Sub-CompactPerformance profile
CaseIH DX33
The CaseIH DX33 is a compact but powerful tractor designed for various farming tasks. It features a 4x4 MFWD (Mechanical Front Wheel Drive) chassis, making it suitable for work in different terrains. The tractor is equipped with a hydrostatic transmission, which allows for smooth and easy operation with infinite forward and reverse gears. Under the hood, the DX33 boasts a Shibaura engine with 3 cylinders and a displacement of 91.3 cubic inches. This liquid-cooled diesel engine produces 33 horsepower at 2800 RPM, providing enough power for most small to medium-sized farm jobs. The tractor comes with a 12-volt electrical system and an electric starter for easy ignition. It also features a dual-element air cleaner and glow plugs for improved performance and cold-weather starting. For attaching implements, the CaseIH DX33 is equipped with a Category I three-point hitch, making it compatible with a wide range of farm tools. This versatile tractor is ideal for farmers looking for a reliable and efficient machine for their daily operations.
ManufacturerCaseIHPower33 hpEngine3-cylTransHydrostatic
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 33hp
- Transmission
- Hydrostatic
At a glance
How the DX33 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
33 hp · 61st
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The DX33 ranks at the 61st percentile for engine power among recorded sub-compact tractors.
Overview
About the CaseIH DX33
The CaseIH DX33 is a compact but powerful tractor designed for various farming tasks. It features a 4x4 MFWD (Mechanical Front Wheel Drive) chassis, making it suitable for work in different terrains. The tractor is equipped with a hydrostatic transmission, which allows for smooth and easy operation with infinite forward and reverse gears. Under the hood, the DX33 boasts a Shibaura engine with 3 cylinders and a displacement of 91.3 cubic inches. This liquid-cooled diesel engine produces 33 horsepower at 2800 RPM, providing enough power for most small to medium-sized farm jobs. The tractor comes with a 12-volt electrical system and an electric starter for easy ignition. It also features a dual-element air cleaner and glow plugs for improved performance and cold-weather starting. For attaching implements, the CaseIH DX33 is equipped with a Category I three-point hitch, making it compatible with a wide range of farm tools. This versatile tractor is ideal for farmers looking for a reliable and efficient machine for their daily operations.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | DX33 |
| Category | Sub-Compact tractor |
| Type | 4x4 MFWD 4WD |
Engine
| Make | Shibaura |
|---|---|
| Power | 33hp |
| Cylinders | 3 |
| Displacement | 91.3ci |
Transmission
| Type | Hydrostatic |
|---|
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
Head to head
DX33 vs. Sub-Compact median
How the CaseIH DX33 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 33 hp | 26.9 hp | +23% | 61st |
| Engine Displacement | 91.3 ci | 91.4 ci | 0% | 49th |
| Cylinders | 3 | 3 | at median | 50th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 757–816 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH Farmall 31 | 31 hp | 2,511 lb | — | Compare → |
| CaseIH D29 | 29 hp | — | — | Compare → |
| CaseIH 1140 | 27 hp | 2,060 lb | — | Compare → |
| CaseIH Farmall 40 | 40 hp | 3,252 lb | — | Compare → |
| CaseIH D25 | 25 hp | — | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST32 | 33 hp | 2,642 lb | — | Compare → |
| AGCO ST33A | 33 hp | 2,400 lb | — | Compare → |
| AGCO ST34A | 33 hp | 3,000 lb | — | Compare → |
| AGCO ST35 | 33 hp | 3,168 lb | — | Compare → |
| Allis Chalmers U | 34.12 hp | 5,030 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH DX33 photos
FAQ
Common questions
What is the engine power output of the CaseIH DX33?
Rated engine output for the CaseIH DX33 is 33 hp, delivered by a 3-cylinder engine. The engine displaces 91.3 ci.
Which transmission does the CaseIH DX33 use?
The CaseIH DX33 is equipped with a Hydrostatic transmission.
What three-point hitch category does the CaseIH DX33 use?
The CaseIH DX33 has a Category I three-point hitch.
How do I maintain a CaseIH DX33?
Routine service for the CaseIH DX33 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
