CaseIH Steiger 400 Rowtrac
The CaseIH Steiger 400 Rowtrac is a powerful row crop tractor built for big farms. It has a strong engine made by FPT that runs on diesel fuel. This engine has 6 cylinders and can produce 400 horsepower, which is very high compared to most tractors. The tractor is big, measuring 315 inches long and 151.3 inches tall. It's also very heavy, weighing 55,785 pounds, which is more than most other tractors. This tractor has some special features that make it work well in fields. It has a full power shift transmission with 16 forward gears and 2 reverse gears. This helps the driver change speeds easily. The Steiger 400 Rowtrac also has a good hydraulic system and a comfortable cab for the operator. It uses special technology to control emissions and can reach up to 440 horsepower when needed. The engine is cooled by liquid and has a fan to keep it from getting too hot.

Key specifications
- Category
- Row Crop
- Engine power
- 400hp
- Operating weight
- 55,785 lb
- Transmission
- Full power shift
Category comparison
Steiger 400 Rowtrac compared with its category
vs. Row Crop medianDistribution
Engine Power (hp)
All recorded Row Crop tractors
This model
The Steiger 400 Rowtrac ranks at the 98th percentile for engine power among recorded row crop tractors.
Overview
About the CaseIH Steiger 400 Rowtrac
The CaseIH Steiger 400 Rowtrac is a powerful row crop tractor built for big farms. It has a strong engine made by FPT that runs on diesel fuel. This engine has 6 cylinders and can produce 400 horsepower, which is very high compared to most tractors. The tractor is big, measuring 315 inches long and 151.3 inches tall. It's also very heavy, weighing 55,785 pounds, which is more than most other tractors. This tractor has some special features that make it work well in fields. It has a full power shift transmission with 16 forward gears and 2 reverse gears. This helps the driver change speeds easily. The Steiger 400 Rowtrac also has a good hydraulic system and a comfortable cab for the operator. It uses special technology to control emissions and can reach up to 440 horsepower when needed. The engine is cooled by liquid and has a fan to keep it from getting too hot.
Full specifications
Recorded specifications
General
| Manufacturer | CaseIH |
|---|---|
| Model | Steiger 400 Rowtrac |
| Category | Row Crop tractor |
| Operating weight | 55,785lb(25,300 kg) |
Engine
| Make | FPT |
|---|---|
| Power | 400hp(298.3 kW) |
| Cylinders | 6 |
| Displacement | 787ci(12.9 L) |
| Bore | 5.32in(135 mm) |
| Stroke | 5.91in(150 mm) |
Transmission
| Type | Full power shift |
|---|---|
| Forward gears | 16 |
| Reverse gears | 2 |
Chassis & drive
| Brakes | Electro-hydraulic wet disc |
|---|---|
| Cab | Cab |
Hydraulics
| Type | Pressure flow compensated |
|---|
Dimensions
| Length | 315in(8,001 mm) |
|---|---|
| Height | 151.3in(3,843 mm) |
| Operating weight | 55,785lb(25,300 kg) |
Closest alternatives
Steiger 400 Rowtrac compared with the nearest models by horsepower
The closest row crop models to the CaseIH Steiger 400 Rowtrac by rated horsepower are the Massey Ferguson 8740S and the John Deere 8400R. The Massey Ferguson 8740S matches it on rated power and weighs 31,980 lb less, so it is lighter for its power, which favors PTO and transport work over heavy draft. The John Deere 8400R matches it on rated power and weighs 23,090 lb less, carrying 82 lb per horsepower against 139 lb. Of the 3 models, the Steiger 400 Rowtrac has the highest weight per horsepower at 139 lb per hp.
| Spec | CaseIH Steiger 400 Rowtrac | Massey Ferguson 8740S | John Deere 8400R |
|---|---|---|---|
| Engine power | 400 hp298.3 kW | 400 hp298.3 kW | 400 hp298.3 kW |
| Operating weight | 55,785 lb25,304 kg | 23,810 lb10,800 kg | 32,691 lb14,828 kg |
| Weight per hp | 139 lb/hp85 kg/kW | 60 lb/hp36 kg/kW | 82 lb/hp50 kg/kW |
| Displacement | 787 ci12.9 L | 512.6 ci8.4 L | 548 ci8.98 L |
| Cylinders | 6 | 6 | 6 |
| Transmission | Full power shift | Continuously-variable transmission (CVT) | Full power shift |
| Drive | - | 4WD | MFWD - Mechanical Front Wheel Drive |
| Years built | - | 2018+ | 2016-2019 |
Calculators
Calculators for the Steiger 400 Rowtrac
PTO power
About 332 to 360 PTO hp
Estimated from the 400 hp engine rating. The calculator also estimates drawbar power by surface.
Implement sizing
Implements a 400 hp tractor can run
Maximum size is about a 47.5 ft rotary cutter or a 40.5 ft tiller. The calculator also sizes discs, plows and balers.
Ballast
162 lb per PTO hp as listed
The calculator gives the target weight and front/rear split for each job.
Units
400 hp is 298.3 kW
The converter gives kW and metric PS values, as used on European spec sheets.
Parts and manuals
Parts and manuals for the CaseIH Steiger 400 Rowtrac
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the FPTAmazon
Fits the FPT 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the FPTAmazon
Fits the FPT 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the FPTAmazon
Fits the FPT 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the FPTAmazon
Fits the FPT 6-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- CaseIH Steiger 400 Rowtrac service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- CaseIH Steiger 400 Rowtrac operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- CaseIH Steiger 400 Rowtrac service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
Steiger 400 Rowtrac vs. Row Crop median
CaseIH Steiger 400 Rowtrac compared with other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 400 hp | 138 hp | +190% | 98th |
| Engine Displacement | 787 ci | 391 ci | +101% | 99th |
| Cylinders | 6 | 6 | at median | 50th |
| Forward Gears | 16 | 16 | at median | 50th |
| Operating Weight | 55,785 lb | 12,307 lb | +353% | 99th |
| Length | 315 in | 180 in | +75% | 99th |
| Height | 151 in | 114 in | +33% | 99th |
Medians and percentiles are calculated from the row crop tractors in the database that have a recorded value for each specification (sample size 1,140–1,417 models).
Same manufacturer
Other CaseIH models
Other manufacturers
Models with similar horsepower
Gallery
CaseIH Steiger 400 Rowtrac photos





FAQ
Frequently asked questions
What is the engine power output of the CaseIH Steiger 400 Rowtrac?
Rated engine output for the CaseIH Steiger 400 Rowtrac is 400 hp, delivered by a 6-cylinder engine. The engine displaces 787 ci.
Which transmission does the CaseIH Steiger 400 Rowtrac use?
The CaseIH Steiger 400 Rowtrac is equipped with a Full power shift transmission with 16 forward gears.
What type of hydraulic system does the CaseIH Steiger 400 Rowtrac use?
Hydraulics on the CaseIH Steiger 400 Rowtrac are Pressure flow compensated.
What is the operating weight of the CaseIH Steiger 400 Rowtrac?
The CaseIH Steiger 400 Rowtrac has an operating weight of about 55,785 lb.
How do I maintain a CaseIH Steiger 400 Rowtrac?
Routine service for the CaseIH Steiger 400 Rowtrac covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
