Row CropPerformance profile
Hurlimann H-490
The Hurlimann H-490 is a row crop tractor built for farm work. It has a 2WD setup with power steering, making it easy to control in the fields. The tractor uses a manual transmission with 12 forward gears and 3 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the H-490 has a SAME diesel engine with 4 cylinders. The engine is naturally aspirated and liquid-cooled, which helps it run smoothly. It produces 95 hp at 2300 rpm, offering average power for its class. The tractor's size is compact, measuring 166.5 inches long and 110.2 inches tall. It weighs 9040 lb, which is on the lighter side for tractors. The H-490 rides on agricultural tires, with 9.00-16 in the front and larger 18.4-34 in the rear, providing good traction in farm conditions.
ManufacturerHurlimannPower95 hpEngine4-cylTransManual
Quick specs
- Category
- Row Crop
- Engine Power Output
- 95hp
- Operating Weight
- 9,040 lb
- Transmission
- Manual
At a glance
How the H-490 compares
vs. Row Crop medianDistribution
Engine Power (hp)
Across all Row Crop tractors
95 hp · 21st
This model
12
Median 138 hp
283
This modelRow Crop tractorsMediann = 1,206
The H-490 ranks at the 21st percentile for engine power among recorded row crop tractors.
Overview
About the Hurlimann H-490
The Hurlimann H-490 is a row crop tractor built for farm work. It has a 2WD setup with power steering, making it easy to control in the fields. The tractor uses a manual transmission with 12 forward gears and 3 reverse gears, giving farmers plenty of options for different tasks. Under the hood, the H-490 has a SAME diesel engine with 4 cylinders. The engine is naturally aspirated and liquid-cooled, which helps it run smoothly. It produces 95 hp at 2300 rpm, offering average power for its class. The tractor's size is compact, measuring 166.5 inches long and 110.2 inches tall. It weighs 9040 lb, which is on the lighter side for tractors. The H-490 rides on agricultural tires, with 9.00-16 in the front and larger 18.4-34 in the rear, providing good traction in farm conditions.
Full specifications
Every recorded spec
General
| Manufacturer | Hurlimann |
|---|---|
| Model | H-490 |
| Category | Row Crop tractor |
| Type | 4x2 2WD |
| Operating weight | 9,040lb |
Engine
| Make | SAME |
|---|---|
| Power | 95hp |
| Cylinders | 4 |
| Displacement | 278.25ci |
| Bore | 4.33in |
| Stroke | 4.72in |
Transmission
| Type | Manual |
|---|---|
| Forward gears | 12 |
| Reverse gears | 3 |
Chassis & drive
| Chassis | 4x2 2WD |
|---|---|
| Drive | 2WD |
| Steering | Power |
Dimensions
| Length | 166.5in |
|---|---|
| Height | 110.2in |
| Operating weight | 9,040lb |
Tires
| Front | 9.00-16 |
|---|---|
| Rear | 18.4-34 |
Head to head
H-490 vs. Row Crop median
How the Hurlimann H-490 compares to other Row Crop tractors
| Spec | This model | Row Crop median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 95 hp | 138 hp | -31% | 21st |
| Engine Displacement | 278 ci | 391 ci | -29% | 27th |
| Cylinders | 4 | 6 | -33% | 17th |
| Forward Gears | 12 | 16 | -25% | 27th |
| Operating Weight | 9,040 lb | 12,307 lb | -27% | 26th |
| Length | 167 in | 180 in | -7% | 32nd |
| Height | 110 in | 114 in | -3% | 38th |
Medians and percentiles are computed from the row crop tractors in our database with a recorded value for each spec (sample sizes 1,140–1,417 models).
Compare to tractors with similar specs
Commonly compared Hurlimann tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Hurlimann H-6165 Master | 163 hp | 12,853 lb | — | Compare → |
| Hurlimann H-6190 Master | 189 hp | 13,228 lb | — | Compare → |
| Hurlimann 909 XT | 95 hp | 8,555 lb | — | Compare → |
| Hurlimann H-496 | 95 hp | 8,511 lb | — | Compare → |
| Hurlimann H-488T Prestige | 90 hp | 7,938 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Antonio Carraro SRX 10400 | 95 hp | 4,718 lb | — | Compare → |
| Antonio Carraro TGF 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRG 10400 | 95 hp | 5,247 lb | — | Compare → |
| Antonio Carraro TRX 10400 | 95 hp | 4,828 lb | — | Compare → |
| Antonio Carraro TTR 10400 | 95 hp | 4,806 lb | — | Compare → |
Explore
Hurlimann siblings
Explore
Similar-spec models
Gallery
Hurlimann H-490 photos
FAQ
Common questions
What is the engine power output of the Hurlimann H-490?
Rated engine output for the Hurlimann H-490 is 95 hp, delivered by a 4-cylinder engine. The engine displaces 278.25 ci.
Which transmission does the Hurlimann H-490 use?
The Hurlimann H-490 is equipped with a Manual transmission with 12 forward gears.
What size tires does the Hurlimann H-490 use?
Factory rubber for the Hurlimann H-490 is 9.00-16 front tires and 18.4-34 rear tires.
What is the operating weight of the Hurlimann H-490?
In working trim, the Hurlimann H-490 comes in at roughly 9,040 lb.
How do I maintain a Hurlimann H-490?
Routine service for the Hurlimann H-490 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
