Cabelas LM75
The Cabelas LM75 is a utility tractor built for tough jobs. It has a strong 4-wheel drive system and power steering, making it easy to handle in various conditions. The tractor comes with a 16-speed transmission, giving you plenty of options for different tasks. Under the hood, you'll find a Deutz TCD2.9 engine. This diesel engine is turbocharged and liquid-cooled, with 4 cylinders. It produces 74 horsepower, which is above average for tractors in its class. The engine size is about average, while its operating weight of 6,110 lb is on the heavier side. This tractor is built to last, with a sturdy frame and standard tires. It also features a Category II hitch, making it compatible with many attachments.
ManufacturerCabelasPower74 hpEngine4-cylTransSynchronized Shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 74hp
- Operating Weight
- 6,110 lb
- Transmission
- Synchronized Shuttle
At a glance
How the LM75 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
74 hp · 66th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The LM75 ranks at the 66th percentile for engine power among recorded utility tractors.
Overview
About the Cabelas LM75
The Cabelas LM75 is a utility tractor built for tough jobs. It has a strong 4-wheel drive system and power steering, making it easy to handle in various conditions. The tractor comes with a 16-speed transmission, giving you plenty of options for different tasks. Under the hood, you'll find a Deutz TCD2.9 engine. This diesel engine is turbocharged and liquid-cooled, with 4 cylinders. It produces 74 horsepower, which is above average for tractors in its class. The engine size is about average, while its operating weight of 6,110 lb is on the heavier side. This tractor is built to last, with a sturdy frame and standard tires. It also features a Category II hitch, making it compatible with many attachments.
Full specifications
Every recorded spec
General
| Manufacturer | Cabelas |
|---|---|
| Model | LM75 |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 6,110lb |
Engine
| Make | Deutz |
|---|---|
| Model | TCD2.9 |
| Power | 74hp |
| Cylinders | 4 |
| Displacement | 178ci |
| Bore | 3.62in |
| Stroke | 4.33in |
Transmission
| Type | Synchronized Shuttle |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Power |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Height | 104.3in |
|---|---|
| Operating weight | 6,110lb |
Capacities
| Cooling system | 2.5gal |
|---|
Head to head
LM75 vs. Utility median
How the Cabelas LM75 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 74 hp | 55 hp | +35% | 66th |
| Engine Displacement | 178 ci | 183 ci | -3% | 47th |
| Cylinders | 4 | 4 | at median | 50th |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 6,110 lb | 5,303 lb | +15% | 58th |
| Height | 104 in | 94.1 in | +11% | 76th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,321–5,720 models).
Compare to tractors with similar specs
Commonly compared Cabelas tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Cabelas LM55 | 55.1 hp | 4,415 lb | — | Compare → |
| Cabelas LM50 | 50.7 hp | 3,640 lb | — | Compare → |
| Cabelas LM45 | 46 hp | 3,770 lb | — | Compare → |
| Cabelas LM43 | 42.7 hp | 3,640 lb | — | Compare → |
| Cabelas LM35 | 35 hp | 3,140 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers D19 | 74.2 hp | 6,650 lb | 1961–1964 | Compare → |
| AGCO GT65 | 71 hp | 5,335 lb | — | Compare → |
| Agco GT65A | 71 hp | 5,864.3 lb | — | Compare → |
| Antonio Carraro SX 7800S | 71 hp | 4,773 lb | — | Compare → |
| Antonio Carraro TGF 7800S | 71 hp | 5,093 lb | — | Compare → |
Explore
Cabelas siblings
Explore
Similar-spec models
Gallery
Cabelas LM75 photos
FAQ
Common questions
How much horsepower does the Cabelas LM75 have?
The Cabelas LM75 produces 74 hp from its 4-cylinder engine. Engine displacement is 178 ci.
What hitch category is the Cabelas LM75?
The Cabelas LM75 uses a Category II hitch.
How much does the Cabelas LM75 weigh?
The Cabelas LM75 weighs about 6,110 lb in operating condition.
What transmission is in the Cabelas LM75?
Transmission on the Cabelas LM75 is Synchronized Shuttle, with 16 forward speeds.
What type of hydraulic system does the Cabelas LM75 use?
Hydraulics on the Cabelas LM75 are Open Center.
What maintenance does the Cabelas LM75 require?
Like any tractor, the Cabelas LM75 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
