Yanmar AC-10
The Yanmar AC-10 is a compact tractor that was made from 2001 to 2014. It's small but strong, perfect for light farm work and gardening. This tractor is 96.9 inches long, 52.8 inches wide, and 69.3 inches tall. It weighs 1124 pounds, which is light enough to be easy to move around. The AC-10 has a Yanmar diesel engine that's air-cooled. This engine is 26.6 cubic inches and can make 10 horsepower. It has a gear transmission with 6 forward gears and 6 reverse gears, giving the driver good control. The tractor starts with an electric starter, making it easy to use. It also has 13 inches of ground clearance, which helps it move over bumpy ground. Yanmar is known for making reliable tractors, and this model is no exception.
ManufacturerYanmarPower10 hpTransGear
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 10hp
- Operating Weight
- 1,124 lb
- Transmission
- Gear
At a glance
How the AC-10 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
10 hp · 1st
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The AC-10 ranks at the 1st percentile for engine power among recorded sub-compact tractors.
Overview
About the Yanmar AC-10
The Yanmar AC-10 is a compact tractor that was made from 2001 to 2014. It's small but strong, perfect for light farm work and gardening. This tractor is 96.9 inches long, 52.8 inches wide, and 69.3 inches tall. It weighs 1124 pounds, which is light enough to be easy to move around. The AC-10 has a Yanmar diesel engine that's air-cooled. This engine is 26.6 cubic inches and can make 10 horsepower. It has a gear transmission with 6 forward gears and 6 reverse gears, giving the driver good control. The tractor starts with an electric starter, making it easy to use. It also has 13 inches of ground clearance, which helps it move over bumpy ground. Yanmar is known for making reliable tractors, and this model is no exception.
Full specifications
Every recorded spec
General
| Manufacturer | Yanmar |
|---|---|
| Model | AC-10 |
| Category | Sub-Compact tractor |
| Years built | 2001–2014 |
| Operating weight | 1,124lb |
Engine
| Make | Yanmar |
|---|---|
| Power | 10hp |
| Displacement | 26.6ci |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 6 |
| Reverse gears | 6 |
Dimensions
| Length | 96.9in |
|---|---|
| Width | 52.8in |
| Height | 69.3in |
| Operating weight | 1,124lb |
Head to head
AC-10 vs. Sub-Compact median
How the Yanmar AC-10 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 10 hp | 26.9 hp | -63% | 1st |
| Engine Displacement | 26.6 ci | 91.4 ci | -71% | 1st |
| Forward Gears | 6 | 9 | -33% | 18th |
| Operating Weight | 1,124 lb | 2,700 lb | -58% | 5th |
| Length | 96.9 in | 113 in | -15% | 25th |
| Width | 52.8 in | 50.7 in | +4% | 55th |
| Height | 69.3 in | 78.4 in | -12% | 27th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).
Compare to tractors with similar specs
Commonly compared Yanmar tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Yanmar FX13D | 13 hp | — | — | Compare → |
| Yanmar YM1301 | 13 hp | 1,124 lb | — | Compare → |
| Yanmar YM135 | 13 hp | 1,100 lb | — | Compare → |
| Yanmar GT14 | 14 hp | — | 1988–1990 | Compare → |
| Yanmar YM140 | 14 hp | 1,096 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Bolens 1050 | 10 hp | 644 lb | 1966–1969 | Compare → |
| Cub Cadet 100 | 10 hp | — | 1963–1965 | Compare → |
| Cub Cadet 1000 | 10 hp | 628 lb | 1974–1980 | Compare → |
| Cub Cadet 1015 | 10 hp | 396.8 lb | 1988–1991 | Compare → |
| Cub Cadet 102 | 10 hp | 778 lb | 1965–1967 | Compare → |
Explore
Yanmar siblings
Explore
Similar-spec models
Gallery
Yanmar AC-10 photos
FAQ
Common questions
What years was the Yanmar AC-10 manufactured?
Production of the Yanmar AC-10 ran from 2001 through 2014.
What type of transmission does the Yanmar AC-10 have?
The Yanmar AC-10 uses a Gear transmission offering 6 forward gears.
How powerful is the Yanmar AC-10?
The Yanmar AC-10 has an engine power output of 10 hp.
What is the working weight of the Yanmar AC-10?
The operating weight of the Yanmar AC-10 is approximately 1,124 lb.
What routine service does the Yanmar AC-10 need?
Regular maintenance for the Yanmar AC-10 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
