CaseIH C42
The CaseIH C42 is a compact 2WD tractor designed for small farm tasks. It features a 4x2 chassis and hydrostatic power steering, making it easy to maneuver. The tractor has a synchro transmission with 16 forward gears and 8 reverse gears, giving the operator plenty of options for different jobs. Under the hood, the C42 is powered by a Steyr WD308 diesel engine. This 3-cylinder engine has a displacement of 143.8 cubic inches and runs at 2400 RPM. It produces 42 horsepower, which is suitable for light to medium farm work. The tractor rides on agricultural tires, with options for 7.50 or 8.3-inch wide front tires. It measures 139 inches long and 90.2 inches tall, with an operating weight of 5204 pounds.
ManufacturerCaseIHPower42 hpEngine3-cylTransSynchro
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 42hp
- Operating Weight
- 5,204 lb
- Transmission
- Synchro
At a glance
How the C42 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
42 hp · 80th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The C42 ranks at the 80th percentile for engine power among recorded sub-compact tractors.
Overview
About the CaseIH C42
The CaseIH C42 is a compact 2WD tractor designed for small farm tasks. It features a 4x2 chassis and hydrostatic power steering, making it easy to maneuver. The tractor has a synchro transmission with 16 forward gears and 8 reverse gears, giving the operator plenty of options for different jobs. Under the hood, the C42 is powered by a Steyr WD308 diesel engine. This 3-cylinder engine has a displacement of 143.8 cubic inches and runs at 2400 RPM. It produces 42 horsepower, which is suitable for light to medium farm work. The tractor rides on agricultural tires, with options for 7.50 or 8.3-inch wide front tires. It measures 139 inches long and 90.2 inches tall, with an operating weight of 5204 pounds.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | C42 |
| Category | Sub-Compact tractor |
| Type | 4x2 2WD |
| Operating weight | 5,204lb |
Engine
| Make | Steyr |
|---|---|
| Model | WD308 |
| Power | 42hp |
| Cylinders | 3 |
| Displacement | 143.8ci |
| Bore | 3.94in |
| Stroke | 3.94in |
Transmission
| Type | Synchro |
|---|---|
| Forward gears | 16 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Hydrostatic power |
Dimensions
| Length | 139in |
|---|---|
| Height | 90.2in |
| Operating weight | 5,204lb |
Tires
| Rear | 12.4 |
|---|
Head to head
C42 vs. Sub-Compact median
How the CaseIH C42 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 42 hp | 26.9 hp | +56% | 80th |
| Engine Displacement | 144 ci | 91.4 ci | +57% | 82nd |
| Cylinders | 3 | 3 | at median | 50th |
| Forward Gears | 16 | 9 | +78% | 89th |
| Operating Weight | 5,204 lb | 2,700 lb | +93% | 94th |
| Length | 139 in | 113 in | +23% | 92nd |
| Height | 90.2 in | 78.4 in | +15% | 76th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 616–816 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH Farmall 40 | 40 hp | 3,252 lb | — | Compare → |
| CaseIH C48 | 48 hp | 5,248 lb | — | Compare → |
| CaseIH CS 48 | 48 hp | 5,976 lb | — | Compare → |
| CaseIH DX33 | 33 hp | — | — | Compare → |
| CaseIH Farmall 31 | 31 hp | 2,511 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers ED40 | 41 hp | 3,527 lb | — | Compare → |
| AGCO ST40 | 40.1 hp | 3,323 lb | — | Compare → |
| AGCO ST41A | 40.1 hp | 3,000 lb | — | Compare → |
| Advance-Rumely OilPull K 12/20 | 40 hp | 6,430 lb | — | Compare → |
| Allis Chalmers 160 | 40 hp | 4,674 lb | 1970–1975 | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH C42 photos
FAQ
Common questions
How much horsepower does the CaseIH C42 have?
The CaseIH C42 produces 42 hp from its 3-cylinder engine. Engine displacement is 143.8 ci.
How much does the CaseIH C42 weigh?
The CaseIH C42 weighs about 5,204 lb in operating condition.
What transmission is in the CaseIH C42?
Transmission on the CaseIH C42 is Synchro, with 16 forward speeds.
What size tires does the CaseIH C42 use?
Factory rubber for the CaseIH C42 is 12.4 rear tires.
What maintenance does the CaseIH C42 require?
Like any tractor, the CaseIH C42 needs periodic engine oil and filter changes, hydraulic fluid checks, and regular greasing and inspection. The owner's manual lists the manufacturer's recommended service intervals.
