Caterpillar D7D
The Caterpillar D7D is a powerful tractor built for tough jobs. It has a strong diesel engine made by Caterpillar. This engine has 4 cylinders and is turbocharged, which means it can work hard without getting tired. The engine is liquid-cooled to keep it running smoothly even when it's hot outside. This tractor is big and heavy, weighing 24,330 pounds. It's 162.25 inches long, 97 inches wide, and 80 inches tall. The D7D has a gear transmission with 5 forward gears and 4 reverse gears, giving the driver good control. It uses manual clutches for steering, which is common for tractors of this type. One unique feature is its starter - it uses a small 2-cylinder engine to start the main engine, which is helpful in cold weather.

Key specifications
- Category
- Crawler
- Operating weight
- 24,330 lb
- Transmission
- Gear
Overview
About the Caterpillar D7D
The Caterpillar D7D is a powerful tractor built for tough jobs. It has a strong diesel engine made by Caterpillar. This engine has 4 cylinders and is turbocharged, which means it can work hard without getting tired. The engine is liquid-cooled to keep it running smoothly even when it's hot outside. This tractor is big and heavy, weighing 24,330 pounds. It's 162.25 inches long, 97 inches wide, and 80 inches tall. The D7D has a gear transmission with 5 forward gears and 4 reverse gears, giving the driver good control. It uses manual clutches for steering, which is common for tractors of this type. One unique feature is its starter - it uses a small 2-cylinder engine to start the main engine, which is helpful in cold weather.
Full specifications
Recorded specifications
General
| Manufacturer | Caterpillar |
|---|---|
| Model | D7D |
| Category | Crawler tractor |
| Operating weight | 24,330lb(11,040 kg) |
Engine
| Make | Caterpillar |
|---|---|
| Cylinders | 4 |
| Displacement | 831ci(13.62 L) |
| Bore | 5.75in(146 mm) |
| Stroke | 8in(203.2 mm) |
Transmission
| Type | Gear |
|---|---|
| Forward gears | 5 |
| Reverse gears | 4 |
Chassis & drive
| Steering | Manual clutches |
|---|
Dimensions
| Length | 162.25in(4,121 mm) |
|---|---|
| Width | 97in(2,464 mm) |
| Height | 80in(2,032 mm) |
| Operating weight | 24,330lb(11,040 kg) |
Parts and manuals
Parts and manuals for the Caterpillar D7D
Each link opens a retailer search keyed to the fields recorded for this model. Confirm fitment against the serial plate before ordering.
Filters
- Oil filter for the CaterpillarAmazon
Fits the Caterpillar 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Air filter for the CaterpillarAmazon
Fits the Caterpillar 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Fuel filter for the CaterpillarAmazon
Fits the Caterpillar 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
- Hydraulic filter for the CaterpillarAmazon
Fits the Caterpillar 4-cylinder diesel engine listed for this model. Confirm the part number against the engine serial plate.
Manuals
- Caterpillar D7D service and repair manualseManualOnline
Digital manuals. Check the serial number range on the listing.
- Caterpillar D7D operator's manualAmazon
Printed and reprint manuals. Check the serial number range on the listing.
- Caterpillar D7D service manualAmazon
Shop and repair manuals for this model.
Links in this section go to retailers. A purchase through them earns this site a commission at no extra cost to the buyer. As an Amazon Associate, Heavy Equipment Specs earns from qualifying purchases. Affiliate disclosure
Category medians
D7D vs. Crawler median
Caterpillar D7D compared with other Crawler tractors
| Spec | This model | Crawler median | Difference | Percentile |
|---|---|---|---|---|
| Engine Displacement | 831 ci | 468 ci | +78% | 88th |
| Cylinders | 4 | 6 | -33% | 33rd |
| Forward Gears | 5 | 10 | -50% | 25th |
| Operating Weight | 24,330 lb | 23,320 lb | +4% | 52nd |
| Length | 162 in | 146 in | +11% | 56th |
| Width | 97 in | 79.5 in | +22% | 65th |
| Height | 80 in | 90.6 in | -12% | 38th |
Medians and percentiles are calculated from the crawler tractors in the database that have a recorded value for each specification (sample size 134–192 models).
Same manufacturer
Other Caterpillar models
Other manufacturers
Models with similar horsepower
Gallery
Caterpillar D7D photos




FAQ
Frequently asked questions
How many cylinders does the Caterpillar D7D have?
The Caterpillar D7D runs a 4-cylinder engine with a displacement of 831 ci.
Which transmission does the Caterpillar D7D use?
The Caterpillar D7D is equipped with a Gear transmission with 5 forward gears.
What is the operating weight of the Caterpillar D7D?
The Caterpillar D7D has an operating weight of about 24,330 lb.
How do I maintain a Caterpillar D7D?
Routine service for the Caterpillar D7D covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
