CaseIH Farmall 45C Series II
The CaseIH Farmall 45C Series II is a versatile utility tractor designed for various farm tasks. It features a four-wheel drive system and power steering, making it easy to handle in different conditions. The tractor has a 16-speed transmission with 16 forward and 16 reverse gears, giving the operator plenty of options for different jobs. Under the hood, this Farmall model has a LS Mtron L3C19-T engine. It's a 3-cylinder, turbocharged diesel engine that's liquid-cooled for better performance. The engine puts out 45 horsepower, which is about average for tractors in its class. It meets Tier IV emissions standards, using exhaust gas recirculation with DOC and DPF to keep pollution low. The tractor has a compact size, measuring 69.1 inches wide and 98.4 inches tall, with a weight of 3,770 pounds. It comes with standard agricultural tires, a Category I rear hitch, and an open center hydraulic system. For safety, it's equipped with a ROPS (Roll-Over Protective Structure) operator station.
ManufacturerCaseIHPower45 hpEngine3-cylTransMechanical Shuttle
Quick specs
- Category
- Utility
- Engine Power Output
- 45hp
- Operating Weight
- 3,770 lb
- Transmission
- Mechanical Shuttle
At a glance
How the Farmall 45C Series II compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
45 hp · 39th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The Farmall 45C Series II ranks at the 39th percentile for engine power among recorded utility tractors.
Overview
About the CaseIH Farmall 45C Series II
The CaseIH Farmall 45C Series II is a versatile utility tractor designed for various farm tasks. It features a four-wheel drive system and power steering, making it easy to handle in different conditions. The tractor has a 16-speed transmission with 16 forward and 16 reverse gears, giving the operator plenty of options for different jobs. Under the hood, this Farmall model has a LS Mtron L3C19-T engine. It's a 3-cylinder, turbocharged diesel engine that's liquid-cooled for better performance. The engine puts out 45 horsepower, which is about average for tractors in its class. It meets Tier IV emissions standards, using exhaust gas recirculation with DOC and DPF to keep pollution low. The tractor has a compact size, measuring 69.1 inches wide and 98.4 inches tall, with a weight of 3,770 pounds. It comes with standard agricultural tires, a Category I rear hitch, and an open center hydraulic system. For safety, it's equipped with a ROPS (Roll-Over Protective Structure) operator station.
Full specifications
Every recorded spec
General
| Manufacturer | CaseIH |
|---|---|
| Model | Farmall 45C Series II |
| Category | Utility tractor |
| Type | 4x4 MFWD 4WD |
| Operating weight | 3,770lb |
Engine
| Make | LS Mtron |
|---|---|
| Model | L3C19-T |
| Power | 45hp |
| Cylinders | 3 |
| Displacement | 115ci |
| Bore | 3.47in |
| Stroke | 4.06in |
Transmission
| Type | Mechanical Shuttle |
|---|---|
| Forward gears | 16 |
| Reverse gears | 16 |
Chassis & drive
| Chassis | 4x4 MFWD 4WD |
|---|---|
| Drive | Four-Wheel Drive (4WD) |
| Steering | Power |
| Cab | ROPS |
Hydraulics
| Type | Open Center |
|---|
Dimensions
| Width | 69.1in |
|---|---|
| Height | 98.4in |
| Operating weight | 3,770lb |
Head to head
Farmall 45C Series II vs. Utility median
How the CaseIH Farmall 45C Series II compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 45 hp | 55 hp | -18% | 39th |
| Engine Displacement | 115 ci | 183 ci | -37% | 28th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 16 | 12 | +33% | 73rd |
| Operating Weight | 3,770 lb | 5,303 lb | -29% | 33rd |
| Width | 69.1 in | 66 in | +5% | 58th |
| Height | 98.4 in | 94.1 in | +5% | 62nd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared CaseIH tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| CaseIH D45 | 45 hp | 3,200 lb | — | Compare → |
| CaseIH DX45 | 45 hp | 3,417 lb | — | Compare → |
| CaseIH Farmall 45 | 45 hp | 3,454 lb | — | Compare → |
| CaseIH Farmall 45A | 45 hp | 3,527 lb | — | Compare → |
| CaseIH Farmall 50C | 45.6 hp | 3,869 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Ag King AK4540 | 45 hp | 4,650 lb | — | Compare → |
| Apollo 454 | 45 hp | 4,365 lb | — | Compare → |
| Ascot Universal 445 | 45 hp | 4,500 lb | — | Compare → |
| Barreiros 5000 VR | 45 hp | 4,080 lb | — | Compare → |
| AGCO ST45 | 44.2 hp | 4,448 lb | — | Compare → |
Explore
CaseIH siblings
Explore
Similar-spec models
Gallery
CaseIH Farmall 45C Series II photos
FAQ
Common questions
How powerful is the CaseIH Farmall 45C Series II?
The CaseIH Farmall 45C Series II has an engine power output of 45 hp. It is powered by a 3-cylinder engine displacing 115 ci.
What type of transmission does the CaseIH Farmall 45C Series II have?
The CaseIH Farmall 45C Series II uses a Mechanical Shuttle transmission offering 16 forward gears.
What type of hydraulic system does the CaseIH Farmall 45C Series II use?
Hydraulics on the CaseIH Farmall 45C Series II are Open Center.
What hitch category is the CaseIH Farmall 45C Series II?
The CaseIH Farmall 45C Series II uses a Category I hitch.
What is the working weight of the CaseIH Farmall 45C Series II?
The operating weight of the CaseIH Farmall 45C Series II is approximately 3,770 lb.
What routine service does the CaseIH Farmall 45C Series II need?
Regular maintenance for the CaseIH Farmall 45C Series II includes checking and changing engine oil, hydraulic fluid, and filters, plus routine inspections as recommended in the owner's manual. Always follow the manufacturer's maintenance schedule for specific intervals and procedures.
