Row CropPerformance profile
CaseIH Farmall 105V
The CaseIH Farmall 105V is a powerful 4WD tractor built for tough farm work. It has a strong FPT engine with 106 horsepower, which is plenty for most farming tasks. The engine has 4 cylinders and uses diesel fuel. It's turbocharged and intercooled, which helps it run better. This tractor has a mechanical shuttle transmission with 32 forward gears and 16 reverse gears. This gives the driver lots of options for different speeds. The Farmall 105V has hydrostatic power steering, making it easy to control. It weighs 5,979 pounds and is 42.5 inches wide, so it can fit in tight spaces. The tractor has ag tires in front and back, which are good for farm use. It also has a Category II hitch, useful for attaching many farm tools.
ManufacturerCaseIHPower106 hpEngine4-cylTransMechanical Shuttle
Quick specs
- Category
- Row Crop
- Engine Power Output
- 106hp
- Operating Weight
- 5,979 lb
- Transmission
- Mechanical Shuttle
At a glance
How the Farmall 105V compares
vs. Row Crop medianDistribution
Engine Power (hp)
Across all Row Crop tractors
106 hp · 29th
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The Farmall 105V ranks at the 29th percentile for engine power among recorded row crop tractors.
Overview
About the CaseIH Farmall 105V
The CaseIH Farmall 105V is a powerful 4WD tractor built for tough farm work. It has a strong FPT engine with 106 horsepower, which is plenty for most farming tasks. The engine has 4 cylinders and uses diesel fuel. It's turbocharged and intercooled, which helps it run better. This tractor has a mechanical shuttle transmission with 32 forward gears and 16 reverse gears. This gives the driver lots of options for different speeds. The Farmall 105V has hydrostatic power steering, making it easy to control. It weighs 5,979 pounds and is 42.5 inches wide, so it can fit in tight spaces. The tractor has ag tires in front and back, which are good for farm use. It also has a Category II hitch, useful for attaching many farm tools.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | Farmall 105V |
| Category | Row Crop tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 5,979lb |
Engine
| Make | FPT |
|---|---|
| Power | 106hp |
| Cylinders | 4 |
| Displacement | 274ci |
| Bore | 4.1in |
| Stroke | 5.2in |
Transmission
| Type | Mechanical Shuttle |
|---|---|
| Forward gears | 32 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | 4WD |
| Steering | Hydrostatic Power |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Width | 42.5in |
|---|---|
| Operating weight | 5,979lb |
Head to head
Farmall 105V vs. Row Crop median
How the CaseIH Farmall 105V compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 106 hp | 138 hp | -23% | 29th |
| Engine Displacement | 274 ci | 391 ci | -30% | 24th |
| Cylinders | 4 | 6 | -33% | 17th |
| Forward Gears | 32 | 16 | +100% | 91st |
| Operating Weight | 5,979 lb | 12,307 lb | -51% | 12th |
| Width | 42.5 in | 91.2 in | -53% | 1st |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 806–1,417 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH 5130 | 105 hp | 9,458 lb | 1990–1997 | Compare → |
| CaseIH CS 110 | 108.5 hp | 11,056 lb | — | Compare → |
| CaseIH Maxxum 110 | 110 hp | 10,240 lb | — | Compare → |
| CaseIH 1694 | 112 hp | 9,580 lb | — | Compare → |
| CaseIH Farmall 100C | 99 hp | 6,989 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Allis Chalmers 7010 | 105.77 hp | 11,260 lb | 1980–1981 | Compare → |
| Belarus 1052 | 105 hp | 7,209 lb | — | Compare → |
| Allis Chalmers D21 Series I | 103 hp | 9,500 lb | 1963–1965 | Compare → |
| AGCO LT90A | 110 hp | 8,820 lb | — | Compare → |
| Agrinar T-110 | 110 hp | — | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH Farmall 105V photos
FAQ
Common questions
What is the engine power output of the CaseIH Farmall 105V?
Rated engine output for the CaseIH Farmall 105V is 106 hp, delivered by a 4-cylinder engine. The engine displaces 274 ci.
What is the operating weight of the CaseIH Farmall 105V?
In working trim, the CaseIH Farmall 105V comes in at roughly 5,979 lb.
Which transmission does the CaseIH Farmall 105V use?
The CaseIH Farmall 105V is equipped with a Mechanical Shuttle transmission with 32 forward gears.
What hydraulics does the CaseIH Farmall 105V have?
The CaseIH Farmall 105V uses an Open Center hydraulic system.
What three-point hitch category does the CaseIH Farmall 105V use?
The CaseIH Farmall 105V has a Category II three-point hitch.
How do I maintain a CaseIH Farmall 105V?
Routine service for the CaseIH Farmall 105V covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
