Utility tractorsSpec sheet
YTO 404
The YTO 404 is a utility tractor built for various farm tasks. It has a 4x4 chassis and four-wheel drive, making it good for working in tough conditions. The tractor is powered by a YTO YTR3105 engine with three cylinders. This diesel engine is liquid-cooled and produces 39.4 horsepower, which is below average for tractors. It runs at 2200 rpm, which is also below average. This tractor is compact, measuring 139.7 inches long, 66 inches wide, and 61.2 inches tall. It weighs 4233 pounds, which is about average for its class. The YTO 404 has agricultural tires, with 7.5-16 tires in front and 11.2-28 tires in the back. It has a ground clearance of 1.6 inches, which helps it move over small obstacles. Overall, the YTO 404 is a basic utility tractor suitable for small to medium-sized farms.
Key specifications
- Category
- Utility
- Engine power
- 39hp
- Operating weight
- 4,233 lb
Category comparison
404 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
39.4 hp · 33rd
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 404 ranks at the 33rd percentile for engine power among recorded utility tractors.
Overview
About the YTO 404
The YTO 404 is a utility tractor built for various farm tasks. It has a 4x4 chassis and four-wheel drive, making it good for working in tough conditions. The tractor is powered by a YTO YTR3105 engine with three cylinders. This diesel engine is liquid-cooled and produces 39.4 horsepower, which is below average for tractors. It runs at 2200 rpm, which is also below average. This tractor is compact, measuring 139.7 inches long, 66 inches wide, and 61.2 inches tall. It weighs 4233 pounds, which is about average for its class. The YTO 404 has agricultural tires, with 7.5-16 tires in front and 11.2-28 tires in the back. It has a ground clearance of 1.6 inches, which helps it move over small obstacles. Overall, the YTO 404 is a basic utility tractor suitable for small to medium-sized farms.
Full specifications
Recorded specifications
General
| Manufacturer | YTO |
|---|---|
| Model | 404 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 4,233lb(1,920 kg) |
Engine
| Make | YTO |
|---|---|
| Model | YTR3105 |
| Power | 39.4hp(29.38 kW) |
| Cylinders | 3 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
Dimensions
| Length | 139.7in(3,548 mm) |
|---|---|
| Width | 66in(1,676 mm) |
| Height | 61.2in(1,554 mm) |
| Operating weight | 4,233lb(1,920 kg) |
Closest alternatives
404 compared with the nearest models by horsepower
By engine horsepower, the nearest utility models to the 404 are the Massey Ferguson 1840E and the Massey Ferguson 1840M. The Massey Ferguson 1840E matches it on rated power and weighs 1,360 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The Massey Ferguson 1840M matches it on rated power and weighs 760 lb less, carrying 88 lb per horsepower against 107 lb. Of the 3 models, the 404 has the highest weight per horsepower at 107 lb per hp.
| Spec | YTO 404 | Massey Ferguson 1840E | Massey Ferguson 1840M |
|---|---|---|---|
| Engine power | 39.4 hp29.4 kW | 39.4 hp29.4 kW | 39.4 hp29.4 kW |
| Operating weight | 4,233 lb1,920 kg | 2,877 lb1,305 kg | 3,472 lb1,575 kg |
| Weight per hp | 107 lb/hp65 kg/kW | 73 lb/hp44 kg/kW | 88 lb/hp54 kg/kW |
| Displacement | - | 111.4 ci1.83 L | 111.4 ci1.83 L |
| Cylinders | 3 | 3 | 3 |
| Transmission | - | Mechanical shuttle | Power Shuttle |
| Drive | 4WD | MFWD 4WD | 4WD |
| Years built | - | 2020+ | 2020+ |
Calculators
Calculators for the 404
PTO power
About 33 to 35 PTO hp
Estimated from the 39.4 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 39.4 hp tractor can run
Maximum size is about a 4.5 ft rotary cutter or a 4 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
125 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
39.4 hp is 29.4 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Category medians
404 vs. Utility median
YTO 404 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 39.4 hp | 55 hp | -28% | 33rd |
| Cylinders | 3 | 4 | -25% | 23rd |
| Operating Weight | 4,233 lb | 5,303 lb | -20% | 40th |
| Length | 140 in | 137 in | +2% | 54th |
| Width | 66 in | 66 in | at median | 50th |
| Height | 61.2 in | 94.1 in | -35% | 11th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,720 models).
Same manufacturer
Other YTO models
Other manufacturers
Models with similar horsepower
Gallery
YTO 404 photos
FAQ
Frequently asked questions
How much horsepower does the YTO 404 have?
The YTO 404 produces 39.4 hp from its 3-cylinder engine.
How much does the YTO 404 weigh?
The YTO 404 weighs about 4,233 lb in operating condition.
What maintenance does the YTO 404 require?
The YTO 404 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
