UtilityPerformance profile
XTZ XTZ-17022
The XTZ XTZ-17022 is a powerful utility tractor built for tough jobs. It has a strong 4-wheel drive system and can turn easily with its special steering. The tractor uses a manual transmission with 12 forward gears and 4 reverse gears, giving the driver lots of control. Under the hood, there's a big Deutz diesel engine with 6 cylinders. This engine is very powerful, putting out 180 horsepower, which is more than most other tractors. It's also cooled by liquid to keep it running smoothly. The tractor is quite heavy, weighing 19,180 pounds, which helps it handle big tasks. It's also pretty big, measuring about 21 feet long, 8 feet wide, and 11 feet tall. This XTZ tractor is made for farm work, with big agricultural tires on both the front and back. It has a very high engine power and weight compared to other tractors, making it great for heavy-duty jobs. The tractor starts up easily with an electric starter, and it has special 26-inch rims on its wheels. Overall, the XTZ-17022 is a strong, capable tractor that can handle tough farm work with ease.
ManufacturerXTZPower180 hpEngine6-cylTransManual
Quick specs
- Category
- Utility
- Engine Power Output
- 180hp
- Operating Weight
- 19,180 lb
- Transmission
- Manual
At a glance
How the XTZ-17022 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
180 hp · 94th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The XTZ-17022 ranks at the 94th percentile for engine power among recorded utility tractors.
Overview
About the XTZ XTZ-17022
The XTZ XTZ-17022 is a powerful utility tractor built for tough jobs. It has a strong 4-wheel drive system and can turn easily with its special steering. The tractor uses a manual transmission with 12 forward gears and 4 reverse gears, giving the driver lots of control. Under the hood, there's a big Deutz diesel engine with 6 cylinders. This engine is very powerful, putting out 180 horsepower, which is more than most other tractors. It's also cooled by liquid to keep it running smoothly. The tractor is quite heavy, weighing 19,180 pounds, which helps it handle big tasks. It's also pretty big, measuring about 21 feet long, 8 feet wide, and 11 feet tall. This XTZ tractor is made for farm work, with big agricultural tires on both the front and back. It has a very high engine power and weight compared to other tractors, making it great for heavy-duty jobs. The tractor starts up easily with an electric starter, and it has special 26-inch rims on its wheels. Overall, the XTZ-17022 is a strong, capable tractor that can handle tough farm work with ease.
Full specifications
Every recorded spec
General
| Manufacturer | XTZ |
|---|---|
| Model | XTZ-17022 |
| Category | Utility tractor |
| Type | 4x4 articulated 4WD |
| Operating weight | 19,180lb |
Engine
| Make | Deutz |
|---|---|
| Model | BF6M1013E |
| Power | 180hp |
| Cylinders | 6 |
| Displacement | 435ci |
| Bore | 4.25in |
| Stroke | 5.51in |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 12 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x4 articulated 4WD |
|---|---|
| Drive | 4WD |
| Steering | Articulated power |
Dimensions
| Length | 255.9in |
|---|---|
| Width | 96.9in |
| Height | 132.3in |
| Operating weight | 19,180lb |
Head to head
XTZ-17022 vs. Utility median
How the XTZ XTZ-17022 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 180 hp | 55 hp | +227% | 94th |
| Engine Displacement | 435 ci | 183 ci | +138% | 92nd |
| Cylinders | 6 | 4 | +50% | 93rd |
| Forward Gears | 12 | 12 | at median | 50th |
| Operating Weight | 19,180 lb | 5,303 lb | +262% | 95th |
| Length | 256 in | 137 in | +87% | 97th |
| Width | 96.9 in | 66 in | +47% | 95th |
| Height | 132 in | 94.1 in | +41% | 96th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared XTZ tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| XTZ XTZ-150K-12 | 180 hp | 17,650 lb | — | Compare → |
| XTZ XTZ-16131 | 180 hp | 19,000 lb | — | Compare → |
| XTZ XTZ-17021 | 180 hp | 18,700 lb | — | Compare → |
| XTZ XTZ-17221 | 180 hp | 19,000 lb | — | Compare → |
| XTZ XTZ-17221-09 | 180 hp | 19,000 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Ascot Universal A1800A | 180 hp | 21,400 lb | — | Compare → |
| AGCO RT140A | 179.7 hp | 16,305 lb | — | Compare → |
| Agrinar T-180 | 182.5 hp | — | — | Compare → |
| Belarus 1500 | 175 hp | 18,600 lb | — | Compare → |
| Belarus 1770 | 185 hp | 19,585 lb | — | Compare → |
Explore
XTZ siblings
Explore
Similar-spec models
Gallery
XTZ XTZ-17022 photos
FAQ
Common questions
How powerful is the XTZ XTZ-17022?
The XTZ XTZ-17022 has an engine power output of 180 hp. It is powered by a 6-cylinder engine displacing 435 ci.
What is the working weight of the XTZ XTZ-17022?
The operating weight of the XTZ XTZ-17022 is approximately 19,180 lb.
What type of transmission does the XTZ XTZ-17022 have?
The XTZ XTZ-17022 uses a Manual transmission offering 12 forward gears.
What routine service does the XTZ XTZ-17022 need?
Regular maintenance for the XTZ XTZ-17022 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
