Farmtrac 520
The Farmtrac 520 is a utility tractor built for various farming tasks. It has a 2-wheel drive system and a shuttle transmission with 8 forward and 8 reverse gears. The tractor is powered by a 3-cylinder diesel engine made by Escorts. This engine is liquid-cooled and naturally aspirated, producing 52 horsepower. The engine's size and power are about average compared to other tractors. This tractor is compact, measuring 137 inches long, 70 inches wide, and 95 inches tall. It weighs 4,220 pounds, which is also average for its class. The Farmtrac 520 has different tire options for various terrains, including agriculture, lawn/turf, and industrial use. It features a Category II/I hitch, making it versatile for attaching different implements. The tractor starts with a 12-volt electric starter, making it easy to use in cold weather.
ManufacturerFarmtracPower52 hpEngine3-cylTransShuttle, partial synchromesh
Quick specs
- Category
- Utility
- Engine Power Output
- 52hp
- Operating Weight
- 4,220 lb
- Transmission
- Shuttle, partial synchromesh
At a glance
How the 520 compares
vs. Utility medianDistribution
Engine Power (hp)
Across all Utility tractors
52 hp · 47th
This model
9
Median 55 hp
177
This modelUtility tractorsMediann = 5,383
The 520 ranks at the 47th percentile for engine power among recorded utility tractors.
Overview
About the Farmtrac 520
The Farmtrac 520 is a utility tractor built for various farming tasks. It has a 2-wheel drive system and a shuttle transmission with 8 forward and 8 reverse gears. The tractor is powered by a 3-cylinder diesel engine made by Escorts. This engine is liquid-cooled and naturally aspirated, producing 52 horsepower. The engine's size and power are about average compared to other tractors. This tractor is compact, measuring 137 inches long, 70 inches wide, and 95 inches tall. It weighs 4,220 pounds, which is also average for its class. The Farmtrac 520 has different tire options for various terrains, including agriculture, lawn/turf, and industrial use. It features a Category II/I hitch, making it versatile for attaching different implements. The tractor starts with a 12-volt electric starter, making it easy to use in cold weather.
Full specifications
Every recorded spec
General
| Manufacturer | Farmtrac |
|---|---|
| Model | 520 |
| Category | Utility tractor |
| Type | 4x2 2WD |
| Operating weight | 4,220lb |
Engine
| Make | Escorts |
|---|---|
| Power | 52hp |
| Cylinders | 3 |
| Displacement | 172ci |
Transmission
| Type | Shuttle, partial synchromesh |
|---|---|
| Forward gears | 8 |
| Reverse gears | 8 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
Dimensions
| Length | 137in |
|---|---|
| Width | 70in |
| Height | 95in |
| Operating weight | 4,220lb |
Tires
| Front | 7.5-16 |
|---|---|
| Rear | 14.9-28 |
Head to head
520 vs. Utility median
How the Farmtrac 520 compares to other Utility tractors
| Spec | This model | Utility median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 52 hp | 55 hp | -5% | 47th |
| Engine Displacement | 172 ci | 183 ci | -6% | 46th |
| Cylinders | 3 | 4 | -25% | 23rd |
| Forward Gears | 8 | 12 | -33% | 23rd |
| Operating Weight | 4,220 lb | 5,303 lb | -20% | 40th |
| Length | 137 in | 137 in | 0% | 50th |
| Width | 70 in | 66 in | +6% | 61st |
| Height | 95 in | 94.1 in | +1% | 52nd |
Medians and percentiles are computed from the utility tractors in our database with a recorded value for each spec (sample sizes 3,933–5,720 models).
Compare to tractors with similar specs
Commonly compared Farmtrac tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Farmtrac 555 | 50 hp | 4,510 lb | — | Compare → |
| Farmtrac 60 | 49.7 hp | 4,519 lb | 2003–2003 | Compare → |
| Farmtrac 550DTC | 55 hp | 4,610 lb | — | Compare → |
| Farmtrac 450DTC | 45 hp | 4,440 lb | — | Compare → |
| Farmtrac 665 | 60 hp | 5,050 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO GT45 | 52 hp | 4,806 lb | — | Compare → |
| Agco GT45A | 52 hp | 5,820.3 lb | — | Compare → |
| Barreiros 50.55 | 52 hp | 5,100 lb | — | Compare → |
| Barreiros R-500 | 52 hp | — | — | Compare → |
| Agco ST52a | 52.1 hp | 3,494.4 lb | — | Compare → |
Explore
Farmtrac siblings
Explore
Similar-spec models
Gallery
Farmtrac 520 photos
FAQ
Common questions
What is the engine power output of the Farmtrac 520?
Rated engine output for the Farmtrac 520 is 52 hp, delivered by a 3-cylinder engine. The engine displaces 172 ci.
What is the operating weight of the Farmtrac 520?
In working trim, the Farmtrac 520 comes in at roughly 4,220 lb.
Which transmission does the Farmtrac 520 use?
The Farmtrac 520 is equipped with a Shuttle, partial synchromesh transmission with 8 forward gears.
What are the factory tire sizes for the Farmtrac 520?
The Farmtrac 520 comes with 7.5-16 front tires and 14.9-28 rear tires.
What three-point hitch category does the Farmtrac 520 use?
The Farmtrac 520 has a Category II/I three-point hitch.
How do I maintain a Farmtrac 520?
Routine service for the Farmtrac 520 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
