CaseIH 395
The CaseIH 395 is a utility tractor built for everyday farm work. It has a 2WD drive system and power steering, making it easy to handle. The tractor uses a partially synchronized transmission with 8 forward gears and 4 reverse gears, giving drivers good control over speed and power. Under the hood, the CaseIH 395 has a Case International D-155 engine. This diesel engine has 3 cylinders and is liquid-cooled. It produces 46 hp at 2200 rpm, which is average power for its class. The engine size is also about average compared to other tractors. The tractor weighs 4869 lb, which is typical for a utility tractor. It has a three-point hitch at the back, which can handle category I or II implements. The open operator station comes with a roll-over protection system (ROPS) for safety.
ManufacturerCaseIHPower46 hpEngine3-cylTransPartially Synchronized
Quick specs
- Category
- Utility
- Engine Power Output
- 46hp
- Operating Weight
- 4,869 lb
- Transmission
- Partially Synchronized
At a glance
How the 395 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
46 hp · 40th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 395 ranks at the 40th percentile for engine power among recorded utility tractors.
Overview
About the CaseIH 395
The CaseIH 395 is a utility tractor built for everyday farm work. It has a 2WD drive system and power steering, making it easy to handle. The tractor uses a partially synchronized transmission with 8 forward gears and 4 reverse gears, giving drivers good control over speed and power. Under the hood, the CaseIH 395 has a Case International D-155 engine. This diesel engine has 3 cylinders and is liquid-cooled. It produces 46 hp at 2200 rpm, which is average power for its class. The engine size is also about average compared to other tractors. The tractor weighs 4869 lb, which is typical for a utility tractor. It has a three-point hitch at the back, which can handle category I or II implements. The open operator station comes with a roll-over protection system (ROPS) for safety.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | 395 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 4,869lb |
Engine
| Make | Case International |
|---|---|
| Model | D-155 |
| Power | 46hp |
| Cylinders | 3 |
| Displacement | 155ci |
| Bore | 3.87in |
| Stroke | 4.37in |
Transmission
| Type | Partially Synchronized |
|---|---|
| Forward gears | 8 |
| Reverse gears | 4 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
| Cab | Open (with ROPS) |
Hydraulics
| Type | Open center |
|---|
Dimensions
| Length | 136in |
|---|---|
| Operating weight | 4,869lb |
Capacities
| Cooling system | 3gal |
|---|
Head to head
395 vs. Utility median
How the CaseIH 395 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 46 hp | 55 hp | -16% | 40th |
| Engine Displacement | 155 ci | 183 ci | -15% | 42nd |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 4,869 lb | 5,303 lb | -8% | 46th |
| Length | 136 in | 137 in | 0% | 49th |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 4,659–5,720 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH Farmall 50C | 45.6 hp | 3,869 lb | — | Compare → |
| CaseIH D45 | 45 hp | 3,200 lb | — | Compare → |
| CaseIH DX45 | 45 hp | 3,417 lb | — | Compare → |
| CaseIH Farmall 45 | 45 hp | 3,454 lb | — | Compare → |
| CaseIH Farmall 45A | 45 hp | 3,527 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST60A | 46.4 hp | 4,078 lb | — | Compare → |
| Ag King AK4540 | 45 hp | 4,650 lb | — | Compare → |
| Apollo 454 | 45 hp | 4,365 lb | — | Compare → |
| Ascot Universal 445 | 45 hp | 4,500 lb | — | Compare → |
| Barreiros 5000 VR | 45 hp | 4,080 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH 395 photos
FAQ
Common questions
What is the engine power output of the CaseIH 395?
Rated engine output for the CaseIH 395 is 46 hp, delivered by a 3-cylinder engine. The engine displaces 155 ci.
What hitch category is the CaseIH 395?
The CaseIH 395 uses a Category I/II hitch.
What is the operating weight of the CaseIH 395?
In working trim, the CaseIH 395 comes in at roughly 4,869 lb.
Which transmission does the CaseIH 395 use?
The CaseIH 395 is equipped with a Partially Synchronized transmission with 8 forward gears.
What type of hydraulic system does the CaseIH 395 use?
Hydraulics on the CaseIH 395 are Open center.
How do I maintain a CaseIH 395?
Routine service for the CaseIH 395 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
