Same brandVolvo 470
The Volvo 470 is a sturdy 2-wheel drive tractor built for farm work. It has a 4x2 chassis and manual steering, making it easy to control in fields. The tractor uses a gear transmission with 5 forward gears and 1 reverse gear, giving farmers options for different tasks. Under the hood, the Volvo 470 has a Bolinder 1114 TR engine. This diesel engine has 4 cylinders and is liquid-cooled to keep it running smoothly. It can produce 79 horsepower at 1800 RPM, which is enough power for many farm jobs. The tractor has big agricultural tires, with 7.50-18 in the front and 16.9/14-34 in the back. It's 135.8 inches long, 74.8 inches wide, and 64.8 inches tall. The Volvo 470 weighs 7408 pounds, making it a solid machine for fieldwork. It has a rear hitch for attaching tools and uses a 12-volt electrical system with an electric starter.

Key specifications
- Category
- Agricultural
- Engine power
- 79hp
- Operating weight
- 7,408 lb
- Transmission
- Gear
Category comparison
470 compared with its category
vs. Agricultural medianDistribution
Engine Power (hp)
All recorded Agricultural tractors
This model
The 470 ranks at the 26th percentile for engine power among recorded agricultural tractors.
Overview
About the Volvo 470
The Volvo 470 is a sturdy 2-wheel drive tractor built for farm work. It has a 4x2 chassis and manual steering, making it easy to control in fields. The tractor uses a gear transmission with 5 forward gears and 1 reverse gear, giving farmers options for different tasks. Under the hood, the Volvo 470 has a Bolinder 1114 TR engine. This diesel engine has 4 cylinders and is liquid-cooled to keep it running smoothly. It can produce 79 horsepower at 1800 RPM, which is enough power for many farm jobs. The tractor has big agricultural tires, with 7.50-18 in the front and 16.9/14-34 in the back. It's 135.8 inches long, 74.8 inches wide, and 64.8 inches tall. The Volvo 470 weighs 7408 pounds, making it a solid machine for fieldwork. It has a rear hitch for attaching tools and uses a 12-volt electrical system with an electric starter.
Full specifications
Recorded specifications
General
| Manufacturer | Volvo |
|---|---|
| Model | 470 |
| Category | Agricultural tractor |
| Type | 4x2 2WD |
| Operating weight | 7,408lb(3,360 kg) |
Engine
| Make | Bolinder |
|---|---|
| Model | 1114 TR |
| Power | 79hp(58.91 kW) |
| Cylinders | 4 |
| Displacement | 307.5ci(5.04 L) |
| Bore | 4.37in(111 mm) |
| Stroke | 5.12in(130 mm) |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 5 |
| Reverse gears | 1 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Manual |
Dimensions
| Length | 135.8in(3,449 mm) |
|---|---|
| Width | 74.8in(1,900 mm) |
| Height | 64.8in(1,646 mm) |
| Operating weight | 7,408lb(3,360 kg) |
Tires
| Front | 7.50-18ConvertShop size |
|---|---|
| Rear | 16.9/14-34Shop size |
Capacities
| Cooling system | 5.03gal(19.04 L) |
|---|
Closest alternatives
470 compared with the nearest models by horsepower
The closest agricultural models to the Volvo 470 by rated horsepower are the Massey Ferguson 5420 and the Shibaura SE7900. The Massey Ferguson 5420 matches it on rated power and weighs 970 lb more, at 106 lb per horsepower against 94 lb. The Shibaura SE7900 matches it on rated power and weighs 590 lb more. Of the 3 models, the 470 has the lowest weight per horsepower at 94 lb per hp.
| Spec | Volvo 470 | Massey Ferguson 5420 | Shibaura SE7900 |
|---|---|---|---|
| Engine power | 79 hp58.9 kW | 79 hp58.9 kW | 79 hp58.9 kW |
| Operating weight | 7,408 lb3,360 kg | 8,378 lb3,800 kg | 7,999 lb3,628 kg |
| Weight per hp | 94 lb/hp57 kg/kW | 106 lb/hp65 kg/kW | 101 lb/hp62 kg/kW |
| Displacement | 307.5 ci5.04 L | 268.5 ci4.4 L | - |
| Cylinders | 4 | 4 | - |
| Transmission | Gear | Four-speed power shift | - |
| Drive | 2WD | 4WD | - |
Calculators
Calculators for the 470
PTO power
About 66 to 71 PTO hp
Estimated from the 79 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 79 hp tractor can run
Maximum size is about a 9.5 ft rotary cutter or a 8 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
109 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
79 hp is 58.9 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Tires
Convert the 7.50-18 tire size
The calculator gives diameter, rolling circumference and the metric or inch equivalent.
Parts and manuals
Parts and manuals for the Volvo 470
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Bolinder 1114 TRAmazon
Fits the Bolinder 1114 TR 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Bolinder 1114 TRAmazon
Fits the Bolinder 1114 TR 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Bolinder 1114 TRAmazon
Fits the Bolinder 1114 TR 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Bolinder 1114 TRAmazon
Fits the Bolinder 1114 TR 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Volvo 470 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Volvo 470 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Volvo 470 service manualAmazon
Shop and repair manuals for this model.
Tires
- 7.50-18 tiresAmazon
Listed front tire size for the Volvo 470.
- 16.9/14-34 tiresAmazon
Listed rear tire size for the Volvo 470.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
470 vs. Agricultural median
Volvo 470 compared with other Agricultural tractors
| Spec | This model | Agricultural median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 79 hp | 110 hp | -28% | 26th |
| Engine Displacement | 308 ci | 336 ci | -8% | 48th |
| Cylinders | 4 | 5.5 | -27% | 31st |
| Forward Gears | 5 | 16 | -69% | 7th |
| Operating Weight | 7,408 lb | 10,914 lb | -32% | 27th |
| Length | 136 in | 173 in | -21% | 18th |
| Width | 74.8 in | 79.5 in | -6% | 39th |
| Height | 64.8 in | 111 in | -41% | 9th |
Medians and percentiles are calculated from the agricultural tractors in the database that have a recorded value for each specification (sample size 497–1,130 models).
Same manufacturer
Other Volvo models
Other manufacturers
Models with similar horsepower
Gallery
Volvo 470 photos






FAQ
Frequently asked questions
What is the engine power output of the Volvo 470?
Rated engine output for the Volvo 470 is 79 hp, delivered by a 4-cylinder engine. The engine displaces 307.5 ci.
Which transmission does the Volvo 470 use?
The Volvo 470 is equipped with a Gear transmission with 5 forward gears.
What are the factory tire sizes for the Volvo 470?
The Volvo 470 comes with 7.50-18 front tires and 16.9/14-34 rear tires.
What is the operating weight of the Volvo 470?
The Volvo 470 has an operating weight of about 7,408 lb.
How do I maintain a Volvo 470?
Routine service for the Volvo 470 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
