears. This tractor is powered by a TAFE S433 diesel engine with 4 cylinders and liquid cooling. The engine puts out 60 hp at 2300 rpm, which is above average for its class. The Gajraj 5900 is a mid-sized tractor, measuring 141.3 inches long, 78.74 inches wide, and 96.46 inches tall. It weighs 4927 lb, which is about average for similar tractors. The tractor has agricultural tires front and rear, with a three-point hitch at the back for attaching implements. It also features a Category II rear hitch, making it versatile for various farming tasks. The engine displacement of 203.4 ci is above average, giving the tractor good pulling power for its size.
Key specifications
- Category
- Utility
- Engine power
- 60hp
- Operating weight
- 4,927 lb
- Transmission
- Manual
Category comparison
Gajraj 5900 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
60 hp · 54th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Gajraj 5900 ranks at the 54th percentile for engine power among recorded utility tractors.
Overview
About the TAFE Gajraj 5900
The TAFE Gajraj 5900 is a utility tractor built for farm work. It has a 2WD drive system and a manual transmission with 8 forward gears and 2 reverse gears. This tractor is powered by a TAFE S433 diesel engine with 4 cylinders and liquid cooling. The engine puts out 60 hp at 2300 rpm, which is above average for its class. The Gajraj 5900 is a mid-sized tractor, measuring 141.3 inches long, 78.74 inches wide, and 96.46 inches tall. It weighs 4927 lb, which is about average for similar tractors. The tractor has agricultural tires front and rear, with a three-point hitch at the back for attaching implements. It also features a Category II rear hitch, making it versatile for various farming tasks. The engine displacement of 203.4 ci is above average, giving the tractor good pulling power for its size.
Full specifications
Recorded specifications
General
| Manufacturer | TAFE |
|---|---|
| Model | Gajraj 5900 |
| Category | Utility tractor |
| Type | 4x2 |
| Operating weight | 4,927lb(2,235 kg) |
Engine
| Make | TAFE |
|---|---|
| Model | S433 |
| Power | 60hp(44.74 kW) |
| Cylinders | 4 |
| Displacement | 203.4ci(3.33 L) |
| Bore | 3.6in(91.39 mm) |
| Stroke | 5in(127 mm) |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 8 |
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 141.3in(3,589 mm) |
|---|---|
| Width | 78.74in(2,000 mm) |
| Height | 96.46in(2,450 mm) |
| Operating weight | 4,927lb(2,235 kg) |
Closest alternatives
Gajraj 5900 compared with the nearest models by horsepower
The closest utility models to the TAFE Gajraj 5900 by rated horsepower are the Kubota L6060 and the Massey Ferguson 1660. The Kubota L6060 matches it on rated power and weighs 940 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The Massey Ferguson 1660 matches it on rated power and weighs 850 lb less, carrying 68 lb per horsepower against 82 lb. Of the 3 models, the Gajraj 5900 has the highest weight per horsepower at 82 lb per hp.
| Spec | TAFE Gajraj 5900 | Kubota L6060 | Massey Ferguson 1660 |
|---|---|---|---|
| Engine power | 60 hp44.7 kW | 60 hp44.7 kW | 60 hp44.7 kW |
| Operating weight | 4,927 lb2,235 kg | 3,990 lb1,810 kg | 4,079 lb1,850 kg |
| Weight per hp | 82 lb/hp50 kg/kW | 67 lb/hp40 kg/kW | 68 lb/hp41 kg/kW |
| Displacement | 203.4 ci3.33 L | 148.5 ci2.43 L | 180.4 ci2.96 L |
| Cylinders | 4 | 4 | 4 |
| Transmission | Manual | Hydrostatic | PowerShuttle, DynaQPS |
| Drive | 2WD | 4WD | 4WD |
| Years built | - | 2013+ | 2009-2013 |
Calculators
Calculators for the Gajraj 5900
PTO power
About 50 to 54 PTO hp
Estimated from the 60 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 60 hp tractor can run
Maximum size is about a 7 ft rotary cutter or a 6 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
95 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
60 hp is 44.7 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
Gajraj 5900 vs. Utility median
TAFE Gajraj 5900 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 60 hp | 55 hp | +9% | 54th |
| Engine Displacement | 203 ci | 183 ci | +11% | 56th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 4,927 lb | 5,303 lb | -7% | 47th |
| Length | 141 in | 137 in | +3% | 57th |
| Width | 78.7 in | 66 in | +19% | 79th |
| Height | 96.5 in | 94.1 in | +3% | 56th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other TAFE models
Other manufacturers
Models with similar horsepower
Gallery
TAFE Gajraj 5900 photos
FAQ
Frequently asked questions
What is the engine power output of the TAFE Gajraj 5900?
Rated engine output for the TAFE Gajraj 5900 is 60 hp, delivered by a 4-cylinder engine. The engine displaces 203.4 ci.
Which transmission does the TAFE Gajraj 5900 use?
The TAFE Gajraj 5900 is equipped with a Manual transmission with 8 forward gears.
What is the operating weight of the TAFE Gajraj 5900?
The TAFE Gajraj 5900 has an operating weight of about 4,927 lb.
How do I maintain a TAFE Gajraj 5900?
Routine service for the TAFE Gajraj 5900 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
