Iseki TA417
The Iseki TA417 is a powerful and versatile tractor designed for various farming tasks. It features a strong Isuzu 4JC1 engine with 4 cylinders and 40.4 horsepower. This diesel engine is liquid-cooled, which helps it run smoothly in different weather conditions. The tractor has a 16-speed transmission for both forward and reverse gears, giving the operator lots of control over speed and power. This tractor is built to handle tough jobs on the farm. It has standard agricultural tires in the front and back, which provide good traction in fields. The Iseki TA417 is 129.9 inches long, 59.1 inches wide, and 92.9 inches tall. It weighs 3814 pounds, making it sturdy enough for heavy work. The tractor has a category I hitch, which lets it connect to many different farm tools. It starts easily with an electric starter, saving time and effort for the farmer.
ManufacturerIsekiPower40.4 hpEngine4-cyl
Quick specs
- Category
- Sub-Compact
- Engine Power Output
- 40hp
- Operating Weight
- 3,814 lb
At a glance
How the TA417 compares
vs. Sub-Compact medianDistribution
Engine Power (hp)
Across all Sub-Compact tractors
40.4 hp · 77th
This model
4
Median 26.85 hp
49
This modelSub-Compact tractorsMediann = 816
The TA417 ranks at the 77th percentile for engine power among recorded sub-compact tractors.
Overview
About the Iseki TA417
The Iseki TA417 is a powerful and versatile tractor designed for various farming tasks. It features a strong Isuzu 4JC1 engine with 4 cylinders and 40.4 horsepower. This diesel engine is liquid-cooled, which helps it run smoothly in different weather conditions. The tractor has a 16-speed transmission for both forward and reverse gears, giving the operator lots of control over speed and power. This tractor is built to handle tough jobs on the farm. It has standard agricultural tires in the front and back, which provide good traction in fields. The Iseki TA417 is 129.9 inches long, 59.1 inches wide, and 92.9 inches tall. It weighs 3814 pounds, making it sturdy enough for heavy work. The tractor has a category I hitch, which lets it connect to many different farm tools. It starts easily with an electric starter, saving time and effort for the farmer.
Full specifications
Every recorded spec
General
| Manufacturer | Iseki |
|---|---|
| Model | TA417 |
| Category | Sub-Compact tractor |
| Operating weight | 3,814lb |
Engine
| Make | Isuzu |
|---|---|
| Model | 4JC1 |
| Power | 40.4hp |
| Cylinders | 4 |
| Displacement | 136.6ci |
| Bore | 3.47in |
| Stroke | 3.62in |
Transmission
| Forward gears | 16 |
|---|---|
| Reverse gears | 16 |
Dimensions
| Length | 129.9in |
|---|---|
| Width | 59.1in |
| Height | 92.9in |
| Operating weight | 3,814lb |
Head to head
TA417 vs. Sub-Compact median
How the Iseki TA417 compares to other Sub-Compact tractors
| Spec | This model | Sub-Compact median | Difference | Percentile |
|---|---|---|---|---|
| Engine Power | 40.4 hp | 26.9 hp | +50% | 77th |
| Engine Displacement | 137 ci | 91.4 ci | +49% | 76th |
| Cylinders | 4 | 3 | +33% | 90th |
| Forward Gears | 16 | 9 | +78% | 89th |
| Operating Weight | 3,814 lb | 2,700 lb | +41% | 74th |
| Length | 130 in | 113 in | +15% | 78th |
| Width | 59.1 in | 50.7 in | +17% | 70th |
| Height | 92.9 in | 78.4 in | +18% | 80th |
Medians and percentiles are computed from the sub-compact tractors in our database with a recorded value for each spec (sample sizes 584–816 models).
Compare to tractors with similar specs
Commonly compared Iseki tractors
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| Iseki TK538 | 40.5 hp | 2,679 lb | — | Compare → |
| Iseki TS4010 | 41 hp | — | — | Compare → |
| Iseki TG6405 | 38.5 hp | — | — | Compare → |
| Iseki TA437 | 42.4 hp | 3,428 lb | — | Compare → |
| Iseki TA370 | 37 hp | 3,439 lb | — | Compare → |
Commonly compared tractors with similar horsepower from other brands
| Tractor | Engine Power | Operating Weight | Years | Compare |
|---|---|---|---|---|
| AGCO ST40 | 40.1 hp | 3,323 lb | — | Compare → |
| AGCO ST41A | 40.1 hp | 3,000 lb | — | Compare → |
| Advance-Rumely OilPull K 12/20 | 40 hp | 6,430 lb | — | Compare → |
| Allis Chalmers 160 | 40 hp | 4,674 lb | 1970–1975 | Compare → |
| Allis Chalmers 5040 | 40 hp | 3,858 lb | 1976–1980 | Compare → |
Explore
Iseki siblings
Explore
Similar-spec models
Gallery
Iseki TA417 photos
FAQ
Common questions
What is the engine power output of the Iseki TA417?
Rated engine output for the Iseki TA417 is 40.4 hp, delivered by a 4-cylinder engine. The engine displaces 136.6 ci.
What hitch category is the Iseki TA417?
The Iseki TA417 uses a Category I hitch.
What is the operating weight of the Iseki TA417?
In working trim, the Iseki TA417 comes in at roughly 3,814 lb.
How do I maintain a Iseki TA417?
Routine service for the Iseki TA417 covers engine oil and filter changes, hydraulic and coolant level checks, air filter cleaning, and scheduled inspections. Refer to the manufacturer's maintenance schedule for exact intervals.
