Bolens HT23
The Bolens HT23 is a compact lawn and garden tractor that was made from 1979 to 1987. It's perfect for taking care of your yard and small farm tasks. This tractor has a 2-wheel drive system and manual steering, making it easy to use for most people. The HT23 is powered by a Kohler K582 engine, which is air-cooled and runs on gasoline. With 23 horsepower, it's stronger than many other lawn tractors. The engine has two cylinders and is very powerful for its size. It uses a special transmission that lets you change speeds smoothly without gears. The tractor can go forward and backward at many different speeds. It has lawn tires on both the front and back, which are good for not damaging grass. The HT23 is small enough to fit in tight spaces, measuring about 75 inches long, 46 inches wide, and 45 inches tall. It weighs 1098 pounds, which is heavier than most lawn tractors but helps it stay stable during work.
ManufacturerBolensPower23 hp(17.2 kW)ClassUnder 25 HP tractors →Engine2-cylinderTransmissionShaft-driven hydrostatic
Key specifications
- Category
- Lawn and Garden
- Engine power
- 23hp
- Operating weight
- 1,098 lb
- Transmission
- Shaft-driven hydrostatic
Category comparison
HT23 compared with its category
vs. Lawn and Garden medianDistribution
Engine Power (hp)
All recorded Lawn and Garden tractors
23 hp · 76th
This model
4
Median 18 hp
28
This modelLawn and Garden tractorsMediann = 380
The HT23 ranks at the 76th percentile for engine power among recorded lawn and garden tractors.
Overview
About the Bolens HT23
The Bolens HT23 is a compact lawn and garden tractor that was made from 1979 to 1987. It's perfect for taking care of your yard and small farm tasks. This tractor has a 2-wheel drive system and manual steering, making it easy to use for most people. The HT23 is powered by a Kohler K582 engine, which is air-cooled and runs on gasoline. With 23 horsepower, it's stronger than many other lawn tractors. The engine has two cylinders and is very powerful for its size. It uses a special transmission that lets you change speeds smoothly without gears. The tractor can go forward and backward at many different speeds. It has lawn tires on both the front and back, which are good for not damaging grass. The HT23 is small enough to fit in tight spaces, measuring about 75 inches long, 46 inches wide, and 45 inches tall. It weighs 1098 pounds, which is heavier than most lawn tractors but helps it stay stable during work.
Full specifications
Recorded specifications
General
| Manufacturer | Bolens |
|---|---|
| Model | HT23 |
| Category | Lawn and Garden tractor |
| Type | 4x2 |
| Years built | 1979–1987 |
| Operating weight | 1,098lb(498 kg) |
Engine
| Make | Kohler |
|---|---|
| Model | K582 |
| Power | 23hp(17.15 kW) |
| Cylinders | 2 |
| Displacement | 57.7ci(0.95 L) |
| Bore | 3.5in(88.9 mm) |
| Stroke | 3in(76.2 mm) |
Transmission
| Type | Shaft-driven hydrostatic |
|---|
Chassis & drive
| Chassis | 4x2 |
|---|---|
| Drive | 2WD |
| Steering | Manual |
| Cab | Open station |
Power take-off
| PTO speed | 2,000rpm |
|---|
Dimensions
| Length | 74.8in(1,900 mm) |
|---|---|
| Width | 45.7in(1,161 mm) |
| Height | 44.9in(1,140 mm) |
| Operating weight | 1,098lb(498 kg) |
Closest alternatives
HT23 compared with the nearest models by horsepower
By engine horsepower, the nearest lawn and garden models to the HT23 are the Cub Cadet XT2 LX46 FAB and the Cub Cadet XT2 LX50. The Cub Cadet XT2 LX46 FAB matches it on rated power and weighs 660 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. It entered production in 2015, 36 years after the HT23. The Cub Cadet XT2 LX50 matches it on rated power and weighs 600 lb less, carrying 22 lb per horsepower against 48 lb. It entered production in 2015, 36 years after the HT23. Of the 3 models, the HT23 has the highest weight per horsepower at 48 lb per hp.
| Spec | Bolens HT23 | Cub Cadet XT2 LX46 FAB | Cub Cadet XT2 LX50 |
|---|---|---|---|
| Engine power | 23 hp17.2 kW | 23 hp17.2 kW | 23 hp17.2 kW |
| Operating weight | 1,098 lb498 kg | 438 lb199 kg | 498 lb226 kg |
| Weight per hp | 48 lb/hp29 kg/kW | 19 lb/hp12 kg/kW | 22 lb/hp13 kg/kW |
| Displacement | 57.7 ci0.95 L | 44.3 ci0.73 L | 44.3 ci0.73 L |
| Cylinders | 2 | 2 | 2 |
| Transmission | Shaft-driven hydrostatic | Belt-driven Hydrostatic | Belt-driven hydrostatic |
| Drive | 2WD | 2WD | 2WD |
| Years built | 1979-1987 | 2015+ | 2015+ |
Calculators
Calculators for the HT23
PTO power
About 19 to 21 PTO hp
Estimated from the 23 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 23 hp tractor can run
The calculator sizes mowers, tillers, discs, plows and balers for this tractor.
Ballast
56 lb per PTO hp as listed
Heavy draft work calls for 130 to 150 lb/hp. The calculator gives the ballast to add.
Units
23 hp is 17.2 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the Bolens HT23
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the Kohler K582Amazon
Fits the Kohler K582 2-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the Kohler K582Amazon
Fits the Kohler K582 2-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the Kohler K582Amazon
Fits the Kohler K582 2-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the Kohler K582Amazon
Fits the Kohler K582 2-cylinder gasoline engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Bolens HT23 service and repair manualseManualOnline
Digital manuals. Built 1979 to 1987. Check the serial number range on the listing.
- Bolens HT23 operator's manualAmazon
Printed and reprint manuals. Built 1979 to 1987. Check the serial number range on the listing.
- Bolens HT23 service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
HT23 vs. Lawn and Garden median
Bolens HT23 compared with other Lawn and Garden tractors
| Spec | This model | Lawn and Garden median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 23 hp | 18 hp | +28% | 76th |
| Engine Displacement | 57.7 ci | 41.1 ci | +40% | 78th |
| Cylinders | 2 | 2 | at median | 50th |
| Operating Weight | 1,098 lb | 738 lb | +49% | 66th |
| Length | 74.8 in | 71.7 in | +4% | 66th |
| Width | 45.7 in | 43.3 in | +6% | 59th |
| Height | 44.9 in | 42.9 in | +5% | 64th |
Medians and percentiles are calculated from the lawn and garden tractors in the database that have a recorded value for each specification (sample size 269–380 models).
Same manufacturer
Other Bolens models
Other manufacturers
Models with similar horsepower
Gallery
Bolens HT23 photos
FAQ
Frequently asked questions
When was the Bolens HT23 in production?
Bolens HT23 production started in 1979 and ended in 1987.
How much does the Bolens HT23 weigh?
The Bolens HT23 weighs about 1,098 lb in operating condition.
What transmission is in the Bolens HT23?
Transmission on the Bolens HT23 is Shaft-driven hydrostatic.
What hitch category is the Bolens HT23?
The Bolens HT23 uses a Category 0 hitch.
How much horsepower does the Bolens HT23 have?
The Bolens HT23 produces 23 hp from its 2-cylinder engine. Engine displacement is 57.7 ci.
What maintenance does the Bolens HT23 require?
The Bolens HT23 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
