Utility tractorsSpec sheet
Zetor Compax 25
The Zetor Compax 25 is a compact utility tractor designed for small farms and light work. It features a 4-wheel drive system and power steering, making it easy to handle in tight spaces. The tractor is powered by a Yanmar diesel engine that produces 23.3 hp, which is below average for its class but suitable for many tasks. This tractor has a 6-forward and 2-reverse gear transmission, giving operators good control over speed and power. It runs on agricultural tires, with 6.0-12 sizes in front and 9.5-16 in the rear. The Compax 25 is small, measuring 100.5 inches long, 45.8 inches wide, and 91.3 inches tall. It comes with an electric starter and a roll-over protection system (ROPS) for safety. The tractor's compact size and features make it a good choice for small-scale farming and property maintenance.
Key specifications
- Category
- Utility
- Engine power
- 23hp
Category comparison
Compax 25 compared with its category
vs. Utility medianDistribution
Engine Power (hp)
All recorded Utility tractors
23.3 hp · 13th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Compax 25 ranks at the 13th percentile for engine power among recorded utility tractors.
Overview
About the Zetor Compax 25
The Zetor Compax 25 is a compact utility tractor designed for small farms and light work. It features a 4-wheel drive system and power steering, making it easy to handle in tight spaces. The tractor is powered by a Yanmar diesel engine that produces 23.3 hp, which is below average for its class but suitable for many tasks. This tractor has a 6-forward and 2-reverse gear transmission, giving operators good control over speed and power. It runs on agricultural tires, with 6.0-12 sizes in front and 9.5-16 in the rear. The Compax 25 is small, measuring 100.5 inches long, 45.8 inches wide, and 91.3 inches tall. It comes with an electric starter and a roll-over protection system (ROPS) for safety. The tractor's compact size and features make it a good choice for small-scale farming and property maintenance.
Full specifications
Recorded specifications
General
| Manufacturer | Zetor |
|---|---|
| Model | Compax 25 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
Engine
| Make | Yanmar |
|---|---|
| Power | 23.3hp(17.37 kW) |
Transmission
| Forward gears | 6 |
|---|---|
| Reverse gears | 2 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
Dimensions
| Length | 100.5in(2,553 mm) |
|---|---|
| Width | 45.8in(1,163 mm) |
| Height | 91.3in(2,319 mm) |
Tires
| Front | 6.0-12ConvertShop size |
|---|---|
| Rear | 9.5-16ConvertShop size |
Closest alternatives
Compax 25 compared with the nearest models by horsepower
By engine horsepower, the nearest utility models to the Compax 25 are the Massey Ferguson 1423 and the Challenger MT225. The Massey Ferguson 1423 matches it on rated power. The Challenger MT225 matches it on rated power.
| Spec | Zetor Compax 25 | Massey Ferguson 1423 | Challenger MT225 |
|---|---|---|---|
| Engine power | 23.3 hp17.4 kW | 23.3 hp17.4 kW | 23.3 hp17.4 kW |
| Operating weight | - | 1,498 lb679 kg | 1,672 lb758 kg |
| Weight per hp | - | 64 lb/hp39 kg/kW | 72 lb/hp44 kg/kW |
| Displacement | - | 68.5 ci1.12 L | 68.5 ci1.12 L |
| Cylinders | - | 3 | 3 |
| Drive | 4WD | 4WD | 4WD |
Calculators
Calculators for the Compax 25
PTO power
About 19 to 21 PTO hp
Estimated from the 23.3 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 23.3 hp tractor can run
The calculator sizes mowers, tillers, discs, plows and balers for this tractor.
Units
23.3 hp is 17.4 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Tires
Convert the 9.5-16 tire size
The calculator gives diameter, rolling circumference and the metric or inch equivalent.
Parts and manuals
Parts and manuals for the Zetor Compax 25
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the YanmarAmazon
Fits the Yanmar diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the YanmarAmazon
Fits the Yanmar diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the YanmarAmazon
Fits the Yanmar diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the YanmarAmazon
Fits the Yanmar diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Zetor Compax 25 service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Zetor Compax 25 operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Zetor Compax 25 service manualAmazon
Shop and repair manuals for this model.
Tires
- 6.0-12 tiresAmazon
Listed front tire size for the Zetor Compax 25.
- 9.5-16 tiresAmazon
Listed rear tire size for the Zetor Compax 25.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Compax 25 vs. Utility median
Zetor Compax 25 compared with other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 23.3 hp | 55 hp | -58% | 13th |
| Forward Gears | 6 | 12 | -50% | 11th |
| Length | 101 in | 137 in | -26% | 9th |
| Width | 45.8 in | 66 in | -31% | 11th |
| Height | 91.3 in | 94.1 in | -3% | 44th |
Medians and percentiles are calculated from the utility tractors in the database that have a recorded value for each specification (sample size 3,933–5,383 models).
Same manufacturer
Other Zetor models
Other manufacturers
Models with similar horsepower
Gallery
Zetor Compax 25 photos
FAQ
Frequently asked questions
How powerful is the Zetor Compax 25?
The Zetor Compax 25 has an engine power output of 23.3 hp.
What size tires does the Zetor Compax 25 use?
The Zetor Compax 25 is fitted with 6.0-12 front tires and 9.5-16 rear tires from the factory.
What routine service does the Zetor Compax 25 need?
Regular maintenance for the Zetor Compax 25 includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
